Here you will find all available parts and drawings of the 'Milwaukee 4000427255 (HD18PXP-H06202CGB2)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Milwaukee 4000427255 (HD18PXP-H06202CGB2)
Spare parts list of model Milwaukee 4000427255 (HD18PXP-H06202CGB2)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| No longer available, no replacement | ||||
| 0003 | 521623001 | |||
| CONNECTOR | ||||
| 0005 | 302119005 | 4.54 | 5.49 | |
| DIAPHRAGM | ||||
| 0008 | 641678001 | 9.06 | 10.96 | |
| No longer available, no replacement | ||||
| 0021 | 611241001 | |||
| PIN | ||||
| 0024 | 4931512376 | 3.00 | 3.63 | |
| BOLT | ||||
| 0025 | 672320001 | 4.49 | 5.43 | |
| ROLL | ||||
| 0026 | 692341002 | 5.40 | 6.53 | |
| BOLT | ||||
| 0027 | 4931441173 | 5.40 | 6.53 | |
| NEEDLE BEARING | ||||
| 0030 | 4931512377 | 6.00 | 7.26 | |
| BALL BEARING | ||||
| 0033 | 4931512378 | 8.40 | 10.16 | |
| FRICTION DISC | ||||
| 0036 | 611044001 | 6.82 | 8.25 | |
| COLLAR | ||||
| 0037 | 611260001 | 7.20 | 8.71 | |
| No longer available, no replacement | ||||
| 0038 | 692561001 | |||
| No longer available, no replacement | ||||
| 0040 | 633487001 | |||
| No longer available, no replacement | ||||
| 0042 | 692560001 | |||
| O-RING | ||||
| 0043 | 562464001 | 3.60 | 4.36 | |
| SPRING | ||||
| 0048 | 692471001 | 3.60 | 4.36 | |
| SPRING | ||||
| 0049 | 692472002 | 3.00 | 3.63 | |
| PRESSURE SPRING | ||||
| 0050 | 4931408243 | 5.40 | 6.53 | |
| SCREW | ||||
| 0051 | 661004001 | 3.00 | 3.63 | |
| LOCKING SCREW | ||||
| 0052 | 661004002 | 3.00 | 3.63 | |
| SCREW | ||||
| 0053 | 660031016 | 3.00 | 3.63 | |
| SCREW (18 needed) | ||||
| 0054 | 660031017 | 3.60 | 4.36 | |
| NAME PLATE | ||||
| 0059 | 940038262 | 3.00 | 3.63 | |
| SWITCH ASSEMBLY | ||||
| 0063 | 201320006 | 50.69 | 61.33 | |
| HANDLE COMPL. | ||||
| 0064 | 200447010 | 20.59 | 24.91 | |
| GEAR BOX | ||||
| 0065 | 200001015 | 52.27 | 63.25 | |
| GEARWHEEL SET | ||||
| 0066 | 201079004 | 68.11 | 82.41 | |
| COVER ASSY | ||||
| 0067 | 200990012 | 30.10 | 36.42 | |
| MOTOR ASSEMBLY | ||||
| 0068 | 200663005 | 44.35 | 53.66 | |
| GEAR BOX | ||||
| 0069 | 200281044 | 80.78 | 97.74 | |
| SPINDLE KIT | ||||
| 0070 | 4931512374 | 62.70 | 75.87 | |
| CARRYING CASE | ||||
| 0700 | 4931512380 | 25.30 | 30.61 | |
