Here you will find all available parts and drawings of the 'Metabo 00323260 (B32/3)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Metabo 00323260 (B32/3)
Spare parts list of model Metabo 00323260 (B32/3)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Schakelknop | ||||
| 1 | 341058850 | 43.15 | 52.21 | |
| Steunstift | ||||
| 2 | 342003540 | 7.22 | 8.74 | |
| Complete shift lever | ||||
| 3 | 316043210 | 8.89 | 10.76 | |
| Circlip | ||||
| 4 | 141156430 | 1.56 | 1.89 | |
| Cilinderkopschroef | ||||
| 5 | 141113680 | 1.68 | 2.03 | |
| Naaldlager | ||||
| 6 | 143115130 | 5.18 | 6.27 | |
| Complete coupling | ||||
| 13 | 316043200 | 321.76 | 389.33 | |
| O-ring | ||||
| 14 | 143195190 | 4.51 | 5.46 | |
| Naaldlager | ||||
| 15 | 143115120 | 5.87 | 7.10 | |
| Cilinderstift | ||||
| 16 | 141164000 | 1.68 | 2.03 | |
| Tandwielflens compl. | ||||
| 17 | 316043220 | 100.74 | 121.90 | |
| Gegolfde dichtring | ||||
| 18 | 143195170 | 12.23 | 14.80 | |
| Kogellager 12x28x 8 | ||||
| 19 | 143114800 | 12.23 | 14.80 | |
| Retaining ring | ||||
| 20 | 141164010 | 1.56 | 1.89 | |
| Cilinderstift | ||||
| 21 | 141163980 | 1.56 | 1.89 | |
| O-ring | ||||
| 22 | 143195180 | 1.56 | 1.89 | |
| Cilinderstift | ||||
| 23 | 141164020 | 1.56 | 1.89 | |
| Corrugated sealing ring | ||||
| 24 | 143192880 | 7.22 | 8.74 | |
| Kogellager | ||||
| 25 | 143115150 | 11.74 | 14.21 | |
| Shim | ||||
| 26 | 141156410 | 1.56 | 1.89 | |
| Spindle wheel | ||||
| 27 | 340003880 | 53.86 | 65.17 | |
| Locking ring | ||||
| 28 | 141181080 | 1.55 | 1.88 | |
| Ball | ||||
| 29 | 143120080 | 1.56 | 1.89 | |
| Pressure spring | ||||
| 30 | 342003530 | 1.68 | 2.03 | |
| Parallel key | ||||
| 31 | 141140190 | 5.18 | 6.27 | |
| Kogellager | ||||
| 32 | 143115140 | 8.89 | 10.76 | |
| Tandwielas | ||||
| 33 | 340003960 | 53.86 | 65.17 | |
| Tandwielas | ||||
| 34 | 340003970 | 48.48 | 58.66 | |
| Gear wheel | ||||
| 35 | 340003920 | 100.74 | 121.90 | |
| Borgveer-ring | ||||
| 36 | 141164080 | 1.56 | 1.89 | |
| Sliding block | ||||
| 37 | 340003950 | 128.32 | 155.27 | |
| Gear wheel | ||||
| 38 | 340003930 | 100.74 | 121.90 | |
| Retaining ring | ||||
| 39 | 141180080 | 1.56 | 1.89 | |
| Naaldlager | ||||
| 40 | 143115110 | 13.48 | 16.31 | |
| Fitting spring | ||||
| 41 | 141140080 | 1.56 | 1.89 | |
| Tussenwiel | ||||
| 42 | 340003940 | 43.15 | 52.21 | |
| snap ring | ||||
| 43 | 141180090 | 1.68 | 2.03 | |
| Countersunk head screw | ||||
| 44 | 141123630 | 1.56 | 1.89 | |
| Handle shell set | ||||
| 45 | 343463140 | 16.25 | 19.66 | |
| Clamp | ||||
| 46 | 339160750 | 1.56 | 1.89 | |
| Self-tap. fill. h. screw | ||||
| 47 | 341701460 | 1.56 | 1.89 | |
| Switch | ||||
| 48 | 343413380 | 43.15 | 52.21 | |
| Spindle | ||||
| 49 | 341604060 | 175.84 | 212.77 | |
| PASSFEDER | ||||
| 50 | 141140140 | 3.02 | 3.65 | |
| Circlip | ||||
| 51 | 141180870 | 1.68 | 2.03 | |
| Washer | ||||
| 52 | 339007170 | 1.68 | 2.03 | |
| Deep groove ball bearing, 30x55x13 | ||||
| 53 | 143112270 | 37.65 | 45.56 | |
| Tandwielhuis | ||||
| 54 | 315104780 | 213.88 | 258.79 | |
| Lensplaatschroef | ||||
| 55 | 141123640 | 1.56 | 1.89 | |
| Extra Handle | ||||
| 56 | 314001120 | 48.48 | 58.66 | |
| Type plate | ||||
| 57 | 338082170 | 1.67 | 2.02 | |
| Koolborstelset,230V | ||||
| 58 | 343012350 | 80.81 | 97.78 | |
| Lock washer | ||||
| 59 | 141156400 | 1.56 | 1.89 | |
| Circlip | ||||
| 60 | 342022150 | 1.68 | 2.03 | |
| Anker 230V | ||||
| 61 | 310009380 | 405.62 | 490.80 | |
| Bearing cap | ||||
| 62 | 343394830 | 7.22 | 8.74 | |
| Field | ||||
| 63 | 311010900 | 161.61 | 195.55 | |
| Bush | ||||
| 64 | 341005780 | 13.48 | 16.31 | |
| Air guide disc | ||||
| 65 | 339151120 | 12.23 | 14.80 | |
| Motor housing | ||||
| 66 | 315013280 | 60.59 | 73.31 | |
| No longer available, no replacement | ||||
| 67 | 338122160 | |||
| Fill. head screw | ||||
| 68 | 141120070 | 1.56 | 1.89 | |
| Motor cap | ||||
| 69 | 343394840 | 18.80 | 22.75 | |
| Self-tap. fill. h. screw | ||||
| 70 | 141119370 | 1.56 | 1.89 | |
| Condensator | ||||
| 71 | 343254520 | 5.87 | 7.10 | |
| Self-tap. fill. h. screw | ||||
| 72 | 141119380 | 1.56 | 1.89 | |
| Afdekplaat | ||||
| 73 | 343395400 | 2.28 | 2.76 | |
| Kabeldoorvoer | ||||
| 74 | 344098420 | 5.87 | 7.10 | |
| Cable | ||||
| 75 | 344497560 | 32.27 | 39.05 | |
| No information available, not orderable | ||||
| 76 | 642396000 | |||
| ADAPTER | ||||
| 77 | 341214240 | 85.96 | 104.01 | |
| Oil | ||||
| 880 | 344131190 | 100.74 | 121.90 | |
| No information available, not orderable | ||||
| 1001 | 338504790 | |||
