Here you will find all available parts and drawings of the 'Makita 6906'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita 6906
Spare parts list of model Makita 6906
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Bumper (a) | ||||
| 001 | 421112-0 | 4.80 | 5.81 | |
| No information available, not orderable | ||||
| 002 | 156087-1 | |||
| HAMMER HOUSING 6906 A | ||||
| 002-1 | 141R37-7 | 96.80 | 117.13 | |
| Seal ring 25 | ||||
| 002A | 213360-3 | 4.80 | 5.81 | |
| Housing 25 | ||||
| 002B | 257535-4 | 13.20 | 15.97 | |
| Retaining ring 16A | ||||
| 003 | 231920-9 | 1.80 | 2.18 | |
| Lock washer 16 A | ||||
| 003 | 232334-5 | 1.20 | 1.45 | |
| Washer 65 | ||||
| 004 | 257040-1 | 23.10 | 27.95 | |
| Washer 25 | ||||
| 005 | 253939-8 | 4.80 | 5.81 | |
| Anvil | ||||
| 006 | 324231-0 | 78.10 | 94.50 | |
| Plastic Washer 27 | ||||
| 007 | 261023-5 | 2.40 | 2.90 | |
| Steel ball 4 | ||||
| 008 | 216008-6 | 1.00 | 1.21 | |
| Hammer | ||||
| 009 | 325318-1 | 100.10 | 121.12 | |
| Washer 30 | ||||
| 010 | 253764-7 | 2.40 | 2.90 | |
| Compression spring 37 | ||||
| 011 | 231135-8 | 7.20 | 8.71 | |
| Washer 36 * | ||||
| 012 | 253765-5 | 1.20 | 1.45 | |
| Steel ball 7.1 | ||||
| 013 | 216009-4 | 1.00 | 1.21 | |
| Gear 29 | ||||
| 014 | 221243-3 | 9.60 | 11.62 | |
| Needle Bearing 609 | ||||
| 015 | 212011-5 | 9.60 | 11.62 | |
| Spindle Ass'y | ||||
| 016 | 325322-0 | 86.90 | 105.15 | |
| Pin 6 | ||||
| 017 | 256041-6 | 1.00 | 1.21 | |
| Needle Bearing 1412 | ||||
| 018 | 212151-9 | 9.60 | 11.62 | |
| Ball bearing 3009 | ||||
| 019 | 211441-7 | 11.00 | 13.31 | |
| Gear Ring | ||||
| 020 | 221242-5 | 48.40 | 58.56 | |
| Pen 5 | ||||
| 021 | 256040-8 | 1.00 | 1.21 | |
| Locking Ring R-75 * | ||||
| 022 | 962352-6 | 3.60 | 4.36 | |
| Inner needle bearing 1016 | ||||
| 023 | 216103-2 | 6.00 | 7.26 | |
| Washer 10 | ||||
| 024 | 253180-3 | 1.20 | 1.45 | |
| Impeller 73 | ||||
| 025 | 241609-1 | 7.20 | 8.71 | |
| Armature | ||||
| 026 | 512883-1 | 100.10 | 121.12 | |
| Insulation ring | ||||
| 027 | 681613-2 | 1.00 | 1.21 | |
| Ball bearing 608llb | ||||
| 028 | 210043-6 | 2.40 | 2.90 | |
| Intermediate Plate | ||||
| 029 | 413008-9 | 3.60 | 4.36 | |
| Hexagon bolt 5x70 | ||||
| 030 | 265350-2 | 2.40 | 2.90 | |
| Field | ||||
| 031 | 527419-3 | 72.60 | 87.85 | |
| Little stator spring Cb-7 | ||||
| 031A | 654019-7 | 1.20 | 1.45 | |
| Clamping bushing for statorv. 1.25mm | ||||
| 031B | 654501-6 | 0.83 | 1.00 | |
| Disk Washer M5 | ||||
| 032 | 253929-1 | 1.00 | 1.21 | |
| Plastic Washer 5 | ||||
| 033 | 262001-8 | 1.39 | 1.68 | |
| Hex socket screw 5x40 | ||||
| 034 | 922262-9 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 035 | 253303-3 | |||
| Washer 65 | ||||
| 036 | 253774-4 | 2.40 | 2.90 | |
| Screw 4x45 | ||||
| 037 | 911571-1 | 1.20 | 1.45 | |
| Handle cover | ||||
| 038 | 414959-9 | 7.20 | 8.71 | |
| Screw 4x8 | ||||
| 039 | 911106-8 | 1.00 | 1.21 | |
| Switch Sw-07 | ||||
| 040 | 651564-3 | 26.40 | 31.94 | |
| Screw 3.5x5 | ||||
| 040A | 652045-0 | 1.00 | 1.21 | |
| Capacitor | ||||
| 041 | 645206-9 | 4.80 | 5.81 | |
| Screw 4X18 | ||||
| 042 | 911133-5 | 1.00 | 1.21 | |
| Clamp Bracket | ||||
| 043 | 687031-2 | 1.00 | 1.21 | |
| Cable grommet 10-85 | ||||
| 044 | 682504-0 | 2.40 | 2.90 | |
| Brush holder cap | ||||
| 046 | 643600-9 | 1.20 | 1.45 | |
| Carbon Brush Set Cb-100 | ||||
| 047 | 181030-1 | 3.54 | 4.28 | |
| Carbon Brush CB100 | ||||
| 047 | 194974-6 | 3.54 | 4.28 | |
| Motor Housing | ||||
| 050 | 159414-1 | 58.30 | 70.54 | |
| Plastic Washer 18 | ||||
| 051 | 262010-7 | 1.20 | 1.45 | |
| Thin washer 15 | ||||
| 052 | 253314-8 | 1.00 | 1.21 | |
| Tail Cover | ||||
| 053 | 284065-2 | 9.60 | 11.62 | |
| Allen bolt 5x16 | ||||
| 054 | 922221-3 | 1.00 | 1.21 | |
| Power cord 2x1.50 4.0mtr | ||||
| 055 | 695123-3 | 22.00 | 26.62 | |
| Connection unit HM1511 | ||||
| 901 | 654741-6 | 2.40 | 2.90 | |
| Interference filter | ||||
| 902 | 646358-9 | 2.40 | 2.90 | |
