Here you will find all available parts and drawings of the 'Makita 6336D'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita 6336D
Spare parts list of model Makita 6336D
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Label | ||||
| 001 | 851487-7 | 3.60 | 4.36 | |
| Tapping Screw 3x16 | ||||
| 002 | 266130-9 | 1.00 | 1.21 | |
| Bit clamp | ||||
| 003 | 344391-2 | 1.00 | 1.21 | |
| Motorhuis set | ||||
| 004 | 183490-3 | 10.80 | 13.07 | |
| High/low speed slide | ||||
| 005 | 125091-1 | 1.20 | 1.45 | |
| Compression Spring 4 | ||||
| 005A | 231433-0 | 1.00 | 1.21 | |
| L/r adjusting lever | ||||
| 006 | 416079-5 | 1.20 | 1.45 | |
| Switch | ||||
| 007 | 650540-4 | 36.30 | 43.92 | |
| Holder | ||||
| 008 | 687085-9 | 1.20 | 1.45 | |
| Contact strip +/+ | ||||
| 009 | 654168-0 | 2.40 | 2.90 | |
| Contact strip -/- | ||||
| 010 | 654169-8 | 2.40 | 2.90 | |
| Screw 6x32 | ||||
| 011 | 251465-1 | 9.60 | 11.62 | |
| BOORKOP SNELSPAN 1,5-13MM | ||||
| 012 | 193616-9 | 29.00 | 35.09 | |
| Gear unit | ||||
| 013 | 125105-6 | 45.10 | 54.57 | |
| Adjustable handle 6316D * | ||||
| 013A | 417381-9 | 1.20 | 1.45 | |
| DC Motor 14.4V | ||||
| 014 | 629734-2 | 48.40 | 58.56 | |
| No information available, not orderable | ||||
| 015 | 265999-8 | |||
| Self-tapping screw 4X8 * | ||||
| 016 | 266134-1 | 1.00 | 1.21 | |
| Schroef 3x8 | ||||
| 017 | 652066-2 | 1.00 | 1.21 | |
| Motorhuis set | ||||
| 018 | 183490-3 | 10.80 | 13.07 | |
| Carbon brush set Cb-430 | ||||
| 019 | 191971-3 | 3.60 | 4.36 | |
| Brush Cap | ||||
| 020 | 643929-3 | 1.00 | 1.21 | |
