Here you will find all available parts and drawings of the 'Metabo 0230125000-10 ( BASICAIR250 )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Metabo 0230125000-10 ( BASICAIR250 )

Spare parts list of model Metabo 0230125000-10 ( BASICAIR250 )

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
No information available, not orderable
12 7823088501
PRESSURE REGULATOR 6-8 BAR 230V MDR2/11 1X3/8"
13 8101149774 74.13 89.70
No information available, not orderable
14 7833662605
Reduction Valve RP-192 1/4"I-A ET
15 341164670 10.38 12.56
Snelkoppeling Euro 1/4" AG
16 7802009083 6.64 8.03
PERSLEIDING ClassicAir 255
21 1319738149 16.25 19.66
No longer available, no replacement
25 1319738165
NON-RETURN VALVE ClassicAir 255
26 7831738175 26.95 32.61
No information available, not orderable
27 316049330
No information available, not orderable
28 7830731762
No information available, not orderable
30 7823088510
Locking screw R 1/2 galv.
32 6109079322 11.74 14.21
No information available, not orderable
33 7057738213
Complete valve
900 1319741468 18.80 22.75
ZUIGER COMPLEET ClassicAir 255
901 1319738157 32.27 39.05
GASKET ET
904 1319741476 43.15 52.21
Cylinder Head
906 1319741484 18.80 22.75
No longer available, no replacement
909 1319741492
LUCHTFILTER
911 341164790 5.20 6.29
No information available, not orderable
914 1001741434
CAPACITOR 30uF/450V CABLE SIDE.280 LA
918 8050700004 87.60 106.00
COVER
919 1001741442 32.27 39.05
No information available, not orderable
920 343434170
