Here you will find all available parts and drawings of the 'Makita 6960D'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita 6960D
Spare parts list of model Makita 6960D
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Motorhuis set | ||||
| 001 | 182945-5 | 13.20 | 15.97 | |
| No information available, not orderable | ||||
| 002 | 859276-4 | |||
| Tap screw 4x18 | ||||
| 003 | 265A48-7 | 1.00 | 1.21 | |
| Screw 4x22 | ||||
| 004 | 911143-2 | 1.00 | 1.21 | |
| L/r adjusting lever | ||||
| 005 | 416079-5 | 1.20 | 1.45 | |
| Cooling Sheet | ||||
| 006 | 689070-8 | 2.71 | 3.28 | |
| Schroef 3x8 | ||||
| 007 | 652066-2 | 1.00 | 1.21 | |
| Switch | ||||
| 008 | 650540-4 | 36.30 | 43.92 | |
| Rubber Pin 4 | ||||
| 009 | 263002-9 | 1.00 | 1.21 | |
| Holder | ||||
| 010 | 687085-9 | 1.20 | 1.45 | |
| Contact strip -/- | ||||
| 011 | 654169-8 | 2.40 | 2.90 | |
| Contact strip +/+ | ||||
| 012 | 654168-0 | 2.40 | 2.90 | |
| Ball bearing 6001llb | ||||
| 013 | 211101-1 | 6.00 | 7.26 | |
| Washer 12 | ||||
| 014 | 253052-2 | 1.00 | 1.21 | |
| Pen 5 | ||||
| 015 | 256253-1 | 1.00 | 1.21 | |
| Gear 20 6960Dwa * | ||||
| 016 | 226360-4 | 6.00 | 7.26 | |
| Gear carrier 6960Dwa * | ||||
| 017 | 323742-2 | 42.90 | 51.91 | |
| Ball bearing 6000llb | ||||
| 018 | 211061-7 | 8.40 | 10.16 | |
| Bearing Housing 6960Dwa * | ||||
| 019 | 317000-6 | 13.20 | 15.97 | |
| Oil Unit Complete 6960Dwa * | ||||
| 020 | 151501-2 | 389.40 | 471.17 | |
| Steel ball 3 | ||||
| 021 | 216019-1 | 1.00 | 1.21 | |
| Ball Bearing 6801llb | ||||
| 022 | 210112-3 | 6.00 | 7.26 | |
| Oil Unit House 6960Dwa * | ||||
| 023 | 317001-4 | 16.50 | 19.96 | |
| Self Tapping Screw Pt4x30 | ||||
| 024 | 266050-7 | 1.00 | 1.21 | |
| Bithouderbus 6960Dwa * | ||||
| 025 | 322803-5 | 6.00 | 7.26 | |
| Compression Spring 13 | ||||
| 026 | 233005-7 | 1.00 | 1.21 | |
| Flat washer | ||||
| 027 | 267143-3 | 1.20 | 1.45 | |
| Spring Washer 10 | ||||
| 028 | 231965-7 | 1.00 | 1.21 | |
| Internal Gear 47 6960Dwa * | ||||
| 029 | 226343-4 | 2.40 | 2.90 | |
| Internal Gearbox 6960Dwa * | ||||
| 030 | 317062-4 | 14.30 | 17.30 | |
| Motor plate 6960Dwa * | ||||
| 031 | 416400-8 | 1.20 | 1.45 | |
| No information available, not orderable | ||||
| 032 | 629722-9 | |||
| Gear for motor 7 | ||||
| 032A | 226337-9 | 16.50 | 19.96 | |
| Gear 20 6960Dwa * | ||||
| 033 | 226360-4 | 6.00 | 7.26 | |
| Pen 5 | ||||
| 034 | 256253-1 | 1.00 | 1.21 | |
| Gear 20 6960Dwa * | ||||
| 035 | 226360-4 | 6.00 | 7.26 | |
| Pen 5 | ||||
| 036 | 256253-1 | 1.00 | 1.21 | |
| Carbon brush set Cb-424 | ||||
| 037 | 191966-6 | 3.60 | 4.36 | |
| Brush Cap | ||||
| 038 | 643933-2 | 2.40 | 2.90 | |
| Motorhuis set | ||||
| 039 | 182945-5 | 13.20 | 15.97 | |
| Allen Bolt M3x10 | ||||
| 040 | 266177-3 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 041 | 819102-9 | |||
| Label Makita | ||||
| 042 | 819063-3 | 2.40 | 2.90 | |
| Rubber Pin 4 | ||||
| 043 | 263002-9 | 1.00 | 1.21 | |
