Here you will find all available parts and drawings of the 'Metabo 01613000 ( MS36-18LTXBL40 )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Metabo 01613000 ( MS36-18LTXBL40 )
Spare parts list of model Metabo 01613000 ( MS36-18LTXBL40 )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Sprocket seal | ||||
| 1 | 316076150 | 5.18 | 6.27 | |
| Complete sword plate | ||||
| 2 | 316076160 | 8.89 | 10.76 | |
| Complete Oil Pump | ||||
| 3 | 316076170 | 11.74 | 14.21 | |
| Complete Chain Wheel | ||||
| 4 | 316076180 | 18.80 | 22.75 | |
| Complete Chain Tensioner | ||||
| 5 | 316076190 | 11.74 | 14.21 | |
| Complete Engine Brake | ||||
| 6 | 316076200 | 16.25 | 19.66 | |
| ELEKTRONISCHE UNIT COMPL. | ||||
| 7 | 316082630 | 209.82 | 253.88 | |
| Complete gear housing | ||||
| 8 | 316076210 | 48.48 | 58.66 | |
| Complete Guide Hook | ||||
| 9 | 316076220 | 8.89 | 10.76 | |
| Ontregelaar cpl. | ||||
| 10 | 316076230 | 5.87 | 7.10 | |
| Motor-unit compl. | ||||
| 11 | 316076240 | 201.99 | 244.41 | |
| Luchtgeleidingsschijf cpl. | ||||
| 12 | 316076250 | 5.18 | 6.27 | |
| Complete switch pusher | ||||
| 13 | 316076260 | 8.89 | 10.76 | |
| Switch | ||||
| 14 | 343413160 | 32.27 | 39.05 | |
| Brush pot oil tank complete | ||||
| 15 | 316076270 | 8.89 | 10.76 | |
| Olietank compl. | ||||
| 16 | 316076280 | 12.23 | 14.80 | |
| Hand protection cpl. | ||||
| 17 | 316076290 | 11.74 | 14.21 | |
| Bracket handle complete | ||||
| 18 | 316076300 | 16.25 | 19.66 | |
| No information available, not orderable | ||||
| 19 | 628439000 | |||
| No information available, not orderable | ||||
| 20 | 628437000 | |||
| Chain Guard | ||||
| 21 | 343460050 | 11.74 | 14.21 | |
| Combination Wrench | ||||
| 22 | 339149940 | 5.18 | 6.27 | |
| Micro switch cpl. | ||||
| 23 | 343413170 | 13.48 | 16.31 | |
| Type plate HK 85 EB 230V | ||||
| 25 | 338136110 | 1.68 | 2.03 | |
| No information available, not orderable | ||||
| 26 | 144162850 | |||
| Identification plate | ||||
| 27 | 338132520 | 1.68 | 2.03 | |
| Identification plate, | ||||
| 28 | 338136130 | 1.68 | 2.03 | |
| Identification plate, | ||||
| 29 | 338136120 | 1.68 | 2.03 | |
| Identification plate, CAS | ||||
| 30 | 338129960 | 1.68 | 2.03 | |
| Type plate HK 85 EB 230V | ||||
| 31 | 338080090 | 1.68 | 2.03 | |
| No information available, not orderable | ||||
| 1001 | 338510980 | |||
