Here you will find all available parts and drawings of the 'Metabo 0200033000-11 ( DH330 )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Metabo 0200033000-11 ( DH330 )
Spare parts list of model Metabo 0200033000-11 ( DH330 )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| COVER DH 330 | ||||
| 1 | 1011711711 | 32.27 | 39.05 | |
| No longer available, no replacement | ||||
| 2 | 1011711819 | |||
| Left cap | ||||
| 3 | 1381711729 | 3.71 | 4.49 | |
| CHAIN TENSIONER DH 330 | ||||
| 4 | 1011711746 | 8.89 | 10.76 | |
| COVER DH 330 | ||||
| 5 | 1381712555 | 21.64 | 26.18 | |
| Indicator DH 330 | ||||
| 6 | 1011711770 | 5.87 | 7.10 | |
| No information available, not orderable | ||||
| 7 | 1011711789 | |||
| Table extension DH 330 | ||||
| 8 | 1011711797 | 107.70 | 130.32 | |
| Crank feed DH 330 | ||||
| 9 | 1011711800 | 26.95 | 32.61 | |
| Right cap | ||||
| 10 | 1381711737 | 3.02 | 3.65 | |
| CHIP EXTRACTION DEVICE DH 330 | ||||
| 12 | 1011711835 | 24.23 | 29.32 | |
| No longer available, no replacement | ||||
| 13 | 1388711848 | |||
| No longer available, no replacement | ||||
| 14 | 1381712563 | |||
| GUIDE DH 330 | ||||
| 15 | 1011711851 | 32.27 | 39.05 | |
| COMPLETE MOTOR 230V/60HZ DH 330 | ||||
| 20 | 1011712572 | 469.34 | 567.90 | |
| COMPLETE ROTOR 230V/60HZ DH 330 | ||||
| 22 | 1011712602 | 213.88 | 258.79 | |
| CARBON BRUSH SET 230V/60HZ DH 330 | ||||
| 23 | 1011712580 | 26.95 | 32.61 | |
| Overload protection 230V-8A TS 250 | ||||
| 24 | 8116706793 | 11.74 | 14.21 | |
| SWITCH 230V/60HZ DH 330 | ||||
| 26 | 1011712599 | 67.33 | 81.47 | |
| CHAIN SET DH 330 | ||||
| 30 | 1011711886 | 24.23 | 29.32 | |
| Compression Spring Set DH 330 | ||||
| 31 | 1011711922 | 5.87 | 7.10 | |
| Shaft for Blades DH 330 | ||||
| 32 | 1011719453 | 296.22 | 358.43 | |
| Rubber Shaft DH 330 | ||||
| 33 | 1011711894 | 67.33 | 81.47 | |
| No longer available, no replacement | ||||
| 34 | 1011712610 | |||
| CHIP UNIT DH 330 | ||||
| 35 | 1011711860 | 134.27 | 162.47 | |
| V-GROOVE DH 330 | ||||
| 36 | 7233712030 | 32.27 | 39.05 | |
| Ruler DH 330 | ||||
| 37 | 1011719461 | 26.95 | 32.61 | |
| Compression Spring Set DH 330 | ||||
| 38 | 1011719470 | 3.02 | 3.65 | |
| Blocking DH 330 ET | ||||
| 40 | 1388727027 | 3.71 | 4.49 | |
| TORX ALLEN KEY | ||||
| 41 | 1388727035 | 8.89 | 10.76 | |
| RUBBER CABLE WITH PLUG | ||||
| 43 | 1009621039 | 43.15 | 52.21 | |
