Here you will find all available parts and drawings of the 'Makita DHR243'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Makita DHR243

Spare parts list of model Makita DHR243

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
Boorkop SDS-PLUS
001 194080-7 45.00 54.45
Nut Bolt M8x90mm
011 266745-2 0.83 1.00
Handle Bracket
012 453129-5 2.71 3.28
Handle
013 158057-6 9.24 11.18
Screw 4x35
014 266351-3 0.83 1.00
Gearbox Bhr242 A
015 144354-6 7.22 8.74
Seal ring 25
015A 213345-9 1.39 1.68
Socket
016 331890-3 2.71 3.28
Ball Bearing 6806llu
017 211294-4 8.21 9.93
Locking Button
018 454112-5 1.18 1.43
Compression Spring 3x28mm
019 234264-6 0.83 1.00
Switch lever cap
020 453131-8 1.18 1.43
Shift lever
021 453125-3 2.71 3.28
O-ring 21
022 213381-5 3.12 3.78
Thin Lock Washer 6
023 253308-3 0.83 1.00
Compression Spring 5
024 234147-0 0.83 1.00
Push Pin
025 326850-8 0.83 1.00
Compression Spring 4
026 233360-7 0.83 1.00
Blocking Plate
027 346537-6 1.18 1.43
Steel ball 3
029 216019-1 0.83 1.00
Chisel holder
030 140266-1 23.06 27.90
Seal ring 9
030A 213344-1 3.96 4.79
No longer available, no replacement
031 332139-4
No longer available, no replacement
032 227360-7
Pin 6
033 268226-2 1.26 1.52
Washer 30
034 267414-8 0.83 1.00
Compression spring 31mm
035 234148-8 1.18 1.43
Washer 30
036 267153-0 0.83 1.00
Lock ring spiro30
037 257932-4 3.12 3.78
Washer 30
038 267153-0 0.83 1.00
Bushing 9b
039 325783-4 0.98 1.19
Slagstuk "b"
040 325791-5 1.67 2.02
Ring 10
041 325792-3 1.18 1.43
Compression Spring 20
042 234149-6 0.98 1.19
O-ring huis "b"
043 325793-1 2.71 3.28
O-ring 9
044 213073-6 0.83 1.00
Spring washer 28
045 233979-2 0.83 1.00
Jackhammer
046 326139-4 3.54 4.28
O-ring 17.5
047 213258-4 2.02 2.44
Piston-cylinder
048 310345-1 8.21 9.93
Guide plate
049 346036-8 0.83 1.00
Piston Pin Hr2440/50 A
050 324215-8 2.02 2.44
Compression Spring 14
051 234098-7 0.83 1.00
Sluitring 14mm
052 267447-3 0.83 1.00
Ball bearing 606Zz A
053 210137-7 0.98 1.19
Stopring Ext-u6
054 257336-0 0.83 1.00
Washer 7 LF1000 A
055 267322-3 0.83 1.00
Gear 10
056 227231-8 25.36 30.69
Clutch Plate A
057 326849-3 4.45 5.38
Clutch
058 326140-9 5.06 6.12
Pendulum Bearing 10
059 219020-5 28.02 33.90
Gear 11
060 227588-7 5.71 6.91
Washer 8
061 257323-9 0.83 1.00
Allen bolt m4x12
062 922118-6 0.83 1.00
Bearing Lock B
063 346038-4 0.83 1.00
Ball Bearing 608Zz A
064 210046-0 0.83 1.00
Washer 8
065 324212-4 4.45 5.38
Hexagon Socket Screw M4X25
066 922147-9 0.83 1.00
Locking Block
067 141230-5 3.12 3.78
O-ring 75
068 213767-3 0.98 1.19
Inner Housing
069 318810-4 15.60 18.88
Damping felt
070 443153-6 0.83 1.00
Allen bolt m4x12
071 922118-6 0.83 1.00
Bearing Lock A
072 346536-8 1.18 1.43
Flat head pin 6mm .
073 256536-9 0.98 1.19
Weight Holder
074 346538-4 0.83 1.00
Counterweight
075 313224-2 3.28 3.97
Weight Holder
076 346538-4 0.83 1.00
Washer 6
077 253726-5 0.83 1.00
Retaining Ring E-5
078 961018-5 0.83 1.00
O-ring 22.4
079 213008-7 0.98 1.19
Gear 11
080 141458-5 5.06 6.12
Ball bearing 608 2rs
081 210024-0 3.12 3.78
Washer 8 x 14 x 1mm
082 253835-0 0.83 1.00
Armature A
083 619737-4 36.87 44.61
Ball bearing 626zz
084 210143-2 2.71 3.28
Field
085 529187-4 33.36 40.37
Speed control circuit
086 620G68-8 112.06 135.59
Speed control circuit
086-1 620G68-8 112.06 135.59
Motor Housing Set Bhr242 A
087 183C02-0 17.38 21.03
Serial number label Dhr243
088 815B50-2 2.71 3.28
Nameplate Dhr243
089 815B44-7 2.71 3.28
No information available, not orderable
090 266326-2
Motor Housing Set Bhr242 A
091 183C02-0 17.38 21.03
L+r switch lever
092 453124-5 0.83 1.00
Switch handle
093 453123-7 0.83 1.00
Switch c3jw-1p
094 650709-0 13.82 16.72
Torsion spring 6mm
095 233598-4 0.83 1.00
Blocking handle
096 313226-8 0.83 1.00
Connection unit (3 contacts)
097 644808-8 3.54 4.28
Damping felt
098 424476-1 0.83 1.00
Battery Housing
099 187377-1 5.71 6.91
Rubber pen 6
099A 263005-3 0.83 1.00
Rubber pen 5
100 263036-2 1.18 1.43
Pin 1.5
101 268184-2 0.83 1.00
Damping Rubber
102 424473-7 1.39 1.68
Damping Rubber
103 424473-7 1.39 1.68
Battery Housing
104 187377-1 5.71 6.91
Rubber pen 6
104A 263005-3 0.83 1.00
Rubber dust cap 35
105 286263-4 0.98 1.19
Lock washer 19
106 233940-9 0.98 1.19
Chisel lock cap
107 418217-5 1.66 2.01
End stop
108 345333-9 1.00 1.21
Steel ball 7.0
109 216022-2 0.83 1.00
Guide Ring
110 345187-4 0.83 1.00
Compression Spring 21-29
111 233916-6 0.83 1.00
Washer 21
112 267279-8 0.83 1.00
No information available, not orderable
113 324355-2
Steel ball 6
114 216030-3 0.83 1.00
Torsion Spring 31
115 231669-1 0.83 1.00
Exchange Washer
116 345334-7 1.39 1.68
Locking cap
117 418218-3 0.98 1.19
Steel ball 5.0
118 216018-3 0.83 1.00
Leaf Spring
119 345335-5 0.83 1.00
Washer 24
120 267270-6 0.83 1.00
Locking washer 21
121 233924-7 0.83 1.00
No information available, not orderable
122 893072-0
No information available, not orderable
123 890994-5
