Here you will find all available parts and drawings of the 'Milwaukee 4000497988 ( M18FHIWF1R-0C )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Milwaukee 4000497988 ( M18FHIWF1R-0C )
Spare parts list of model Milwaukee 4000497988 ( M18FHIWF1R-0C )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| SWITCH LEVER | ||||
| 0003 | 4931496036 | 3.00 | 3.63 | |
| ISOLATION | ||||
| 0007 | 4931496037 | 3.00 | 3.63 | |
| COVER | ||||
| 0008 | 4931496038 | 3.60 | 4.36 | |
| RUBBER SLEEVE (2 needed) | ||||
| 0020 | 4931496039 | 7.20 | 8.71 | |
| TUBE | ||||
| 0021 | 4931496040 | 25.30 | 30.61 | |
| SUPPORTING RING | ||||
| 0026 | 4931496041 | 3.00 | 3.63 | |
| GEAR CASE | ||||
| 0027 | 4931496042 | 18.70 | 22.63 | |
| INTERN.GEARED WHEEL | ||||
| 0028 | 4931496043 | 18.70 | 22.63 | |
| HOLDING RING | ||||
| 0029 | 4931465319 | 3.00 | 3.63 | |
| GASKET | ||||
| 0030 | 4931472118 | 4.49 | 5.43 | |
| RUBBER FOOT | ||||
| 0032 | 4931496044 | 11.40 | 13.79 | |
| BALL BEARING | ||||
| 0034 | 4931496055 | 3.00 | 3.63 | |
| BALL BEARING | ||||
| 0037 | 4931472120 | 5.40 | 6.53 | |
| BALL BEARING | ||||
| 0038 | 4931472117 | 5.40 | 6.53 | |
| BEARING WASHER | ||||
| 0039 | 4931465317 | 3.00 | 3.63 | |
| PIN (3 needed) | ||||
| 0040 | 671565004 | 4.49 | 5.43 | |
| PLANETARY DRIVE (3 needed) | ||||
| 0041 | 4931465316 | 5.30 | 6.41 | |
| CAM SHAFT | ||||
| 0042 | 4931472116 | 101.38 | 122.67 | |
| SPRING | ||||
| 0043 | 4931472114 | 14.40 | 17.42 | |
| WASHER | ||||
| 0044 | 4931472113 | 4.49 | 5.43 | |
| BALL (31 needed) | ||||
| 0045 | 4931440453 | 3.00 | 3.63 | |
| HAMMER | ||||
| 0046 | 4931472112 | 123.55 | 149.50 | |
| BALL (3 needed) | ||||
| 0047 | 4931472115 | 1.80 | 2.18 | |
| O-RING | ||||
| 0049 | 4931472111 | 3.00 | 3.63 | |
| PROTECTION WASHER | ||||
| 0050 | 4931472110 | 7.20 | 8.71 | |
| RUBBER DISC | ||||
| 0051 | 4931472109 | 3.00 | 3.63 | |
| SCREW (12 needed) | ||||
| 0052 | 4931473361 | 3.00 | 3.63 | |
| SCREW (8 needed) | ||||
| 0053 | 4931465543 | 3.00 | 3.63 | |
| SCREW (6 needed) | ||||
| 0054 | 4931480405 | 3.00 | 3.63 | |
| SCREW (4 needed) | ||||
| 0055 | 4931480449 | 3.00 | 3.63 | |
| FOAM | ||||
| 0056 | 4931496045 | 1.20 | 1.45 | |
| GUARD | ||||
| 0058 | 4931494988 | 22.55 | 27.29 | |
| LABEL | ||||
| 0059 | 4931496046 | 1.20 | 1.45 | |
| ANVIL | ||||
| 0101 | 4931472125 | 128.30 | 155.24 | |
| HAMMER | ||||
| 0102 | 4931472126 | 174.24 | 210.83 | |
| ROTOR | ||||
| 0105 | 4931496047 | 79.20 | 95.83 | |
| ELECTRONIC | ||||
| 0106 | 4931496048 | 233.20 | 282.17 | |
| SWITCH | ||||
| 0107 | 4931496049 | 8.40 | 10.16 | |
| GEAR BOX COVER | ||||
| 0109 | 4931496050 | 73.15 | 88.51 | |
| HOUSING | ||||
| 0120 | 4931496051 | 66.00 | 79.86 | |
| HANDLE | ||||
| 0121 | 4931496052 | 27.50 | 33.28 | |
| MOTOR HOUSING | ||||
| 0122 | 4931496053 | 61.60 | 74.54 | |
| TOOL BOX | ||||
| 0700 | 4931496054 | 148.50 | 179.68 | |
