Here you will find all available parts and drawings of the 'Metabo 0250550022-11 ( HWW5500/50M )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Metabo 0250550022-11 ( HWW5500/50M )
Spare parts list of model Metabo 0250550022-11 ( HWW5500/50M )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| No information available, not orderable | ||||
| 1 | 1341676033 | |||
| OLIERING ET | ||||
| 2 | 1349148818 | 1.55 | 1.88 | |
| BALL BEARING | ||||
| 3 | 7100136915 | 7.22 | 8.74 | |
| Rotor ET | ||||
| 4 | 1349676520 | 148.53 | 179.72 | |
| Motor complete | ||||
| 6 | 317004340 | 268.64 | 325.05 | |
| No longer available, no replacement | ||||
| 9 | 1349148893 | |||
| LAGERDEKSEL ET | ||||
| 10 | 1349148869 | 13.48 | 16.31 | |
| WAAIER ET | ||||
| 11 | 1349148877 | 3.02 | 3.65 | |
| FAN HOUSING ET | ||||
| 12 | 1349148885 | 7.22 | 8.74 | |
| No information available, not orderable | ||||
| 13 | 6109610443 | |||
| PUMP CYLINDER ET | ||||
| 14 | 1349676598 | 148.53 | 179.72 | |
| Cilinderkopschroef | ||||
| 15 | 141113840 | 1.67 | 2.02 | |
| O-RING ET | ||||
| 16 | 7632676608 | 3.02 | 3.65 | |
| ADAPTER ET | ||||
| 17 | 1349676547 | 18.80 | 22.75 | |
| PUMP CYLINDER COVER ET | ||||
| 18 | 1349676555 | 32.27 | 39.05 | |
| SCHROEF WIEL ET | ||||
| 19 | 1349148729 | 1.67 | 2.02 | |
| WIEL ET | ||||
| 20 | 1349148745 | 18.80 | 22.75 | |
| GELEIDEROL ET | ||||
| 21 | 1349148753 | 26.95 | 32.61 | |
| TRANSPORT WHEEL ET | ||||
| 23 | 1349676660 | 13.48 | 16.31 | |
| Sliding seal ET | ||||
| 24 | 1349676679 | 26.95 | 32.61 | |
| No information available, not orderable | ||||
| 25 | 7632149217 | |||
| CLOSURE ET | ||||
| 26 | 1349676687 | 32.27 | 39.05 | |
| No longer available, no replacement | ||||
| 27 | 1343610838 | |||
| No longer available, no replacement | ||||
| 28 | 1349148850 | |||
| VERDEELSTUK 5-FACH ET | ||||
| 29 | 1349149040 | 32.27 | 39.05 | |
| PRESSURE GAUGE CONNECTION REAR RD 40 R1/4" | ||||
| 30 | 7823127590 | 26.95 | 32.61 | |
| No longer available, no replacement | ||||
| 31 | 1349148982 | |||
| PRESSURE HOSE 600 MM 1" BERW. 1" AG /ET | ||||
| 33 | 7853622510 | 67.33 | 81.47 | |
| Gasket 30X23X3 ET | ||||
| 34 | 7631131454 | 3.02 | 3.65 | |
| Hexagonal screw | ||||
| 35 | 6103001178 | 1.55 | 1.88 | |
| Self-locking hexagon nut | ||||
| 36 | 6202002305 | 1.55 | 1.88 | |
| Hexagonal screw | ||||
| 37 | 6103001178 | 1.55 | 1.88 | |
| No longer available, no replacement | ||||
| 38 | 1349676827 | |||
| RUBBER BELLOW 50 L ET ZILMET | ||||
| 39 | 1349677314 | 134.27 | 162.47 | |
| No information available, not orderable | ||||
| 40 | 7830635607 | |||
| Dust cap ET | ||||
| 41 | 1349635557 | 1.55 | 1.88 | |
| Pressure vessel 50 L ET | ||||
| 42 | 1349622501 | 296.22 | 358.43 | |
