Here you will find all available parts and drawings of the 'Makita 9505BH'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita 9505BH
Spare parts list of model Makita 9505BH
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Screw 4x20 | ||||
| 001 | 911138-5 | 1.00 | 1.21 | |
| Gear Cover | ||||
| 002 | 157393-7 | 38.50 | 46.58 | |
| Gear 11 | ||||
| 003 | 221357-8 | 11.00 | 13.31 | |
| Ball bearing 6000ddw | ||||
| 004 | 211088-7 | 10.00 | 12.10 | |
| Ball bearing 6000DDW A | ||||
| 004 | 210315-9 | 6.00 | 7.26 | |
| Intermediate plate 9503Bh-N9503Bh * | ||||
| 005 | 341398-9 | 2.40 | 2.90 | |
| Fan 60 * | ||||
| 006 | 241509-5 | 2.40 | 2.90 | |
| Armature | ||||
| 007 | 511908-8 | 52.80 | 63.89 | |
| Screw M4X70 * | ||||
| 008 | 911596-5 | 1.20 | 1.45 | |
| Insulation ring | ||||
| 009 | 681614-0 | 1.00 | 1.21 | |
| Ball bearing 627llb | ||||
| 010 | 210025-8 | 3.60 | 4.36 | |
| Field | ||||
| 011 | 593138-3 | 29.70 | 35.94 | |
| Green Motor House N9501Bh-3Bh * | ||||
| 012 | 159283-0 | 18.70 | 22.63 | |
| Rubber Pin 4 | ||||
| 013 | 263002-9 | 1.00 | 1.21 | |
| Cross-head screw 4x70 | ||||
| 016 | 911198-7 | 1.00 | 1.21 | |
| Power cord 2x1.00 2.2mtr | ||||
| 017 | 665383-1 | 10.80 | 13.07 | |
| Rear cover 9503Bh-N9503Bh | ||||
| 018 | 410190-5 | 4.80 | 5.81 | |
| Capacitor | ||||
| 019 | 645173-8 | 8.40 | 10.16 | |
| Cable grommet 8-85 | ||||
| 020 | 682502-4 | 2.40 | 2.90 | |
| Screw 4X10 | ||||
| 021 | 911111-5 | 1.00 | 1.21 | |
| Switch Sw-03 | ||||
| 022 | 651651-8 | 10.80 | 13.07 | |
| Screw 4X18 | ||||
| 023 | 911133-5 | 1.00 | 1.21 | |
| Switch holder 9503/N9503B * | ||||
| 024 | 410191-3 | 3.60 | 4.36 | |
| Clamp Bracket | ||||
| 025 | 687001-1 | 1.00 | 1.21 | |
| Screw 4x16 A | ||||
| 026 | 911526-6 | 1.00 | 1.21 | |
| Locking plate 9501Bhk * | ||||
| 027 | 687637-6 | 1.00 | 1.21 | |
| Brush holder cap | ||||
| 030 | 643550-8 | 1.20 | 1.45 | |
| Brush Set CB411 RT0702C | ||||
| 031 | 195010-1 | 4.80 | 5.81 | |
| No longer available, no replacement | ||||
| 032 | 414659-1 | |||
| Inlegspie 3 | ||||
| 033 | 254002-0 | 1.00 | 1.21 | |
| Lock washer S-12 | ||||
| 034 | 961052-5 | 1.00 | 1.21 | |
| Gear 36 | ||||
| 035 | 221356-0 | 16.50 | 19.96 | |
| Lock washer r-32 | ||||
| 036 | 962151-6 | 1.00 | 1.21 | |
| Ball Bearing 6201llb | ||||
| 037 | 211106-1 | 6.00 | 7.26 | |
| Washer 12 * | ||||
| 038 | 253055-6 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 039 | 321815-5 | |||
| No information available, not orderable | ||||
| 040 | 443034-4 | |||
| No information available, not orderable | ||||
| 041 | 312998-2 | |||
| Screw 4x14 | ||||
| 042 | 911121-2 | 1.00 | 1.21 | |
| Screw 5x16 | ||||
| 043 | 251259-4 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 044 | 134440-1 | |||
| BINNENFLENS HAAKSE SLIJPER EN SLEUVENZAAG | ||||
| 045 | 224415-9 | 3.00 | 3.63 | |
| SLUITMOER HAAKSE SLIJPER | ||||
| 046 | 224554-5 | 3.00 | 3.63 | |
