Here you will find all available parts and drawings of the 'Makita MT242'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita MT242
Spare parts list of model Makita MT242
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Screw 5x20 | ||||
| 002 | 265122-5 | 0.83 | 1.00 | |
| Outer/Inner flange 2414En A | ||||
| 003 | 224456-5 | 3.96 | 4.79 | |
| Hex bolt+Rivet M10X25 | ||||
| 004 | 251680-7 | 3.12 | 3.78 | |
| Cover Bush | ||||
| 005 | 418142-0 | 0.83 | 1.00 | |
| Cover Bush | ||||
| 006 | 418142-0 | 0.83 | 1.00 | |
| Spring protection cap | ||||
| 007 | 165707-6 | 17.38 | 21.03 | |
| Screw M6 | ||||
| 008 | 265121-7 | 0.83 | 1.00 | |
| Screw M6 | ||||
| 010 | 265121-7 | 0.83 | 1.00 | |
| Centering cap | ||||
| 011 | 346635-6 | 3.96 | 4.79 | |
| Wing bolt m6x12 | ||||
| 012 | 265754-8 | 0.83 | 1.00 | |
| O-ring 14 | ||||
| 013 | 213180-5 | 0.83 | 1.00 | |
| Washer 17mm | ||||
| 014 | 257255-0 | 0.83 | 1.00 | |
| Outer/Inner flange 2414En A | ||||
| 015 | 224456-5 | 3.96 | 4.79 | |
| Washer 17mm | ||||
| 016 | 257255-0 | 0.83 | 1.00 | |
| FIXED PROTECTIVE COVER | ||||
| 017 | 165706-8 | 27.90 | 33.76 | |
| No information available, not orderable | ||||
| 018 | 211282-1 | |||
| Bearing Housing | ||||
| 019 | 317663-8 | 3.97 | 4.80 | |
| Gear 49 | ||||
| 020 | 226572-9 | 11.34 | 13.72 | |
| Plunger | ||||
| 021 | 324321-9 | 3.54 | 4.28 | |
| Ball Bearing 6000zz | ||||
| 022 | 210067-2 | 1.18 | 1.43 | |
| Handle set | ||||
| 023 | 187128-2 | 12.22 | 14.79 | |
| Switch Tga115ct-2 | ||||
| 024 | 650545-4 | 3.54 | 4.28 | |
| Switch Handle | ||||
| 025 | 418140-4 | 0.83 | 1.00 | |
| Locking Button | ||||
| 026 | 418139-9 | 0.83 | 1.00 | |
| Compression Spring 4 | ||||
| 027 | 231397-8 | 0.83 | 1.00 | |
| Hanger | ||||
| 028 | 281216-8 | 0.83 | 1.00 | |
| No information available, not orderable | ||||
| 029 | 268101-2 | |||
| Handle set | ||||
| 030 | 187128-2 | 12.22 | 14.79 | |
| Child lock | ||||
| 031 | 418138-1 | 0.83 | 1.00 | |
| No information available, not orderable | ||||
| 032 | 266326-2 | |||
| Screw M5x40mm | ||||
| 034 | 265104-7 | 0.83 | 1.00 | |
| Terminal block Bo4553-Bo4554 A | ||||
| 035 | 654475-1 | 0.83 | 1.00 | |
| Noise suppression capacitor | ||||
| 036 | 645191-6 | 0.83 | 1.00 | |
| Line filter | ||||
| 037 | 688131-1 | 0.83 | 1.00 | |
| No information available, not orderable | ||||
| 038 | 266326-2 | |||
| Clamp Bracket | ||||
| 039 | 687124-5 | 0.83 | 1.00 | |
| Power cord 2x1.50 4.0mtr | ||||
| 040 | 695123-3 | 21.08 | 25.51 | |
| Cable grommet 10-90 | ||||
| 041 | 682505-8 | 1.67 | 2.02 | |
| Label | ||||
| 042 | 897918-2 | 2.71 | 3.28 | |
| Motor Housing | ||||
| 043 | 140939-6 | 11.82 | 14.30 | |
| Brush Holder | ||||
| 043A | 643564-7 | 2.02 | 2.44 | |
| Brush holder cap | ||||
| 044 | 643700-5 | 0.98 | 1.19 | |
| Koolborstel Set Cb-203 A | ||||
| 045 | 194991-6 | 6.38 | 7.72 | |
| Screw M5x40mm | ||||
| 046 | 265104-7 | 0.83 | 1.00 | |
| FIELD 220V | ||||
| 047 | 596249-3 | 26.55 | 32.13 | |
| No information available, not orderable | ||||
| 047A | 654237-7 | |||
| Clamping bushing for statorv. 2mm | ||||
| 047B | 654502-4 | 0.83 | 1.00 | |
| Screw 5x14mm | ||||
| 048 | 266328-8 | 0.83 | 1.00 | |
| Spacer plate | ||||
| 049 | 418143-8 | 0.83 | 1.00 | |
| Ball bearing 6202zz | ||||
| 050 | 211240-7 | 1.67 | 2.02 | |
| Armature 240v | ||||
| 051 | 517864-0 | 39.76 | 48.11 | |
| Fan 60 | ||||
| 052 | 240063-6 | 2.36 | 2.86 | |
| Washer 15 | ||||
| 053 | 267274-8 | 0.83 | 1.00 | |
| Ball bearing 6202zz | ||||
| 054 | 211240-7 | 1.67 | 2.02 | |
| Spring retaining ring | ||||
| 055 | 324322-7 | 0.83 | 1.00 | |
| Compression Spring 7 | ||||
| 056 | 233372-0 | 0.83 | 1.00 | |
| Gear Cover | ||||
| 057 | 153600-6 | 41.84 | 50.63 | |
| Rubber pen 6 | ||||
| 057A | 263029-9 | 0.83 | 1.00 | |
| Spring pin 5-20 | ||||
| 058 | 951163-4 | 0.83 | 1.00 | |
| No information available, not orderable | ||||
| 059 | 272027-2 | |||
| No information available, not orderable | ||||
| 060 | 324323-5 | |||
| Hexagonal bolt 6x10 | ||||
| 063 | 251961-9 | 0.83 | 1.00 | |
| Chain | ||||
| 064 | 282015-1 | 1.39 | 1.68 | |
| Screw spindle | ||||
| 065 | 313114-9 | 3.54 | 4.28 | |
| Spindle Nut Plate | ||||
| 066 | 345311-9 | 0.83 | 1.00 | |
| No information available, not orderable | ||||
| 067 | 317662-0 | |||
| Scoring Pin 5-36 | ||||
| 068 | 951175-7 | 0.83 | 1.00 | |
| Spring Pin 4-16 | ||||
| 069 | 951110-5 | 0.83 | 1.00 | |
| Met.screw M8x30mm | ||||
| 070 | 265125-9 | 0.83 | 1.00 | |
| Allen bolt M10x25mm | ||||
| 071 | 265508-3 | 1.00 | 1.21 | |
| Allen bolt M10x25mm | ||||
| 072 | 265508-3 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 073 | 346637-2 | |||
| No information available, not orderable | ||||
| 074 | 252183-4 | |||
| Lock Washer M10 | ||||
| 075 | 942251-8 | 0.83 | 1.00 | |
| Washer 10 | ||||
| 076 | 267258-6 | 0.83 | 1.00 | |
| Pipe 20-128 | ||||
| 077 | 331648-0 | 2.71 | 3.28 | |
| Torsion Spring 24 | ||||
| 078 | 231667-5 | 3.96 | 4.79 | |
| Spark arrestor | ||||
| 081 | 165705-0 | 1.67 | 2.02 | |
| Screw 6x12 | ||||
| 082 | 265144-5 | 0.83 | 1.00 | |
| Buffer | ||||
| 083 | 421834-2 | 0.83 | 1.00 | |
| Washer 10 | ||||
| 084 | 267258-6 | 0.83 | 1.00 | |
| Hexagonal bolt 10x140 | ||||
| 085 | 265509-1 | 1.66 | 2.01 | |
| Foot pad | ||||
| 086 | 165373-9 | 30.70 | 37.15 | |
| Lock ring S-8 | ||||
| 087 | 961004-6 | 0.83 | 1.00 | |
| Washer 8 | ||||
| 088 | 267257-8 | 0.83 | 1.00 | |
| No information available, not orderable | ||||
| 089 | 256545-8 | |||
| Lock ring S-16 | ||||
| 090 | 961056-7 | 0.83 | 1.00 | |
| Washer 8 | ||||
| 091 | 267257-8 | 0.83 | 1.00 | |
| No information available, not orderable | ||||
| 092 | 346636-4 | |||
| Washer 6mm A | ||||
| 093 | 267214-6 | 0.83 | 1.00 | |
| Rubber block | ||||
| 095 | 421870-8 | 5.06 | 6.12 | |
| Rubber block holder | ||||
| 096 | 345443-2 | 4.45 | 5.38 | |
| Insulation ring | ||||
| 097 | 681630-2 | 1.39 | 1.68 | |
