Here you will find all available parts and drawings of the 'Makita EW3050H'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita EW3050H
Spare parts list of model Makita EW3050H
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Gearbox Housing | ||||
| 001 | 2771010261 | 375.10 | 453.87 | |
| Valve guide | ||||
| 002 | 2371420203 | 34.10 | 41.26 | |
| Valve gasket | ||||
| 003 | 2771601001 | 4.80 | 5.81 | |
| Oil Seal 25X38X7 G2800L | ||||
| 004 | 0440250200 | 10.80 | 13.07 | |
| Ball bearing 62/28 G2800L | ||||
| 005 | 0600280021 | 17.60 | 21.30 | |
| Fit bush 10 10.3X8.5X14 Eg241 * | ||||
| 006 | 2771501103 | 1.20 | 1.45 | |
| Stud G2400R | ||||
| 007 | 0105080250 | 2.40 | 2.90 | |
| Tapeind M6X980Mm G2800L | ||||
| 008 | 0105060351 | 7.20 | 8.71 | |
| Oil seal 6X10X2.5 G4300L | ||||
| 009 | 0440060020 | 6.00 | 7.26 | |
| Carterplug Eg-Series | ||||
| 010 | 0401140030 | 2.40 | 2.90 | |
| Gasket G2400-3500-550 | ||||
| 011 | 0211140020 | 1.20 | 1.45 | |
| Carter Cover Ew2050H A | ||||
| 012 | 2771100161 | 93.50 | 113.14 | |
| Oil seal 25X41X6 G2800L | ||||
| 013 | 0440250210 | 11.00 | 13.31 | |
| No information available, not orderable | ||||
| 014 | 0600250140 | |||
| No information available, not orderable | ||||
| 015 | 27745004K1 | |||
| Regulator bush G28/4300L A | ||||
| 016 | 2774190201 | 30.80 | 37.27 | |
| O-ring for oil dipstick A | ||||
| 017 | 424100-6 | 1.00 | 1.21 | |
| Oil Dipstick | ||||
| 018 | 2776360130 | 7.20 | 8.71 | |
| Flange Bolt G4300L * | ||||
| 019 | 0010408350 | 2.40 | 2.90 | |
| Cylinder Head | ||||
| 020 | 2771300111 | 176.00 | 212.96 | |
| No information available, not orderable | ||||
| 021 | 2771500143 | |||
| Flange Bolt M8X68 G4300L * | ||||
| 022 | 0110080240 | 3.60 | 4.36 | |
| Flange bolt M8X33 G4300L * | ||||
| 023 | 0110080310 | 2.40 | 2.90 | |
| Valve Cover | ||||
| 024 | 2771550301 | 34.10 | 41.26 | |
| Valve cover gasket | ||||
| 025 | 2771600113 | 3.60 | 4.36 | |
| Fit bush 10 10.3X8.5X14 Eg241 * | ||||
| 026 | 2771501103 | 1.20 | 1.45 | |
| Flange bolt G24/35/5500 | ||||
| 027 | 0110060020 | 2.40 | 2.90 | |
| No information available, not orderable | ||||
| 028 | 2779900167 | |||
| Crank Shaft | ||||
| 029 | 2772030121 | 210.10 | 254.22 | |
| Flange Nut M14 G2800L * | ||||
| 030 | 0180140020 | 2.38 | 2.88 | |
| Insert Wedge G2400-3500-1R | ||||
| 031 | 0323030010 | 3.60 | 4.36 | |
| Connecting Rod | ||||
| 032 | 2772250110 | 78.10 | 94.50 | |
| Connecting rod Ew2050H | ||||
| 032A | 2772250200 | 82.50 | 99.82 | |
| Connecting rod bolt | ||||
| 033 | 2772300103 | 3.60 | 4.36 | |
| Piston Pin | ||||
| 034 | 2772330113 | 9.60 | 11.62 | |
| Piston 67 | ||||
| 035 | 27723401J3 | 36.30 | 43.92 | |
| Piston ov.siz.0.25mm | ||||
| 035A | 27723403J3 | 39.60 | 47.92 | |
| Piston over size 0.50mm | ||||
| 035B | 27723404J3 | 39.60 | 47.92 | |
| Piston Ring | ||||
| 036 | 20A2353107 | 34.10 | 41.26 | |
| Piston ring set 0.25mm | ||||
| 036A | 2772353207 | 42.90 | 51.91 | |
| Piston Ring Set 0.50mm | ||||
| 036B | 2772353307 | 42.90 | 51.91 | |
| Lock Washer Eg241/321A | ||||
| 037 | 0565160010 | 1.20 | 1.45 | |
| No information available, not orderable | ||||
| 038 | 2773160131 | |||
| Camshaft Pin Eg241A A | ||||
| 039 | 2773510101 | 11.00 | 13.31 | |
| O-Ring 5,8X9,6 Eg241A A | ||||
| 040 | 0240060030 | 2.40 | 2.90 | |
| Pin 4mm G4300L * | ||||
| 041 | 2773860103 | 1.20 | 1.45 | |
| Freewheel Hook | ||||
| 042 | 2773640113 | 14.30 | 17.30 | |
| Locking Ring 13.8mm G4300L * | ||||
| 043 | 2773650103 | 1.20 | 1.45 | |
| No information available, not orderable | ||||
| 044 | 2773870323 | |||
| Valve spring | ||||
| 045 | 2793360103 | 3.60 | 4.36 | |
| Return spring | ||||
| 046 | 2693370103 | 6.00 | 7.26 | |
| No information available, not orderable | ||||
| 047 | 27733401H3 | |||
| No information available, not orderable | ||||
| 048 | 27733501H3 | |||
| Check valve | ||||
| 049 | 13210KA031 | 2.40 | 2.90 | |
| Camshaft chain Eg241A A | ||||
| 050 | 27735602H1 | 28.60 | 34.61 | |
| Camshaft chain | ||||
| 051 | 20A3691103 | 3.60 | 4.36 | |
| Extension Spring | ||||
| 052 | 2773710103 | 3.60 | 4.36 | |
| Pin 6x13x34mm | ||||
| 053 | 2773690203 | 3.60 | 4.36 | |
| Chain guide | ||||
| 054 | 20A3691303 | 3.60 | 4.36 | |
| Rocker arm pin | ||||
| 055 | 2773500401 | 3.60 | 4.36 | |
| Lock washer G28/4300L * | ||||
| 056 | 0031305000 | 1.00 | 1.21 | |
| Valve arm | ||||
| 057 | 2773600107 | 39.60 | 47.92 | |
| Set screw M5 G28/4300L * | ||||
| 058 | 0149050020 | 3.60 | 4.36 | |
| Set screw M5 G28/4300L * | ||||
| 059 | 0149050020 | 3.60 | 4.36 | |
| Nut M5 G28/4300L * | ||||
| 060 | 0170050030 | 1.20 | 1.45 | |
| Nut M5 G28/4300L * | ||||
| 061 | 0170050030 | 1.20 | 1.45 | |
| Flange bolt G24/35/5500 | ||||
| 062 | 0110060020 | 2.40 | 2.90 | |
| Muffler | ||||
| 063 | 27730111J1 | 68.20 | 82.52 | |
| Exhaust Cap | ||||
| 064 | 20A3420101 | 21.96 | 26.57 | |
| Exhaust Gasket | ||||
| 065 | 2773520113 | 2.40 | 2.90 | |
| No information available, not orderable | ||||
| 066 | 0023808000 | |||
| Tap Bolt Ew2050H | ||||
| 067 | 0152060090 | 1.20 | 1.45 | |
| Bolt G2400-3500-550 * | ||||
| 068 | 0110060010 | 2.40 | 2.90 | |
| Flange Bolt G4300L * | ||||
| 069 | 0110080320 | 2.40 | 2.90 | |
| Rivet | ||||
| 070 | 20A0210100 | 1.20 | 1.45 | |
| Spark arrestor | ||||
| 071 | 27737203H1 | 11.00 | 13.31 | |
| Tapschroef M4X6L G1700I | ||||
| 072 | 0150040060 | 1.00 | 1.21 | |
| Manifold | ||||
| 073 | 20A3290201 | 11.00 | 13.31 | |
| Manifold gasket "2" | ||||
| 074 | 20A3590303 | 1.20 | 1.45 | |
| Gasket 1 Manifold Eg241A A | ||||
| 075 | 20A3590203 | 1.20 | 1.45 | |
| Nut M/Rivet G28/6100R | ||||
| 076 | 0023806000 | 1.20 | 1.45 | |
| Bolt Eg241A A | ||||
| 077 | 0010406200 | 1.20 | 1.45 | |
| Vent Pipe | ||||
| 078 | 2773276008 | 14.30 | 17.30 | |
| No information available, not orderable | ||||
| 079 | 2773271530 | |||
| No information available, not orderable | ||||
| 080 | 2773263018 | |||
| Air filter gasket | ||||
| 081 | 2773261008 | 10.80 | 13.07 | |
| No longer available, no replacement | ||||
| 082 | 2773260408 | |||
| No information available, not orderable | ||||
| 083 | 2773264008 | |||
| Label | ||||
| 084 | 2773260908 | 2.40 | 2.90 | |
| Nut Wing | ||||
| 085 | 2773274118 | 4.80 | 5.81 | |
| Nut Wing | ||||
| 086 | 2773260718 | 3.60 | 4.36 | |
| Complete Element | ||||
| 087 | 20A3263600 | 48.40 | 58.56 | |
| Regulator lever | ||||
| 088 | 2774230140 | 13.20 | 15.97 | |
| Regulator shaft | ||||
| 089 | 2774220133 | 11.00 | 13.31 | |
| Regulator rod | ||||
| 090 | 2774270123 | 3.60 | 4.36 | |
| Regulator rod spring | ||||
| 091 | 2774280123 | 2.40 | 2.90 | |
| Lock washer G28/4300L * | ||||
| 092 | 0031305000 | 1.00 | 1.21 | |
| Bolt Eg241A A | ||||
| 093 | 0010406200 | 1.20 | 1.45 | |
| Nut G2400-3500-550 | ||||
| 094 | 0186060020 | 1.20 | 1.45 | |
| Regulator spring | ||||
| 095 | 2774251023 | 3.60 | 4.36 | |
| Hendel, toerenregeling- | ||||
| 096 | 2774330303 | 10.80 | 13.07 | |
| Stop Plate | ||||
| 097 | 2774350203 | 4.80 | 5.81 | |
| Rivet | ||||
| 098 | 2774450103 | 1.20 | 1.45 | |
| Friction ring Ew2050H | ||||
| 099 | 0217060070 | 1.20 | 1.45 | |
| Screw Ew2050H | ||||
| 100 | 0043106250 | 1.00 | 1.21 | |
| Veer tbv stang | ||||
| 101 | 2374500423 | 1.20 | 1.45 | |
| Frame Support | ||||
| 102 | 2774600202 | 11.00 | 13.31 | |
| Borgmoer Eg601A | ||||
| 103 | 0023506000 | 2.40 | 2.90 | |
| Flange bolt G24/35/5500 | ||||
| 104 | 0110060020 | 2.40 | 2.90 | |
| Flywheel Housing | ||||
| 105 | 2775120501 | 56.10 | 67.88 | |
| Label Makita | ||||
| 106 | 2779170503 | 8.40 | 10.16 | |
| Bolt M6X1.0X14Dx14L | ||||
| 107 | 0110060030 | 2.40 | 2.90 | |
| Intermediate Plate | ||||
| 108 | 20A5271101 | 8.40 | 10.16 | |
| Intermediate Plate | ||||
| 109 | 2775270203 | 19.80 | 23.96 | |
| Flange Bolt Eg241A A | ||||
| 110 | 0010406140 | 1.00 | 1.21 | |
| Flange bolt G24/35/5500 | ||||
| 111 | 0110060020 | 2.40 | 2.90 | |
| Fan | ||||
| 112 | 20A5410113 | 14.30 | 17.30 | |
| Bolt M6X1.0X14Dx14L | ||||
| 113 | 0110060030 | 2.40 | 2.90 | |
| Startinrichting | ||||
| 114 | 20A5020130 | 88.00 | 106.48 | |
| FUEL TANK | ||||
| 115 | 2776010511 | 118.80 | 143.75 | |
| Label (Warning) Eg601A A | ||||
| 116 | 0732005760 | 3.60 | 4.36 | |
| Label | ||||
| 117 | 2779511603 | 6.00 | 7.26 | |
| No information available, not orderable | ||||
| 118 | 0430440143 | |||
| No information available, not orderable | ||||
| 119 | X641360010 | |||
| Feed nozzle | ||||
| 120 | X505120020 | 6.00 | 7.26 | |
| Nut M/Rivet G28/6100R | ||||
| 121 | 0023806000 | 1.20 | 1.45 | |
| Bolt M/Rivet G2800R | ||||
| 122 | 0110060130 | 2.40 | 2.90 | |
| No information available, not orderable | ||||
| 123 | 2776260121 | |||
| No information available, not orderable | ||||
| 124 | X851061352 | |||
| No information available, not orderable | ||||
| 125 | X561110060 | |||
| Choke-slide | ||||
| 126 | 2774380101 | 8.40 | 10.16 | |
| No information available, not orderable | ||||
| 127 | 2776230250 | |||
| Throttle valve | ||||
| 128 | 2776253508 | 16.50 | 19.96 | |
| Screw | ||||
| 129 | 2096235108 | 1.20 | 1.45 | |
| Choke Valve | ||||
| 130 | 2776252508 | 11.00 | 13.31 | |
| Gas needle | ||||
| 131 | 2466242008 | 13.20 | 15.97 | |
| Choke Handle | ||||
| 132 | 2776252008 | 19.80 | 23.96 | |
| Gas Rod | ||||
| 133 | 2776253118 | 34.10 | 41.26 | |
| Bolt G2400R * | ||||
| 134 | 2276245108 | 10.80 | 13.07 | |
| Pointer | ||||
| 135 | 2776250008 | 34.10 | 41.26 | |
| Pin | ||||
| 136 | 2776251508 | 3.60 | 4.36 | |
| Float chamber | ||||
| 137 | 2776250608 | 39.60 | 47.92 | |
| Gasket | ||||
| 138 | 2146245008 | 1.20 | 1.45 | |
| Gasket | ||||
| 139 | 2146254008 | 6.00 | 7.26 | |
| Float | ||||
| 140 | 2266250608 | 34.10 | 41.26 | |
| Main jet | ||||
| 141 | 2776244008 | 26.40 | 31.94 | |
| Main jet | ||||
| 142 | 2266241208 | 16.50 | 19.96 | |
| Clip | ||||
| 143 | 2266270118 | 4.80 | 5.81 | |
| Bolt | ||||
| 144 | 2776236008 | 8.40 | 10.16 | |
| Screw | ||||
| 145 | 1066255608 | 2.40 | 2.90 | |
| Spring | ||||
| 146 | 2836235708 | 7.20 | 8.71 | |
| Air Nozzle | ||||
| 147 | 2486241008 | 16.50 | 19.96 | |
| Air nozzle (inlet) | ||||
| 148 | 1066241008 | 16.50 | 19.96 | |
| Seal | ||||
| 149 | 2366268008 | 6.00 | 7.26 | |
| Gasket | ||||
| 150 | 2366254108 | 6.00 | 7.26 | |
| Gasket | ||||
| 151 | 2466239008 | 3.60 | 4.36 | |
| Nut | ||||
| 152 | 2776255308 | 7.20 | 8.71 | |
| No information available, not orderable | ||||
| 153 | 2796210320 | |||
| Gasket | ||||
| 154 | 2776211018 | 3.60 | 4.36 | |
| Gasoline sight glass | ||||
| 155 | 2776210018 | 6.00 | 7.26 | |
| O-ring | ||||
| 156 | 2776255208 | 6.00 | 7.26 | |
| No information available, not orderable | ||||
| 157 | 1656237708 | |||
| Magneto Rotor Comp. | ||||
| 158 | 20A7923101 | 132.00 | 159.72 | |
| Ignition | ||||
| 159 | 20A7943101 | 78.10 | 94.50 | |
| Bolt Eg241A A | ||||
| 160 | 0010406200 | 1.20 | 1.45 | |
| Stop cable | ||||
| 161 | 27773102H1 | 7.20 | 8.71 | |
| Switch | ||||
| 162 | X660000510 | 10.50 | 12.70 | |
| No information available, not orderable | ||||
| 163 | 0150040090 | |||
| Spark Plug | ||||
| 164 | X650143050 | 9.60 | 11.62 | |
| Spark plug cap G2400-3500-550 * | ||||
| 165 | 0655000110 | 17.60 | 21.30 | |
| Pump Housing | ||||
| 166 | 4800801001 | 210.10 | 254.22 | |
| Inner house gasket | ||||
| 167 | 4800801012 | 9.60 | 11.62 | |
| Inner Housing | ||||
| 168 | 4800801011 | 127.60 | 154.40 | |
| Fan | ||||
| 169 | 4800801009 | 52.80 | 63.89 | |
| Mechanical seal | ||||
| 170 | 4800501010 | 52.80 | 63.89 | |
| Pump housing gasket | ||||
| 171 | 4800501002 | 13.20 | 15.97 | |
| Stop | ||||
| 172 | 4800501021 | 6.00 | 7.26 | |
| O-ring | ||||
| 173 | 4800501022 | 2.40 | 2.90 | |
| Bolt with washer | ||||
| 174 | 4800531003 | 1.20 | 1.45 | |
| Pump housing cap | ||||
| 175 | 4800501004 | 117.70 | 142.42 | |
| Bolt M8x48mm | ||||
| 176 | 4800501005 | 2.40 | 2.90 | |
| Suction flange | ||||
| 177 | 4800801013 | 69.30 | 83.85 | |
| Bolt with ring M8x30mm | ||||
| 178 | 4800801014 | 3.60 | 4.36 | |
| Valve | ||||
| 179 | 4800801015 | 30.80 | 37.27 | |
| Washer | ||||
| 180 | 4800801017 | 4.80 | 5.81 | |
| Hose connector | ||||
| 181 | 4810000108 | 13.20 | 15.97 | |
| Swivel for socket | ||||
| 182 | 4800801016 | 47.30 | 57.23 | |
| Feed flange | ||||
| 183 | 4800801019 | 100.10 | 121.12 | |
| Bolt with washer | ||||
| 184 | 4810000170 | 2.40 | 2.90 | |
| Gasket for feed flange | ||||
| 185 | 4800801020 | 6.00 | 7.26 | |
| Stop | ||||
| 186 | 4800501021 | 6.00 | 7.26 | |
| O-ring | ||||
| 187 | 4800501022 | 2.40 | 2.90 | |
| Sieve "suction head" | ||||
| 188 | 4800805029 | 45.10 | 54.57 | |
| Hose clamp IAS 3 | ||||
| 189 | 4800801028 | 4.80 | 5.81 | |
| Frame | ||||
| 190 | 4810000250 | 184.80 | 223.61 | |
| Bolt with ring M8x40mm | ||||
| 191 | 4800501023 | 2.40 | 2.90 | |
| Flange Nut M8 | ||||
| 192 | 4800501024 | 1.20 | 1.45 | |
| Label | ||||
| 193 | 4879000103 | 6.00 | 7.26 | |
| Spark Screen | ||||
| 197 | 2773760101 | 26.40 | 31.94 | |
| Tapschroef M4X6L G1700I | ||||
| 198 | 0150040060 | 1.00 | 1.21 | |
| Oil Sensor | ||||
| 199 | 2777630121 | 42.90 | 51.91 | |
| O-ring | ||||
| 200 | 2777635008 | 8.40 | 10.16 | |
| Float | ||||
| 201 | KU31104321 | 52.80 | 63.89 | |
| No information available, not orderable | ||||
| 202 | 2777580103 | |||
| Flange Bolt Eg241A A | ||||
| 203 | 0010406140 | 1.00 | 1.21 | |
| Tapschroef G2400-3500-550 | ||||
| 204 | 0152050010 | 1.20 | 1.45 | |
| Label, Waarschuwings- | ||||
| 205 | 0732005860 | 3.60 | 4.36 | |
