Here you will find all available parts and drawings of the 'Makita 4390D'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Makita 4390D

Spare parts list of model Makita 4390D

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
Motor 9.6V A
001 197671-3 25.36 30.69
No information available, not orderable
002 152272-4
Gear 4300Dw-4307Dw *
003 153202-8 21.23 25.69
Thin Lock Washer 4
004 253307-5 0.83 1.00
4 Washer
005 253874-0 0.83 1.00
Needle Bearing 407
006 212092-9 13.82 16.72
No longer available, no replacement
007 154401-5
Slide Bearing 3 *
008 214020-0 1.18 1.43
No information available, not orderable
009 443063-7
Terminal Device
010 344979-8 3.54 4.28
Slide Bearing 3 *
011 214020-0 1.18 1.43
Slide Bearing 3 *
012 214020-0 1.18 1.43
Allen bolt 4x8
013 922106-3 0.83 1.00
Battery terminal plate
014 342833-0 2.36 2.86
Complete Housing 4390Dw *
015 182406-5 51.84 62.73
Compression spring 3 *
017 231390-2 0.83 1.00
Unlock button
018 414169-8 0.83 1.00
Battery clamp
019 643918-8 7.22 8.74
No information available, not orderable
020 410972-5
No information available, not orderable
021 651862-5
No longer available, no replacement
022 322099-8
Locking Pin 4
023 256654-3 2.02 2.44
No longer available, no replacement
024 343875-7
Stopring E-3
026 961017-7 0.83 1.00
Screw 4x22
027 911143-2 0.83 1.00
