Here you will find all available parts and drawings of the 'Makita PW5000C'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita PW5000C
Spare parts list of model Makita PW5000C
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Lock Button Cap | ||||
| 001 | 417236-8 | 1.20 | 1.45 | |
| Compression Spring 8 | ||||
| 002 | 233376-2 | 1.00 | 1.21 | |
| Gear Cover | ||||
| 003 | 153488-4 | 19.80 | 23.96 | |
| Lock washer S-12 | ||||
| 004 | 961052-5 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 005 | 210105-0 | |||
| Washer 12 | ||||
| 006 | 253084-9 | 1.00 | 1.21 | |
| Inner Cover | ||||
| 008 | 317359-1 | 10.80 | 13.07 | |
| Fan 57 | ||||
| 009 | 240033-5 | 4.80 | 5.81 | |
| Armature Pw5000Ch * | ||||
| 010 | 515268-0 | 72.60 | 87.85 | |
| Insulation ring | ||||
| 011 | 681656-4 | 1.00 | 1.21 | |
| SLUITRING 7 LF1000 A | ||||
| 012 | 267326-5 | 1.00 | 1.21 | |
| Ball bearing 627ddw | ||||
| 013 | 210045-2 | 3.60 | 4.36 | |
| Labyrinth ring GA5040C A | ||||
| 014 | 422750-1 | 2.40 | 2.90 | |
| Spring Washer 6 | ||||
| 015 | 267756-0 | 1.00 | 1.21 | |
| Magnetic socket Rt0700 A | ||||
| 016 | 688117-5 | 3.60 | 4.36 | |
| Spring retaining ring | ||||
| 017 | 259039-2 | 1.00 | 1.21 | |
| Intermediate Plate | ||||
| 018 | 413076-2 | 2.40 | 2.90 | |
| Tapping Screw 4x70 | ||||
| 019 | 266258-3 | 1.20 | 1.45 | |
| Holding Plate | ||||
| 020 | 344871-8 | 1.20 | 1.45 | |
| Insulating Cap | ||||
| 021 | 417237-6 | 1.20 | 1.45 | |
| Field | ||||
| 022 | 626548-0 | 30.80 | 37.27 | |
| Tap screw 4x18 | ||||
| 023 | 265A48-7 | 1.00 | 1.21 | |
| Clamp Bracket | ||||
| 024 | 687124-5 | 1.00 | 1.21 | |
| Switch Holder | ||||
| 025 | 632945-0 | 9.60 | 11.62 | |
| Switch Sw-126 A | ||||
| 027 | 651069-3 | 8.40 | 10.16 | |
| Switch cover | ||||
| 028 | 687113-0 | 1.20 | 1.45 | |
| Cable gland 10 | ||||
| 029 | 682566-8 | 1.20 | 1.45 | |
| Power cord 2x1.50 4.0mtr | ||||
| 030 | 695123-3 | 22.00 | 26.62 | |
| No information available, not orderable | ||||
| 031 | 816398-3 | |||
| Rear House Pw5000Ch * | ||||
| 032 | 418453-3 | 9.60 | 11.62 | |
| Tap screw 4x18 | ||||
| 033 | 265A48-7 | 1.00 | 1.21 | |
| Self Tapper Pt 3x10 | ||||
| 035 | 266256-7 | 1.00 | 1.21 | |
| Brush Holder R Pw5000Ch * | ||||
| 036 | 643765-7 | 6.00 | 7.26 | |
| Carbon brush set CB-318 | ||||
| 037 | 191978-9 | 8.40 | 10.16 | |
| Switch Button | ||||
| 038 | 417813-6 | 1.20 | 1.45 | |
| Label "makita" | ||||
| 039 | 819080-3 | 2.40 | 2.90 | |
| Motor Housing | ||||
| 040 | 418512-3 | 15.40 | 18.63 | |
| Brush Holder L Pw5000Ch * | ||||
| 041 | 643805-1 | 7.20 | 8.71 | |
| Compression Spring 4 | ||||
| 042 | 233071-4 | 1.00 | 1.21 | |
| Switch handle | ||||
| 043 | 417186-7 | 2.40 | 2.90 | |
| No information available, not orderable | ||||
| 044 | 631700-7 | |||
| Tap screw 4x18 | ||||
| 045 | 265A48-7 | 1.00 | 1.21 | |
| Mounting Plate Pw5000Ch * | ||||
| 046 | 345372-9 | 1.20 | 1.45 | |
| Water Hose Pw5000Ch * | ||||
| 047 | 245031-4 | 2.40 | 2.90 | |
| Tap Pw5000Ch * | ||||
| 048 | 154649-9 | 39.60 | 47.92 | |
| Nipple Pw5000Ch * | ||||
| 048A | 243098-6 | 7.20 | 8.71 | |
| Nipple Pw5000Ch * | ||||
| 049 | 331669-2 | 6.00 | 7.26 | |
| O-ring 12 | ||||
| 050 | 213107-5 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 051 | 743080-0 | |||
| Through-bushing Pw5000Ch * | ||||
| 052 | 324407-9 | 4.80 | 5.81 | |
| As Pw5000Ch * | ||||
| 053 | 324409-5 | 48.40 | 58.56 | |
| Feather Key 4 | ||||
| 054 | 254202-2 | 1.00 | 1.21 | |
| Hex bolt 4x16 | ||||
| 055 | 266437-3 | 1.00 | 1.21 | |
| Ball Bearing Housing | ||||
| 056 | 153717-5 | 34.10 | 41.26 | |
| Seal Ring 17 Pw5000Ch * | ||||
| 056A | 213280-1 | 6.00 | 7.26 | |
| Nipple Pw5000Ch * | ||||
| 056B | 243098-6 | 7.20 | 8.71 | |
| Ball Bearing 6201dw1 | ||||
| 057 | 211129-9 | 8.40 | 10.16 | |
| Bearing lock ring 19-33 | ||||
| 058 | 285841-7 | 2.40 | 2.90 | |
| O-ring 52 | ||||
| 059 | 213673-2 | 1.20 | 1.45 | |
| Gear 38 | ||||
| 060 | 227455-6 | 35.20 | 42.59 | |
| Lock washer S-12 | ||||
| 061 | 961052-5 | 1.00 | 1.21 | |
| Pin | ||||
| 062 | 256459-1 | 1.20 | 1.45 | |
| O-ring 6 | ||||
| 063 | 213048-5 | 1.00 | 1.21 | |
| Tapping Screw 4x28 | ||||
| 064 | 266257-5 | 1.00 | 1.21 | |
| Connector Pw5000Ch * | ||||
| 065 | 655033-6 | 11.00 | 13.31 | |
| Washer 22 | ||||
| 066 | 267126-3 | 1.20 | 1.45 | |
| Rubber Ring 12 Pw5000Ch * | ||||
| 067 | 261128-1 | 1.00 | 1.21 | |
| Plastic ring 10mm | ||||
| 068 | 261127-3 | 1.00 | 1.21 | |
