Here you will find all available parts and drawings of the 'Makita DTD155'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita DTD155
Spare parts list of model Makita DTD155
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Motor Housing Set | ||||
| 001 | 183G71-5 | 14.30 | 17.30 | |
| Lock Nut M4x7mm | ||||
| 001C10 | 252126-6 | 1.00 | 1.21 | |
| Nameplate Dtd155 | ||||
| 002 | 853G07-5 | 3.60 | 4.36 | |
| Tapping Screw 3x16 | ||||
| 003 | 266130-9 | 1.00 | 1.21 | |
| Rotary knob ABB OHYS2AJ | ||||
| 004 | 455053-8 | 1.00 | 1.21 | |
| Complete Switch | ||||
| 005 | 143975-1 | 17.60 | 21.30 | |
| Armature | ||||
| 006 | 619415-6 | 26.40 | 31.94 | |
| Field | ||||
| 007 | 629233-4 | 11.00 | 13.31 | |
| LED Circuit | ||||
| 008 | 620521-2 | 6.00 | 7.26 | |
| Connection unit Bcl182D(3 Cont) A | ||||
| 009 | 643523-1 | 6.00 | 7.26 | |
| Spring Washer 10 | ||||
| 010 | 231965-7 | 1.00 | 1.21 | |
| Flat washer | ||||
| 011 | 267143-3 | 1.20 | 1.45 | |
| Compression Spring 13 | ||||
| 012 | 233005-7 | 1.00 | 1.21 | |
| Bit Holder | ||||
| 013 | 326803-7 | 2.40 | 2.90 | |
| Leg | ||||
| 014 | 424914-3 | 1.20 | 1.45 | |
| Gear Cover | ||||
| 016 | 144132-4 | 9.60 | 11.62 | |
| Nylon washer 19mm | ||||
| 017 | 261159-0 | 1.00 | 1.21 | |
| Steel ball 4.8 | ||||
| 018 | 216002-8 | 1.00 | 1.21 | |
| Anvil Td0100 A | ||||
| 019 | 326630-2 | 6.00 | 7.26 | |
| Striker | ||||
| 020 | 324894-2 | 8.40 | 10.16 | |
| Steel ball 3 | ||||
| 021 | 216019-1 | 1.00 | 1.21 | |
| Rivet 20mm | ||||
| 022 | 267380-9 | 1.00 | 1.21 | |
| Pressure Spring 21 | ||||
| 023 | 232326-4 | 1.00 | 1.21 | |
| Rivet 21mm | ||||
| 024 | 267813-4 | 1.00 | 1.21 | |
| Steel ball 3 | ||||
| 025 | 216019-1 | 1.00 | 1.21 | |
| Gear 17 | ||||
| 026 | 221437-0 | 4.80 | 5.81 | |
| Spindle Ass'y | ||||
| 027 | 324897-6 | 6.00 | 7.26 | |
| Pen 3,5mm | ||||
| 028 | 268217-3 | 1.00 | 1.21 | |
| Washer 12 | ||||
| 029 | 253052-2 | 1.00 | 1.21 | |
| Gear 43 | ||||
| 030 | 227316-0 | 3.60 | 4.36 | |
| O-ring 33 | ||||
| 032 | 213479-8 | 1.00 | 1.21 | |
| Bearing Housing | ||||
| 033 | 141893-7 | 6.00 | 7.26 | |
| Motor Housing Set | ||||
| 035 | 183G71-5 | 14.30 | 17.30 | |
| Lock Nut M4x7mm | ||||
| 035 | 252126-6 | 1.00 | 1.21 | |
| Shift Plate | ||||
| 036 | 144137-4 | 2.40 | 2.90 | |
| Parker Ck 2x6mm | ||||
| 039 | 266490-9 | 1.00 | 1.21 | |
| Controller | ||||
| 041 | 620586-4 | 63.80 | 77.20 | |
