Here you will find all available parts and drawings of the 'Makita 6333D'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita 6333D
Spare parts list of model Makita 6333D
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Tapping Screw 3x16 | ||||
| 002 | 266130-9 | 1.00 | 1.21 | |
| Bit clamp | ||||
| 003 | 344391-2 | 1.00 | 1.21 | |
| Motor Housing Set 6333Dw * | ||||
| 004 | 182868-7 | 16.50 | 19.96 | |
| High/low speed slide | ||||
| 005 | 416058-3 | 1.00 | 1.21 | |
| Compression Spring 4 | ||||
| 006 | 231433-0 | 1.00 | 1.21 | |
| Compression Spring 4 | ||||
| 007 | 231433-0 | 1.00 | 1.21 | |
| L/r adjusting lever | ||||
| 008 | 416079-5 | 1.20 | 1.45 | |
| Switch | ||||
| 009 | 650540-4 | 36.30 | 43.92 | |
| Holder | ||||
| 010 | 687085-9 | 1.20 | 1.45 | |
| Contact strip +/+ | ||||
| 011 | 654168-0 | 2.40 | 2.90 | |
| Contact strip -/- | ||||
| 012 | 654169-8 | 2.40 | 2.90 | |
| Schroef 3x8 | ||||
| 013 | 652066-2 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 014 | 629700-9 | |||
| No information available, not orderable | ||||
| 014A | 226325-6 | |||
| Gear set | ||||
| 015 | 125067-8 | 36.30 | 43.92 | |
| H/L Adjusting Handle 6313D | ||||
| 015A | 417078-0 | 1.20 | 1.45 | |
| No longer available, no replacement | ||||
| 016 | 257671-6 | |||
| No information available, not orderable | ||||
| 017 | 192891-4 | |||
| Bolt 5x35 | ||||
| 018 | 266154-5 | 3.60 | 4.36 | |
| Leaf Spring | ||||
| 019 | 232159-7 | 1.00 | 1.21 | |
| Motor Housing Set 6333Dw * | ||||
| 021 | 182868-7 | 16.50 | 19.96 | |
| Screw 3X12 | ||||
| 022 | 911017-7 | 1.00 | 1.21 | |
| Self-tapping screw 4X8 * | ||||
| 023 | 266134-1 | 1.00 | 1.21 | |
| Brush Cap | ||||
| 024 | 643929-3 | 1.00 | 1.21 | |
| Carbon brush set Cb-430 | ||||
| 025 | 191971-3 | 3.60 | 4.36 | |
| Gearbox housing A 6203 series * | ||||
| 099 | 416055-9 | 3.60 | 4.36 | |
