Here you will find all available parts and drawings of the 'Makita BFR540ZJ'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita BFR540ZJ
Spare parts list of model Makita BFR540ZJ
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Nose cap | ||||
| 001 | 424043-2 | 2.02 | 2.44 | |
| Stop base | ||||
| 002 | 345839-7 | 8.21 | 9.93 | |
| Guide Block | ||||
| 003 | 140493-0 | 13.82 | 16.72 | |
| Shield | ||||
| 004 | 346269-5 | 2.02 | 2.44 | |
| Lever | ||||
| 005 | 345837-1 | 0.83 | 1.00 | |
| Pressure Spring 2 | ||||
| 006 | 233211-4 | 0.83 | 1.00 | |
| Pin 6 | ||||
| 007 | 256451-7 | 1.24 | 1.50 | |
| Feeder house | ||||
| 008 | 450107-6 | 3.96 | 4.79 | |
| Bus 5 6833/34/35/37 Grs A | ||||
| 009 | 257685-5 | 2.71 | 3.28 | |
| Stopper 6833 | ||||
| 010 | 310062-3 | 5.06 | 6.12 | |
| Torsion spring 4 | ||||
| 011 | 231636-6 | 0.83 | 1.00 | |
| Pen 3 | ||||
| 012 | 256158-5 | 0.83 | 1.00 | |
| Gear 16 | ||||
| 013 | 226344-2 | 1.39 | 1.68 | |
| Pawl gear 6842 | ||||
| 014 | 158374-4 | 16.35 | 19.78 | |
| Compression Spring 6 | ||||
| 015 | 233212-2 | 0.83 | 1.00 | |
| Feed Housing Lid | ||||
| 016 | 158375-2 | 8.21 | 9.93 | |
| Tap screw 4x18 | ||||
| 017 | 265A48-7 | 0.83 | 1.00 | |
| Dust-Protection Cover | ||||
| 018 | 162201-9 | 3.97 | 4.80 | |
| Feed wheel | ||||
| 019 | 416518-5 | 2.71 | 3.28 | |
| Bow | ||||
| 020 | 345838-9 | 3.12 | 3.78 | |
| Lock Lever | ||||
| 021 | 450111-5 | 1.18 | 1.43 | |
| Adjusting Screw | ||||
| 022 | 265177-0 | 2.02 | 2.44 | |
| Socket | ||||
| 023 | 257764-9 | 1.67 | 2.02 | |
| Compression Spring 23 Bfr540 | ||||
| 024 | 234031-9 | 1.67 | 2.02 | |
| Screw housing cap | ||||
| 025 | 450114-9 | 1.39 | 1.68 | |
| Screw Housing | ||||
| 026 | 158377-8 | 30.70 | 37.15 | |
| Label "bfr540" nose piece | ||||
| 026A | 816885-2 | 2.84 | 3.44 | |
| Adjusting pin | ||||
| 027 | 310237-4 | 4.67 | 5.65 | |
| Insulation sleeve | ||||
| 028 | 450110-7 | 1.67 | 2.02 | |
| Circlip | ||||
| 029 | 318181-9 | 9.24 | 11.18 | |
| Button 42mm | ||||
| 030 | 417056-0 | 1.39 | 1.68 | |
| O-ring 12 | ||||
| 031 | 213107-5 | 0.83 | 1.00 | |
| Washer 6 6835D | ||||
| 032 | 267201-5 | 1.02 | 1.23 | |
| Countersunk screw 4x12 | ||||
| 033 | 912117-6 | 0.83 | 1.00 | |
| Steel ball 3.5 | ||||
| 034 | 216040-0 | 0.83 | 1.00 | |
| Countersunk screw 4x12 | ||||
| 035 | 912117-6 | 0.83 | 1.00 | |
| Screw 4x28 | ||||
| 036 | 265779-2 | 1.39 | 1.68 | |
| Complete nose piece 55 | ||||
| 037 | 195184-8 | 146.44 | 177.19 | |
| Screwdriver Set | ||||
| 041 | 188309-1 | 6.38 | 7.72 | |
| Tap screw 4x18 | ||||
| 042 | 265A48-7 | 0.83 | 1.00 | |
| No information available, not orderable | ||||
| 043A | 188556-4 | |||
| Motor Housing (3 contacts) | ||||
| 043B | 187475-1 | 29.35 | 35.51 | |
| Label | ||||
| 044 | 863788-1 | 2.84 | 3.44 | |
| Tap screw 4x18 | ||||
| 045 | 265A48-7 | 0.83 | 1.00 | |
| Dust Ring | ||||
| 046 | 421467-3 | 0.98 | 1.19 | |
| Slide bearing 14 | ||||
| 047 | 214173-5 | 4.45 | 5.38 | |
| O-ring 18 | ||||
| 048 | 213262-3 | 0.98 | 1.19 | |
| Steel ball 3.5 | ||||
| 049 | 216040-0 | 0.83 | 1.00 | |
| As 6842 | ||||
| 050 | 324808-1 | 21.08 | 25.51 | |
| Washer | ||||
| 052 | 421927-5 | 0.83 | 1.00 | |
| Washer 25 | ||||
| 054 | 267331-2 | 0.98 | 1.19 | |
| Washer 25 | ||||
| 055 | 267331-2 | 0.98 | 1.19 | |
| Compression Spring 25 | ||||
| 056 | 234017-3 | 2.36 | 2.86 | |
| Clutch Plate C Bfr540 | ||||
| 057 | 223169-5 | 15.60 | 18.88 | |
| Steel ball 4 | ||||
| 058 | 216008-6 | 0.83 | 1.00 | |
| Gear | ||||
| 059 | 226670-9 | 25.36 | 30.69 | |
| Ball Bearing | ||||
| 060 | 211034-0 | 3.72 | 4.50 | |
| Sleeve 10 | ||||
| 061 | 165115-1 | 2.48 | 3.00 | |
| Slide Bearing 5 | ||||
| 062 | 214017-9 | 0.83 | 1.00 | |
| Lock washer 5 | ||||
| 063 | 253811-4 | 0.83 | 1.00 | |
| Gear | ||||
| 064 | 154937-4 | 25.36 | 30.69 | |
| Slide Bearing 5 | ||||
| 065 | 214017-9 | 0.83 | 1.00 | |
| O-ring 10 | ||||
| 066 | 213055-8 | 0.83 | 1.00 | |
| L/r adjusting lever | ||||
| 067 | 419304-3 | 1.67 | 2.02 | |
| Switch Bfr540/50 (2 Cont.) | ||||
| 068A | 650575-5 | 15.60 | 18.88 | |
| Switch (3 contacts) | ||||
| 068B | 650670-1 | 13.82 | 16.72 | |
| Connection Unit (2 contacts) | ||||
| 069A | 643847-5 | 3.54 | 4.28 | |
| Connection unit (3 contacts) | ||||
| 069B | 643850-6 | 4.45 | 5.38 | |
| Magnet Unit | ||||
| 071 | 638426-2 | 23.06 | 27.90 | |
| Armature | ||||
| 074 | 619180-7 | 33.36 | 40.37 | |
| Brush set Cb448 | ||||
| 076 | 196855-0 | 3.54 | 4.28 | |
| Brush Holder | ||||
| 077 | 638433-5 | 3.12 | 3.78 | |
| Torsion spring 'r' | ||||
| 077A | 231696-8 | 0.83 | 1.00 | |
| Torsion spring 'l' | ||||
| 077B | 231697-6 | 0.83 | 1.00 | |
| Rubber Pin 4 | ||||
| 078 | 263032-0 | 0.83 | 1.00 | |
| Motor Hood | ||||
| 079 | 419307-7 | 5.06 | 6.12 | |
| Tap screw 4x18 | ||||
| 080 | 265A48-7 | 0.83 | 1.00 | |
| Screwdriver Set | ||||
| 082 | 188309-1 | 6.38 | 7.72 | |
| No information available, not orderable | ||||
| 083A | 188556-4 | |||
| Motor Housing (3 contacts) | ||||
| 083B | 187475-1 | 29.35 | 35.51 | |
| Washer 26 | ||||
| 084 | 267332-0 | 0.83 | 1.00 | |
| Tap screw 4x18 | ||||
| 088 | 265A48-7 | 0.83 | 1.00 | |
| Screw tape guide | ||||
| 089 | 188310-6 | 5.71 | 6.91 | |
| Screw tape guide | ||||
| 090 | 188310-6 | 5.71 | 6.91 | |
| No information available, not orderable | ||||
| 091A | 233516-2 | |||
| Torsion Spring | ||||
| 091B | 233567-5 | 0.83 | 1.00 | |
| Pen 2 | ||||
| 092 | 268188-4 | 0.83 | 1.00 | |
| Guide | ||||
| 093 | 310236-6 | 2.71 | 3.28 | |
