Here you will find all available parts and drawings of the 'Makita JS8000'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita JS8000
Spare parts list of model Makita JS8000
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| No information available, not orderable | ||||
| A01 | 783221-6 | |||
| No information available, not orderable | ||||
| A02 | 824780-2 | |||
| No information available, not orderable | ||||
| A03 | 804914-3 | |||
| Rubber Pin 4 | ||||
| C10 | 263002-9 | 1.00 | 1.21 | |
| Capacitor | ||||
| E01 | 645253-0 | 4.80 | 5.81 | |
| ZIJMES | ||||
| 001 | 725130-3 | 50.00 | 60.50 | |
| MIDDENMES | ||||
| 002 | 725129-8 | 57.00 | 68.97 | |
| Rotary Bush | ||||
| 003 | 331738-9 | 17.60 | 21.30 | |
| ZIJMES | ||||
| 004 | 725130-3 | 50.00 | 60.50 | |
| Socket | ||||
| 005 | 331737-1 | 11.00 | 13.31 | |
| No information available, not orderable | ||||
| 006 | 331736-3 | |||
| Hexagon socket screw M5x35 | ||||
| 007 | 266407-2 | 3.60 | 4.36 | |
| Locknut M5 | ||||
| 008 | 264007-2 | 3.60 | 4.36 | |
| SCHAARKOP COMPLEET | ||||
| 009 | 125354-5 | 131.00 | 158.51 | |
| Ball bearing eccentric | ||||
| 010 | 125355-3 | 112.20 | 135.76 | |
| Rivet 13 | ||||
| 011 | 267341-9 | 2.40 | 2.90 | |
| Coupling socket | ||||
| 013 | 331695-1 | 8.40 | 10.16 | |
| Spindle Ass'y | ||||
| 014 | 324394-2 | 6.00 | 7.26 | |
| Ball bearing 6002ddw | ||||
| 015 | 211236-8 | 9.60 | 11.62 | |
| Washer 22 | ||||
| 016 | 253793-0 | 1.20 | 1.45 | |
| Self Tapping Screw Pt4x30 | ||||
| 017 | 266050-7 | 1.00 | 1.21 | |
| Gear Cover | ||||
| 018 | 317727-8 | 11.00 | 13.31 | |
| No information available, not orderable | ||||
| 019 | 211014-6 | |||
| No information available, not orderable | ||||
| 019-1 | 211012-0 | |||
| Complete Gear 17-35 Js130* | ||||
| 020 | 226133-5 | 9.60 | 11.62 | |
| Washer 8 | ||||
| 021 | 267017-8 | 1.20 | 1.45 | |
| Gear 36 Js1300 * | ||||
| 022 | 227010-4 | 19.80 | 23.96 | |
| Gasket | ||||
| 023 | 442136-3 | 2.40 | 2.90 | |
| No information available, not orderable | ||||
| 024 | 152910-8 | |||
| Ball Bearing 608 | ||||
| 025 | 210007-0 | 6.00 | 7.26 | |
| Washer 8x0.5mm | ||||
| 026 | 253139-0 | 1.00 | 1.21 | |
| Fan 52 6824+6825 * | ||||
| 027 | 240022-0 | 2.40 | 2.90 | |
| Armature | ||||
| 028 | 517374-7 | 48.40 | 58.56 | |
| Insulation ring | ||||
| 029 | 681636-0 | 1.20 | 1.45 | |
| Ball bearing 607llb | ||||
| 030 | 211021-9 | 4.80 | 5.81 | |
| Rubber Ring for Bearing | ||||
| 031 | 421479-6 | 4.80 | 5.81 | |
| Tapping screw Pf 4x55 | ||||
| 032 | 266147-2 | 1.20 | 1.45 | |
| Intermediate Plate | ||||
| 033 | 416993-5 | 1.20 | 1.45 | |
| Field | ||||
| 034 | 633484-3 | 16.50 | 19.96 | |
| No information available, not orderable | ||||
| 035 | 183285-4 | |||
| No information available, not orderable | ||||
| 035-1 | 188628-5 | |||
| Motor Housing | ||||
| 035-2 | 450718-7 | 7.20 | 8.71 | |
| Hang Hook | ||||
| 036 | 417625-7 | 2.40 | 2.90 | |
| Label | ||||
| 037 | 862959-7 | 3.60 | 4.36 | |
| Carbon Brush Holder Js1300 * | ||||
| 038 | 643972-2 | 6.00 | 7.26 | |
| Label Makita | ||||
| 039 | 819063-3 | 2.40 | 2.90 | |
| Brush Set CB-419 | ||||
| 040 | 195015-1 | 4.80 | 5.81 | |
| Brush Set CB-419 | ||||
| 040-1 | 195015-1 | 4.80 | 5.81 | |
| Carbon Brush Holder Js1300 * | ||||
| 041 | 643971-4 | 2.40 | 2.90 | |
| Cable gland 10 | ||||
| 042 | 682566-8 | 1.20 | 1.45 | |
| No information available, not orderable | ||||
| 043 | 665865-3 | |||
| No information available, not orderable | ||||
| 044 | 687052-4 | |||
| Clamp Bracket | ||||
| 044-1 | 687124-5 | 1.00 | 1.21 | |
| Tap screw 4x18 | ||||
| 045 | 265A48-7 | 1.00 | 1.21 | |
| Switch Js1300 * | ||||
| 046 | 651296-2 | 30.80 | 37.27 | |
| No information available, not orderable | ||||
| 047 | 151961-8 | |||
| Handle Cover | ||||
| 047-1 | 158710-4 | 7.20 | 8.71 | |
| No information available, not orderable | ||||
| 048 | 265999-8 | |||
| No information available, not orderable | ||||
| 049 | 265999-8 | |||
| No information available, not orderable | ||||
| 050 | 135168-4 | |||
