Here you will find all available parts and drawings of the 'Makita 9402'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita 9402
Spare parts list of model Makita 9402
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Belt pulley 6-24l | ||||
| 001 | 222012-5 | 7.20 | 8.71 | |
| Belt pulley 6-24l | ||||
| 001-1 | 222012-5 | 7.20 | 8.71 | |
| No information available, not orderable | ||||
| 002 | 157148-0 | |||
| No information available, not orderable | ||||
| 002-1 | 157148-0 | |||
| Carbon Brush Set Cb-153 | ||||
| 003 | 194985-1 | 4.80 | 5.81 | |
| Carbon Brush Set Cb-153 | ||||
| 003-1 | 194985-1 | 4.80 | 5.81 | |
| Brush holder cap | ||||
| 004 | 643650-4 | 1.20 | 1.45 | |
| Brush holder cap | ||||
| 004-1 | 643650-4 | 1.20 | 1.45 | |
| Rivet 0,5 | ||||
| 005 | 953106-2 | 1.00 | 1.21 | |
| Label | ||||
| 006-1 | 850176-1 | 3.60 | 4.36 | |
| Field | ||||
| 007 | 524723-1 | 55.40 | 67.03 | |
| Field | ||||
| 007C | 524723-1 | 55.40 | 67.03 | |
| Field | ||||
| 008 | 911270-5 | 1.00 | 1.21 | |
| Field | ||||
| 008-1 | 911270-5 | 1.00 | 1.21 | |
| Intermediate Plate | ||||
| 009 | 411143-7 | 2.40 | 2.90 | |
| Ball bearing 6200llb | ||||
| 010 | 211066-7 | 4.80 | 5.81 | |
| Insulation ring | ||||
| 011 | 681635-2 | 1.20 | 1.45 | |
| Insulation ring | ||||
| 011-3 | 681635-2 | 1.20 | 1.45 | |
| Armature | ||||
| 012 | 514205-1 | 93.50 | 113.14 | |
| Armature | ||||
| 012C | 514205-1 | 93.50 | 113.14 | |
| Fan 90 | ||||
| 013 | 241806-9 | 6.00 | 7.26 | |
| Ball bearing 6200llb | ||||
| 014 | 211066-7 | 4.80 | 5.81 | |
| Ball bearing 6200dw | ||||
| 014-1 | 211087-9 | 8.40 | 10.16 | |
| Dust collection plate | ||||
| 015 | 151177-5 | 58.30 | 70.54 | |
| Dust collection plate | ||||
| 015-1 | 151177-5 | 58.30 | 70.54 | |
| Screw 5x18 | ||||
| 016 | 911230-7 | 1.20 | 1.45 | |
| Impeller 74 | ||||
| 017 | 241611-4 | 6.00 | 7.26 | |
| Screw 5x12 | ||||
| 018 | 911211-1 | 1.00 | 1.21 | |
| Screw 5x12 | ||||
| 018 | 911213-7 | 1.00 | 1.21 | |
| Fan Guide | ||||
| 019 | 343166-6 | 2.40 | 2.90 | |
| Screw 5x25 | ||||
| 020 | 911241-2 | 1.00 | 1.21 | |
| Screw 5x25 | ||||
| 020 | 911243-8 | 1.00 | 1.21 | |
| Dust Cover | ||||
| 021 | 315772-7 | 45.10 | 54.57 | |
| Dust Cover | ||||
| 021-1 | 315772-7 | 45.10 | 54.57 | |
| Screw 5x25 | ||||
| 022 | 911243-8 | 1.00 | 1.21 | |
| Screw 5x25 | ||||
| 022-1 | 911241-2 | 1.00 | 1.21 | |
| Tension roller | ||||
| 023 | 152103-7 | 41.80 | 50.58 | |
| Slide Bearing 12 | ||||
| 023A | 214101-0 | 3.60 | 4.36 | |
| Disk Washer M12 | ||||
| 024 | 253922-5 | 1.00 | 1.21 | |
| Tension roller | ||||
| 025 | 325108-2 | 9.60 | 11.62 | |
| Disk Washer M12 | ||||
| 026 | 253922-5 | 1.00 | 1.21 | |
| Lock washer S-12 | ||||
| 027 | 961052-5 | 1.00 | 1.21 | |
| Button 55 | ||||
| 028 | 271207-7 | 7.20 | 8.71 | |
| Compression Spring 9 | ||||
| 029 | 231110-4 | 1.00 | 1.21 | |
| Washer 8 | ||||
| 030 | 941202-8 | 1.00 | 1.21 | |
| Locking screw M8x72 | ||||
| 031 | 251821-5 | 4.80 | 5.81 | |
| Screw 5x16 | ||||
| 032 | 911221-8 | 1.00 | 1.21 | |
| Bushing 6 | ||||
| 033 | 257504-5 | 2.40 | 2.90 | |
| Screen cover | ||||
| 034 | 343165-8 | 19.80 | 23.96 | |
| Handle Cover | ||||
| 035 | 411142-9 | 9.60 | 11.62 | |
| Screw 4X18 | ||||
| 036 | 911133-5 | 1.00 | 1.21 | |
| Screw 4X18 | ||||
| 036-1 | 911133-5 | 1.00 | 1.21 | |
| Clamp Bracket | ||||
| 037 | 687001-1 | 1.00 | 1.21 | |
| Clamp Bracket | ||||
| 037A1 | 687001-1 | 1.00 | 1.21 | |
| Clamp Bracket | ||||
| 037A2 | 687031-2 | 1.00 | 1.21 | |
| Capacitor 0,1uf | ||||
| 038-1 | 645105-5 | 3.60 | 4.36 | |
| Switch Sw-02 | ||||
| 039 | 651017-2 | 16.50 | 19.96 | |
| No information available, not orderable | ||||
| 039-1 | 651018-0 | |||
| Power cord 2x1.50 4.0mtr | ||||
| 040 | 695123-3 | 22.00 | 26.62 | |
| No information available, not orderable | ||||
| 040C1 | 666226-0 | |||
| No information available, not orderable | ||||
| 040C2 | 665883-1 | |||
| Switch Sw-46 | ||||
| 041 | 651557-0 | 19.80 | 23.96 | |
| Switch Sw-46 | ||||
| 041-1 | 651557-0 | 19.80 | 23.96 | |
| Cable grommet 10-85 | ||||
| 042 | 682504-0 | 2.40 | 2.90 | |
| Cable grommet 8-85 | ||||
| 042A | 682502-4 | 2.40 | 2.90 | |
| Cable grommet 9.3-85 | ||||
| 042A1 | 682516-3 | 1.20 | 1.45 | |
| Screw 4x30 | ||||
| 043 | 911158-9 | 1.00 | 1.21 | |
| Screw 5x40 | ||||
| 044 | 911263-2 | 1.00 | 1.21 | |
| Lock washer S-12 | ||||
| 045 | 961052-5 | 1.00 | 1.21 | |
| Thin Washer 12 | ||||
| 046 | 253312-2 | 1.00 | 1.21 | |
| Thin Washer 12 | ||||
| 046-1 | 253312-2 | 1.00 | 1.21 | |
| Gear 42 | ||||
| 047 | 221194-0 | 13.20 | 15.97 | |
| Screw 5x16 | ||||
| 048 | 911221-8 | 1.00 | 1.21 | |
| Screw 5x16 | ||||
| 048-1 | 911221-8 | 1.00 | 1.21 | |
| Frame | ||||
| 049 | 156226-3 | 161.70 | 195.66 | |
| Slide Bearing 12 | ||||
| 049A | 214101-0 | 3.60 | 4.36 | |
| Countersunk Screw 5x18 | ||||
| 050 | 912227-9 | 1.00 | 1.21 | |
| Support Pin | ||||
| 051 | 325109-0 | 2.40 | 2.90 | |
| Wear strip | ||||
| 052 | 155885-0 | 4.80 | 5.81 | |
| Wear strip | ||||
| 052-1 | 155885-0 | 4.80 | 5.81 | |
| Cork plate | ||||
| 053 | 421093-8 | 3.60 | 4.36 | |
| Torsion spring 18 | ||||
| 054 | 231520-5 | 1.20 | 1.45 | |
| Tension Roll Arm | ||||
| 055 | 163039-5 | 16.50 | 19.96 | |
| Leaf Spring | ||||
| 056 | 232029-0 | 1.20 | 1.45 | |
| Balance Plate | ||||
| 057 | 341195-3 | 3.60 | 4.36 | |
| Disk Washer M12 | ||||
| 058 | 253922-5 | 1.00 | 1.21 | |
| Drive roller | ||||
| 059 | 151346-8 | 48.40 | 58.56 | |
| Drive roller | ||||
| 059A | 151346-8 | 48.40 | 58.56 | |
| Guard | ||||
| 060 | 342331-4 | 4.80 | 5.81 | |
| Screw 5x18 | ||||
| 061 | 911230-7 | 1.20 | 1.45 | |
| Feather Key 4 | ||||
| 062 | 254202-2 | 1.00 | 1.21 | |
| Screw 4X10 | ||||
| 063 | 911111-5 | 1.00 | 1.21 | |
| Screw 4x12 | ||||
| 063 | 911116-5 | 1.00 | 1.21 | |
| Support strip | ||||
| 064 | 341079-5 | 1.20 | 1.45 | |
| Carbon Plate | ||||
| 065 | 423029-3 | 4.80 | 5.81 | |
| Needle Bearing 810 | ||||
| 066 | 212003-4 | 4.80 | 5.81 | |
| Gear 10 | ||||
| 067 | 221193-2 | 13.20 | 15.97 | |
| Ball bearing 6200llb | ||||
| 068 | 211066-7 | 4.80 | 5.81 | |
| Gearbox Cover | ||||
| 069 | 312549-1 | 16.50 | 19.96 | |
| Gearbox Cover | ||||
| 069-1 | 312549-1 | 16.50 | 19.96 | |
| Belt Disc 6-55.7 | ||||
| 070 | 222038-7 | 15.40 | 18.63 | |
| V-belt 6-355 | ||||
| 071 | 225021-3 | 16.50 | 19.96 | |
| V-belt 6-355 | ||||
| 071-2 | 225021-3 | 16.50 | 19.96 | |
| Rubber Pin 4 | ||||
| 072 | 263002-9 | 1.00 | 1.21 | |
| Rubber Pin 4 | ||||
| 073 | 263002-9 | 1.00 | 1.21 | |
| Rubber Pin 4 | ||||
| 074 | 263002-9 | 1.00 | 1.21 | |
| Hose Band | ||||
| 075 | 687010-0 | 1.00 | 1.21 | |
