Here you will find all available parts and drawings of the 'Makita 6940D'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita 6940D
Spare parts list of model Makita 6940D
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Motorhuis set | ||||
| 001 | 182713-6 | 13.20 | 15.97 | |
| Self-tapping screw 4x20 | ||||
| 002 | 265925-7 | 1.00 | 1.21 | |
| Battery clamp | ||||
| 004 | 643918-8 | 8.40 | 10.16 | |
| Battery Plate | ||||
| 006 | 344121-1 | 2.40 | 2.90 | |
| Compression Spring 6 | ||||
| 007 | 231470-4 | 1.00 | 1.21 | |
| Switch Block | ||||
| 008 | 417160-5 | 1.20 | 1.45 | |
| Switch Handle | ||||
| 009 | 152615-0 | 10.80 | 13.07 | |
| Switch slide | ||||
| 010 | 414740-8 | 2.40 | 2.90 | |
| Switch Sw-148 | ||||
| 011 | 651967-1 | 41.80 | 50.58 | |
| Hex bolt 5x30 | ||||
| 012 | 265409-5 | 2.40 | 2.90 | |
| Transmission Housing | ||||
| 013 | 152461-1 | 56.10 | 67.88 | |
| Gear Shaft | ||||
| 014 | 226720-0 | 20.90 | 25.29 | |
| Ball bearing 6000 | ||||
| 015 | 211064-1 | 5.71 | 6.91 | |
| Sleeve 10 | ||||
| 016 | 257660-1 | 2.40 | 2.90 | |
| Ball bearing 6000llb | ||||
| 017 | 211061-7 | 8.40 | 10.16 | |
| Locking Ring S-10 | ||||
| 018 | 257408-1 | 1.20 | 1.45 | |
| Lock ring R-26 A | ||||
| 019 | 962105-3 | 1.00 | 1.21 | |
| Sleeve 15 | ||||
| 020 | 257662-7 | 6.00 | 7.26 | |
| Rubber ring 21 | ||||
| 021 | 261095-0 | 1.20 | 1.45 | |
| Washer 15 | ||||
| 022 | 267120-5 | 3.60 | 4.36 | |
| Anvil | ||||
| 023 | 322689-7 | 31.90 | 38.60 | |
| Hammer | ||||
| 024 | 322688-9 | 17.60 | 21.30 | |
| Steel ball 3.5 | ||||
| 025 | 216040-0 | 1.00 | 1.21 | |
| Washer 20 | ||||
| 026 | 267121-3 | 1.20 | 1.45 | |
| Compression Spring 22 | ||||
| 027 | 233107-9 | 2.40 | 2.90 | |
| DC Motor 9.6v | ||||
| 028 | 629683-3 | 34.10 | 41.26 | |
| Washer 12 | ||||
| 029 | 267053-4 | 1.00 | 1.21 | |
| Internal gear 69 | ||||
| 030 | 226280-2 | 16.50 | 19.96 | |
| Washer 32 | ||||
| 031 | 257187-1 | 3.60 | 4.36 | |
| Gear 29 | ||||
| 032 | 226279-7 | 3.60 | 4.36 | |
| Gear 29 | ||||
| 033 | 226279-7 | 3.60 | 4.36 | |
| Spindle Ass'y | ||||
| 034 | 154416-2 | 28.60 | 34.61 | |
| Pin 3 6940Dw * | ||||
| 034A | 256216-7 | 1.00 | 1.21 | |
| Steel ball 4.8 | ||||
| 035 | 216002-8 | 1.00 | 1.21 | |
| Ball bearing 6000 | ||||
| 036 | 211064-1 | 5.71 | 6.91 | |
| Ring 10 | ||||
| 037 | 322719-4 | 4.80 | 5.81 | |
| Gear 29 | ||||
| 038 | 226279-7 | 3.60 | 4.36 | |
| Steel ball 4.8 | ||||
| 039 | 216002-8 | 1.00 | 1.21 | |
| Steel ball 3.5 | ||||
| 041 | 216040-0 | 1.00 | 1.21 | |
| Rubber Washer 31 | ||||
| 042 | 262062-8 | 1.20 | 1.45 | |
| Washer 9 A | ||||
| 043 | 231990-8 | 1.00 | 1.21 | |
| Gear 13 | ||||
| 044 | 226721-8 | 13.20 | 15.97 | |
| Ball Bearing 6001dw | ||||
| 045 | 211131-2 | 9.60 | 11.62 | |
| As C-form | ||||
| 046 | 323921-2 | 18.70 | 22.63 | |
| Steel ball 3.5 | ||||
| 047 | 216040-0 | 1.00 | 1.21 | |
| Socket | ||||
| 048 | 322718-6 | 7.20 | 8.71 | |
| Compression Spring 13 | ||||
| 049 | 233005-7 | 1.00 | 1.21 | |
| Washer 12 | ||||
| 050 | 267085-1 | 1.00 | 1.21 | |
| Spring Washer 6 | ||||
| 051 | 231956-8 | 1.20 | 1.45 | |
| Stop ring R-28 | ||||
| 052 | 962116-8 | 1.20 | 1.45 | |
