Here you will find all available parts and drawings of the 'Milwaukee 4000393004 ( WCS45 )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Milwaukee 4000393004 ( WCS45 )
Spare parts list of model Milwaukee 4000393004 ( WCS45 )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| No longer available, no replacement | ||||
| 0004 | 4931383611 | |||
| No longer available, no replacement | ||||
| 0005 | 44760050 | |||
| No information available, not orderable | ||||
| 0007 | 12990005 | |||
| TYPE PLATE | ||||
| 0008 | 4931378806 | 5.40 | 6.53 | |
| DRIVING PLATE | ||||
| 0011 | 4931413244 | 52.27 | 63.25 | |
| GUARD CAP | ||||
| 0012 | 4931413247 | 74.45 | 90.08 | |
| COVER | ||||
| 0013 | 4931383375 | 5.40 | 6.53 | |
| SPRING | ||||
| 0014 | 4931383376 | 5.40 | 6.53 | |
| BUSH (2 needed) | ||||
| 0015 | 4931383377 | 5.40 | 6.53 | |
| AXLE | ||||
| 0016 | 4931383378 | 17.42 | 21.08 | |
| ROLL (4 needed) | ||||
| 0017 | 4931383379 | 5.40 | 6.53 | |
| AXLE (2 needed) | ||||
| 0018 | 4931383384 | 5.40 | 6.53 | |
| COVER PLATE | ||||
| 0019 | 4931383381 | 30.10 | 36.42 | |
| WASHER | ||||
| 0020 | 4931383382 | 1.80 | 2.18 | |
| SPACER | ||||
| 0021 | 4931383383 | 4.49 | 5.43 | |
| NUT D 985 M 6 GAL | ||||
| 0022 | 4931616196 | 1.80 | 2.18 | |
| WASHER | ||||
| 0023 | 4931383386 | 1.80 | 2.18 | |
| BUSH | ||||
| 0024 | 4931383385 | 5.40 | 6.53 | |
| RULER THRUST | ||||
| 0025 | 4931383387 | 3.60 | 4.36 | |
| NUT D 934 M 6 | ||||
| 0026 | 4931621674 | 5.40 | 6.53 | |
| LOCKING ROD | ||||
| 0027 | 4931383388 | 10.80 | 13.07 | |
| PRESSURE SPRING | ||||
| 0028 | 4931383389 | 4.49 | 5.43 | |
| DRIVING SHAFT | ||||
| 0029 | 4931383390 | 87.12 | 105.42 | |
| CLAMPING FLANGE | ||||
| 0030 | 4931348960 | 5.40 | 6.53 | |
| BUSH | ||||
| 0032 | 4931383392 | 25.34 | 30.66 | |
| KEY | ||||
| 0033 | 4931383393 | 5.40 | 6.53 | |
| SLEEVE | ||||
| 0039 | 4931383395 | 19.01 | 23.00 | |
| CLAMPING LEVER | ||||
| 0040 | 4931383499 | 18.15 | 21.96 | |
| NEEDLE BEARING N874989 HK 1010 | ||||
| 0041 | 4931943567 | 1.80 | 2.18 | |
| SHAFT CLIP | ||||
| 0042 | 4931621973 | 5.40 | 6.53 | |
| O-RING | ||||
| 0043 | 4931383396 | 1.80 | 2.18 | |
| SCREW (4 needed) | ||||
| 0044 | 4931383397 | 1.80 | 2.18 | |
| SCREW D 912 M 4X10 SSI (2 needed) | ||||
| 0045 | 4931624384 | 1.80 | 2.18 | |
| SCREW D912 M6X12 (2 needed) | ||||
| 0046 | 4931607021 | 4.49 | 5.43 | |
| No longer available, no replacement | ||||
| 0047 | 4931383399 | |||
| SCREW D 912 M 4X10 SSI | ||||
| 0048 | 4931624382 | 1.80 | 2.18 | |
| SPRING WASHER (3 needed) | ||||
| 0049 | 4931623799 | 1.80 | 2.18 | |
| SEALING WASHER (4 needed) | ||||
| 0050 | 4931615511 | 1.80 | 2.18 | |
| RING D471 12X1 (2 needed) | ||||
| 0051 | 4931605142 | 5.40 | 6.53 | |
| No longer available, no replacement | ||||
| 0052 | 4931383504 | |||
| COVER | ||||
| 0053 | 4931385349 | 4.49 | 5.43 | |
| CARRY.C.W.COVER BOX MET | ||||
| 0070 | 4932383357 | 166.16 | 201.05 | |
| HOUSING | ||||
| 0100 | 31500050 | 34.85 | 42.17 | |
| BONNET | ||||
| 0101 | 4931383613 | 12.60 | 15.25 | |
| MOTOR ASSEMBLY | ||||
| 0105 | 290302004 | 139.39 | 168.66 | |
| MOTOR ASSEMBLY | ||||
| 0106 | 290302004 | 139.39 | 168.66 | |
| BALL BEARING | ||||
| 0108 | 4931435723 | 9.00 | 10.89 | |
| BALL BEARING | ||||
| 0108 | 02041850 | 8.64 | 10.45 | |
| BALL BEARING | ||||
| 0108 | 2041850 | 5.00 | 6.05 | |
| Ball bearing for power tools | ||||
| 0109 | 02040847 | 8.64 | 10.45 | |
| BALL BEARING | ||||
| 0109 | 2040847 | 5.00 | 6.05 | |
| AIR DEFLECTOR RING | ||||
| 0111 | 31050045 | 5.68 | 6.87 | |
| WASHER (2 needed) | ||||
| 0112 | 45880577 | 1.90 | 2.30 | |
| No longer available, no replacement | ||||
| 0125 | 23941180 | |||
| SWITCH | ||||
| 0126 | 4931385373 | 95.04 | 115.00 | |
| BRUSH HOLDER (2 needed) | ||||
| 0130 | 22220030 | 5.40 | 6.53 | |
| CARBON BRUSH | ||||
| 0131 | 22180085 | 7.20 | 8.71 | |
| SWITCH RETAINER | ||||
| 0134 | 4931385599 | 4.49 | 5.43 | |
| SWITCH | ||||
| 0135 | 23662117 | 14.40 | 17.42 | |
| No information available, not orderable | ||||
| 0136 | 05890045 | |||
| SCREW (12 needed) | ||||
| 0138 | 06827270 | 1.90 | 2.30 | |
| SCREW (6 needed) | ||||
| 0138 | 6827270 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 0139 | 1000063920 | |||
| CAPACITOR | ||||
| 0140 | 14201325 | 15.29 | 18.50 | |
| SEALING WASHER | ||||
| 0149 | 4931383422 | 1.80 | 2.18 | |
| No longer available, no replacement | ||||
| 0150 | 4931383614 | |||
| No longer available, no replacement | ||||
| 0151 | 44520682 | |||
| STRIP-BAND | ||||
| 0152 | 4931383615 | 22.18 | 26.84 | |
| GEAR | ||||
| 0153 | 4931383616 | 20.59 | 24.91 | |
| O-RING | ||||
| 0154 | 34401375 | 1.90 | 2.30 | |
| O-RING | ||||
| 0155 | 34401380 | 1.80 | 2.18 | |
| SLIDER | ||||
| 0156 | 4931383617 | 1.80 | 2.18 | |
| MOTOR ASSEMBLY | ||||
| 0200 | 290302004 | 139.39 | 168.66 | |
| No longer available, no replacement | ||||
| 0214 | 4931393224 | |||
| Location bolt | ||||
| 0401 | 4931383394 | 23.76 | 28.75 | |
| CLAMPING NUT | ||||
| 0402 | 4931449262 | 118.80 | 143.75 | |
| ADJUSTING LOCK | ||||
| 0403 | 4931449351 | 58.61 | 70.92 | |
| Opspansleutel, gebogen | ||||
| 0601 | 4932371469 | 8.04 | 9.73 | |
| SCREW DRIVER | ||||
| 0602 | 4931606753 | 1.80 | 2.18 | |
| No information available, not orderable | ||||
| 0701 | 4932334704 | |||
| Zijhandgreep tbv slijpmachines 180 - 230 mm | ||||
| 0703 | 4931433531 | 11.40 | 13.79 | |
| T-sleutel | ||||
| 0708 | 4931362928 | 5.00 | 6.05 | |
| Afzuigslangadapter | ||||
| 0710 | 4932362778 | 30.14 | 36.47 | |
| NOSEPIECE | ||||
| 0720 | 4931419658 | 17.42 | 21.08 | |
