Here you will find all available parts and drawings of the 'Makita 6980FD'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita 6980FD
Spare parts list of model Makita 6980FD
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Motor Housing 6980Fd A | ||||
| 001 | 183777-3 | 13.20 | 15.97 | |
| Name Plate 6980Fd | ||||
| 002 | 860199-1 | 3.60 | 4.36 | |
| Tapping Screw 3x16 | ||||
| 003 | 266130-9 | 1.00 | 1.21 | |
| Tapping screw Pt3x10 | ||||
| 004 | 266007-8 | 1.00 | 1.21 | |
| L/r adjusting lever | ||||
| 005 | 416079-5 | 1.20 | 1.45 | |
| Switch 6980Fd | ||||
| 006 | 638326-6 | 52.80 | 63.89 | |
| Rubber Pin 4 | ||||
| 007 | 263024-9 | 1.20 | 1.45 | |
| Holder | ||||
| 008 | 687085-9 | 1.20 | 1.45 | |
| Contact strip +/+ | ||||
| 009 | 654168-0 | 2.40 | 2.90 | |
| Contact strip -/- | ||||
| 010 | 654169-8 | 2.40 | 2.90 | |
| Locking Ring 11 | ||||
| 011 | 231951-8 | 1.00 | 1.21 | |
| Washer 12 | ||||
| 012 | 267085-1 | 1.00 | 1.21 | |
| Compression Spring 13 | ||||
| 013 | 233005-7 | 1.00 | 1.21 | |
| Socket | ||||
| 014 | 324420-7 | 4.80 | 5.81 | |
| Buffer Ring Btd123F | ||||
| 015 | 421847-3 | 2.40 | 2.90 | |
| Impact Case CPL. | ||||
| 016 | 153808-2 | 14.30 | 17.30 | |
| Nylon ring 14 | ||||
| 017 | 261108-7 | 1.00 | 1.21 | |
| Steel ball 3.5 | ||||
| 018 | 216040-0 | 1.00 | 1.21 | |
| Anvil | ||||
| 019 | 324432-0 | 19.80 | 23.96 | |
| Striker | ||||
| 020 | 324262-9 | 22.00 | 26.62 | |
| Steel ball 3.5 | ||||
| 021 | 216040-0 | 1.00 | 1.21 | |
| Flat Washer 24 | ||||
| 022 | 267175-0 | 1.20 | 1.45 | |
| Compression Spring 25 | ||||
| 023 | 233274-0 | 2.40 | 2.90 | |
| Washer 14 | ||||
| 024 | 267766-7 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 025 | 216011-7 | |||
| Gear 22 | ||||
| 026 | 227362-3 | 3.60 | 4.36 | |
| Axis 6916Fd A | ||||
| 027 | 324220-5 | 10.80 | 13.07 | |
| Pen 5 | ||||
| 028 | 256253-1 | 1.00 | 1.21 | |
| Washer 12 | ||||
| 029 | 267212-0 | 1.00 | 1.21 | |
| Washer 41 | ||||
| 030 | 257254-2 | 1.20 | 1.45 | |
| Internal gear 51 | ||||
| 031 | 227112-6 | 4.80 | 5.81 | |
| Ball Bearing 6901zz | ||||
| 032 | 211150-8 | 6.00 | 7.26 | |
| O-ring 46 | ||||
| 033 | 213620-3 | 1.20 | 1.45 | |
| Screw 4x12 | ||||
| 034 | 911516-9 | 2.40 | 2.90 | |
| Gearcase Sa | ||||
| 035 | 158079-6 | 16.50 | 19.96 | |
| Magnet Unit | ||||
| 036 | 638511-1 | 30.80 | 37.27 | |
| Armature | ||||
| 037 | 619084-3 | 34.10 | 41.26 | |
| Brush/bearing holder | ||||
| 038 | 638156-5 | 6.00 | 7.26 | |
| Brush Set Cb-434 | ||||
| 039 | 193466-2 | 4.80 | 5.81 | |
| Brush Cap | ||||
| 040 | 643933-2 | 2.40 | 2.90 | |
| Spacer | ||||
| 041 | 689096-0 | 1.20 | 1.45 | |
| No information available, not orderable | ||||
| 042 | 266170-7 | |||
| Tapping Screw 3x16 | ||||
| 043 | 266130-9 | 1.00 | 1.21 | |
| Lock Lever | ||||
| 044 | 313118-1 | 2.40 | 2.90 | |
| No information available, not orderable | ||||
| 045 | 819720-3 | |||
| Motor Housing 6980Fd A | ||||
| 046 | 183777-3 | 13.20 | 15.97 | |
| Rubber Pin 4 | ||||
| 047 | 263024-9 | 1.20 | 1.45 | |
