Here you will find all available parts and drawings of the 'Makita GA5021CY'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita GA5021CY
Spare parts list of model Makita GA5021CY
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| ZIJHANDGREEP ANTI-VIBRATIE M8 | ||||
| A01 | 194514-0 | 11.00 | 13.31 | |
| NOKKENSLEUTEL RECHT 35MM | ||||
| A02 | 782423-1 | 2.00 | 2.42 | |
| No information available, not orderable | ||||
| A03F | 806767-6 | |||
| BESCHERMKAPAFDICHTING DOORSLIJPEN 125MM | ||||
| A05 | 199710-5 | 10.00 | 12.10 | |
| BORSTEL A 191W06-8 | ||||
| C10 | 743129-6 | 15.40 | 18.63 | |
| Brush Holder | ||||
| C10 | 643751-8 | 3.60 | 4.36 | |
| Stator spring Cb5 | ||||
| C10 | 654020-2 | 1.20 | 1.45 | |
| O-ring 4 | ||||
| C10 | 213009-5 | 1.00 | 1.21 | |
| BORSTEL B 191W05-0 | ||||
| C20 | 743130-1 | 15.40 | 18.63 | |
| LABEL WAARSCH GA5090 | ||||
| C20 | 8050A1-8 | 2.40 | 2.90 | |
| Plug | ||||
| C20 | 654555-3 | 1.00 | 1.21 | |
| STOFAFZUIGKAP KOMSCHIJF 125 MM | ||||
| F01 | 191W06-8 | 32.00 | 38.72 | |
| Tap Screw 5X25 | ||||
| 001 | 266041-8 | 1.00 | 1.21 | |
| Self-tapping screw Pf 5x25 | ||||
| 001-1 | 266459-3 | 1.00 | 1.21 | |
| Lock pin cap | ||||
| 002 | 417771-6 | 1.00 | 1.21 | |
| Compression Spring 8 | ||||
| 003 | 234057-1 | 1.00 | 1.21 | |
| Gear Cover | ||||
| 004 | 318158-4 | 10.80 | 13.07 | |
| Rubber ring 26mm | ||||
| 005 | 424051-3 | 1.00 | 1.21 | |
| Nut M7 | ||||
| 006 | 264010-3 | 1.00 | 1.21 | |
| Gear 11 | ||||
| 007 | 227520-1 | 3.60 | 4.36 | |
| Ball bearing 6000ddw | ||||
| 008 | 211289-7 | 13.20 | 15.97 | |
| Ball bearing 6000ddw | ||||
| 008 | 211088-7 | 10.00 | 12.10 | |
| Ball bearing 6000ddw | ||||
| 008-1 | 211289-7 | 13.20 | 15.97 | |
| Ball bearing 6000ddw | ||||
| 008-1I | 211289-7 | 13.20 | 15.97 | |
| Washer 22 Ga5021 | ||||
| 009 | 267352-4 | 1.00 | 1.21 | |
| Lock ring R-30 | ||||
| 010 | 962107-9 | 1.00 | 1.21 | |
| Fan 70 | ||||
| 011 | 240094-5 | 2.40 | 2.90 | |
| No information available, not orderable | ||||
| 012 | 513729-4 | |||
| No information available, not orderable | ||||
| 012-1 | 513799-3 | |||
| No information available, not orderable | ||||
| 012-1I | 513799-3 | |||
| Insulation ring | ||||
| 013 | 681660-3 | 7.20 | 8.71 | |
| Washer 8 | ||||
| 014 | 267281-1 | 1.00 | 1.21 | |
| Ball Bearing 608ddw | ||||
| 015 | 210005-4 | 4.80 | 5.81 | |
| Rubber Ring | ||||
| 016 | 421720-7 | 7.20 | 8.71 | |
| Tapping Screw 4x70 | ||||
| 017 | 266325-4 | 1.00 | 1.21 | |
| Spacer plate | ||||
| 018 | 419961-7 | 1.20 | 1.45 | |
| Plug | ||||
| 019 | 654555-3 | 1.00 | 1.21 | |
| Stator spring Cb5 | ||||
| 019A | 654020-2 | 1.20 | 1.45 | |
| No information available, not orderable | ||||
| 019B | 525784-4 | |||
| Motor Housing | ||||
| 020 | 158398-0 | 12.10 | 14.64 | |
| Brush Holder | ||||
| 020A | 643751-8 | 3.60 | 4.36 | |
| Carbon brush set Cb-253 | ||||
| 021 | 194547-5 | 3.96 | 4.79 | |
| KOOLBORSTEL SET CB-253 A | ||||
| 021 | 194994-0 | 3.96 | 4.79 | |
| KOOLBORSTEL SET CB-253 A | ||||
| 021-1 | 194994-0 | 3.96 | 4.79 | |
| Carbon brush cap | ||||
| 022 | 643515-0 | 1.00 | 1.21 | |
| Nameplate "ga5021c" | ||||
| 023 | 864047-6 | 3.60 | 4.36 | |
| Set Of Handles | ||||
| 024 | 188452-6 | 13.20 | 15.97 | |
| No information available, not orderable | ||||
| 025 | 266326-2 | |||
| Tap screw 4x18 | ||||
| 025-1 | 265A48-7 | 1.00 | 1.21 | |
| Speed control circuit | ||||
| 026 | 631799-2 | 34.10 | 41.26 | |
| No information available, not orderable | ||||
| 026-1 | 620G47-6 | |||
| Socket | ||||
| 027 | 418518-1 | 1.20 | 1.45 | |
| Switch Sw-131 | ||||
| 028 | 651922-3 | 11.00 | 13.31 | |
| No information available, not orderable | ||||
| 028-1 | 650677-7 | |||
| Switch Sw-131 | ||||
| 028-2 | 651922-3 | 11.00 | 13.31 | |
| Switch Sw-131 | ||||
| 028-2I | 651922-3 | 11.00 | 13.31 | |
| Terminal block | ||||
| 029 | 654575-7 | 3.60 | 4.36 | |
| No information available, not orderable | ||||
| 030 | 266326-2 | |||
| Tap screw 4x18 | ||||
| 030-1 | 265A48-7 | 1.00 | 1.21 | |
| Clamp Bracket | ||||
| 031 | 687260-7 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 032 | 682505-8 | |||
| Power cord 2x1.00 2.2mtr | ||||
| 033 | 665383-1 | 10.80 | 13.07 | |
| Compression Spring 6x29mm | ||||
| 034 | 233117-6 | 1.00 | 1.21 | |
| Switch mounting plate | ||||
| 035 | 418519-9 | 1.20 | 1.45 | |
| Switch Button (Safety) | ||||
| 036 | 153788-2 | 6.00 | 7.26 | |
| Switch button Cpl Ga5021C A | ||||
| 036 | 158402-5 | 6.00 | 7.26 | |
| Set Of Handles | ||||
| 037 | 188452-6 | 13.20 | 15.97 | |
| O-ring 7 | ||||
| 038 | 213977-2 | 1.00 | 1.21 | |
| Collar Pin 5 | ||||
| 039 | 256505-0 | 1.00 | 1.21 | |
| Rubber Pin 4 | ||||
| 040 | 263002-9 | 1.00 | 1.21 | |
| Ball bearing 696ZZ A | ||||
| 041 | 210026-6 | 2.40 | 2.90 | |
| Locking washer 7 | ||||
| 042 | 233926-3 | 1.20 | 1.45 | |
| Washer 8 x 14 x 1mm | ||||
| 043 | 253835-0 | 1.00 | 1.21 | |
| Spring retaining ring | ||||
| 044 | 267811-8 | 2.40 | 2.90 | |
| Gear 35b | ||||
| 045 | 227522-7 | 8.40 | 10.16 | |
| Lock washer 16 | ||||
| 046 | 234356-1 | 6.00 | 7.26 | |
| Lock washer 16 | ||||
| 046-1 | 234356-1 | 6.00 | 7.26 | |
| Lock washer 16 | ||||
| 046-1I | 234356-1 | 6.00 | 7.26 | |
| Blocking Bush | ||||
| 047 | 324833-2 | 3.60 | 4.36 | |
| Screw 3x6 | ||||
| 048 | 911003-8 | 1.00 | 1.21 | |
| Bearing Lock 39 | ||||
| 049 | 285728-3 | 1.00 | 1.21 | |
| Ball bearing 6002ddw | ||||
| 050 | 211236-8 | 9.60 | 11.62 | |
| Washer 15 | ||||
| 051 | 253853-8 | 1.00 | 1.21 | |
| O-ring 48 | ||||
| 052 | 213624-5 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 053 | 318160-7 | |||
| No information available, not orderable | ||||
| 053-1 | 318299-6 | |||
| Bearing Housing | ||||
| 053-2 | 318332-4 | 6.00 | 7.26 | |
| Bearing Housing | ||||
| 053-2I | 318332-4 | 6.00 | 7.26 | |
| Screw 5X18 | ||||
| 054 | 265131-4 | 1.00 | 1.21 | |
| Intermediate Ring | ||||
| 055 | 345464-4 | 1.00 | 1.21 | |
| Spindle Ass'y | ||||
| 056 | 324789-9 | 11.00 | 13.31 | |
| No information available, not orderable | ||||
| 057 | 251391-4 | |||
| Screw 5x16 | ||||
| 057-1 | 265180-1 | 1.00 | 1.21 | |
| Screw 5x16 | ||||
| 057-1I | 265180-1 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 058 | 135108-2 | |||
| No information available, not orderable | ||||
| 058-1 | 135242-8 | |||
| No information available, not orderable | ||||
| 058-2 | 122895-2 | |||
| No longer available, no replacement | ||||
| 058-3 | 123145-8 | |||
| No longer available, no replacement | ||||
| 058-3I | 123145-8 | |||
| BESCHERMKAP 125MM AFBRAMEN EN SCHUREN | ||||
| 058-4 | 141P36-7 | 7.00 | 8.47 | |
| BINNENFLENS HAAKSE SLIJPER EN SLEUVENZAAG | ||||
| 059 | 224415-9 | 3.00 | 3.63 | |
| BINNENFLENS HAAKSE SLIJPER "SUPER" | ||||
| 059A | 192227-7 | 15.00 | 18.15 | |
| SLUITMOER HAAKSE SLIJPER | ||||
| 060 | 224554-5 | 3.00 | 3.63 | |
| No information available, not orderable | ||||
| 060-1I | 195354-9 | |||
| No information available, not orderable | ||||
| 060I | 122864-3 | |||
| Washer 10 | ||||
| 061 | 253828-7 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 062 | 819282-1 | |||
