Here you will find all available parts and drawings of the 'Makita BHP343'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita BHP343
Spare parts list of model Makita BHP343
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| High/low speed slide | ||||
| 001 | 125310-5 | 0.98 | 1.19 | |
| Compression Spring 4 | ||||
| 001A | 231433-0 | 0.83 | 1.00 | |
| Housing for 2 contacts | ||||
| 002A | 188616-2 | 14.48 | 17.52 | |
| Housing 3 contacts | ||||
| 002B | 187929-8 | 11.82 | 14.30 | |
| Nameplate "bdf453" | ||||
| 003 | 865437-6 | 2.71 | 3.28 | |
| Rubber pen 6 | ||||
| 003A | 263005-3 | 0.83 | 1.00 | |
| Tapping Screw 3x16 | ||||
| 004 | 266130-9 | 0.83 | 1.00 | |
| Leaf Spring | ||||
| 005 | 232182-2 | 0.83 | 1.00 | |
| L/r slide | ||||
| 006 | 419250-0 | 0.83 | 1.00 | |
| Switch | ||||
| 007A | 650662-0 | 17.38 | 21.03 | |
| Switch | ||||
| 007B | 632A24-0 | 28.02 | 33.90 | |
| Connection Unit (2 contacts) | ||||
| 008A | 643828-9 | 4.45 | 5.38 | |
| Connection unit (3 contacts) | ||||
| 008B | 643854-8 | 3.12 | 3.78 | |
| Drill Chuck Screw M6x22mm Li | ||||
| 009 | 251468-5 | 0.83 | 1.00 | |
| Boorkop snelspan 1-10mm | ||||
| 010 | 763229-6 | 13.00 | 15.73 | |
| Gear set (white locking plate) | ||||
| 011A | 125484-2 | 32.15 | 38.90 | |
| Gear set (black lock plate) | ||||
| 011B | 126001-1 | 33.36 | 40.37 | |
| No information available, not orderable | ||||
| 012A | 629823-3 | |||
| Motor 14.4v (black locking plate) | ||||
| 012B | 629900-1 | 11.82 | 14.30 | |
| Screw 3x6 | ||||
| 013 | 911003-8 | 0.83 | 1.00 | |
| Housing for 2 contacts | ||||
| 014A | 188616-2 | 14.48 | 17.52 | |
| Rubber pen 6 | ||||
| 014AA | 263005-3 | 0.83 | 1.00 | |
| Housing 3 contacts | ||||
| 014B | 187929-8 | 11.82 | 14.30 | |
| Damping felt | ||||
| 015 | 424476-1 | 0.83 | 1.00 | |
