Here you will find all available parts and drawings of the 'Makita 4304'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita 4304
Spare parts list of model Makita 4304
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Switch Sw-131 | ||||
| 001 | 651922-3 | 11.00 | 13.31 | |
| Handle Set 4304 * | ||||
| 002 | 182680-5 | 18.70 | 22.63 | |
| Tapping screw Pt4x20 | ||||
| 003 | 266045-0 | 1.00 | 1.21 | |
| Power cord 2x1.00 2.2mtr | ||||
| 004 | 665383-1 | 10.80 | 13.07 | |
| Cable grommet 8-85 | ||||
| 005 | 682502-4 | 2.40 | 2.90 | |
| Clamp Bracket | ||||
| 006 | 687053-2 | 1.00 | 1.21 | |
| Clamp Bracket | ||||
| 006 | 687124-5 | 1.00 | 1.21 | |
| Tap screw 4x18 | ||||
| 007 | 265A48-7 | 1.00 | 1.21 | |
| Pen 3 | ||||
| 009 | 256221-4 | 1.00 | 1.21 | |
| Switch Button | ||||
| 010 | 415158-6 | 3.60 | 4.36 | |
| Spacer 4304 * | ||||
| 011 | 415159-4 | 2.40 | 2.90 | |
| Compression Spring 4 | ||||
| 012 | 233101-1 | 1.00 | 1.21 | |
| Lock Lever | ||||
| 013 | 415534-4 | 1.20 | 1.45 | |
| Speed control unit | ||||
| 014 | 631678-4 | 22.00 | 26.62 | |
| Tapping screw Pt4x20 | ||||
| 015 | 266045-0 | 1.00 | 1.21 | |
| Tapping Screw Ct4x16 | ||||
| 016 | 266034-5 | 1.00 | 1.21 | |
| Gearbox cover | ||||
| 017 | 153389-6 | 52.80 | 63.89 | |
| Glijlager 8 | ||||
| 017A | 214005-6 | 1.20 | 1.45 | |
| Slide Bearing 10 | ||||
| 017B | 214061-6 | 2.40 | 2.90 | |
| Spring pin 3-12 | ||||
| 017C | 951057-3 | 1.00 | 1.21 | |
| Seal 8 | ||||
| 017D | 421821-1 | 1.20 | 1.45 | |
| Bridge Holder | ||||
| 018 | 316608-3 | 11.00 | 13.31 | |
| New bridge | ||||
| 019 | 310028-3 | 12.10 | 14.64 | |
| Countersunk screw M4x12 | ||||
| 020 | 251263-3 | 3.60 | 4.36 | |
| Intermediate Plate | ||||
| 021 | 344232-2 | 1.20 | 1.45 | |
| Needle Bearing 607 | ||||
| 022 | 212010-7 | 13.20 | 15.97 | |
| Eccentric | ||||
| 023 | 152454-8 | 9.60 | 11.62 | |
| Pin 6 | ||||
| 023A | 256033-5 | 1.20 | 1.45 | |
| Washer 26 | ||||
| 024 | 253792-2 | 1.00 | 1.21 | |
| Balance Plate | ||||
| 025 | 344330-2 | 7.20 | 8.71 | |
| Balance Plate | ||||
| 026 | 344330-2 | 7.20 | 8.71 | |
| Pressure plate 4304 | ||||
| 027 | 344134-2 | 4.80 | 5.81 | |
| Washer 26 | ||||
| 028 | 253792-2 | 1.00 | 1.21 | |
| Needle Bearing 810 | ||||
| 029 | 212043-2 | 3.60 | 4.36 | |
| Gear 51 | ||||
| 030 | 226428-6 | 23.10 | 27.95 | |
| Needle Bearing 810 | ||||
| 031 | 212043-2 | 3.60 | 4.36 | |
| Washer 8x0.5mm | ||||
| 032 | 253139-0 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 033 | 322691-0 | |||
| Ball bearing 607llb | ||||
| 034 | 211021-9 | 4.80 | 5.81 | |
| Insulation ring | ||||
| 035 | 681636-0 | 1.20 | 1.45 | |
| Armature | ||||
| 036 | 517098-5 | 56.10 | 67.88 | |
| Impeller 54 | ||||
| 037 | 240039-3 | 3.60 | 4.36 | |
| Ball Bearing 608ddw | ||||
| 038 | 210005-4 | 4.80 | 5.81 | |
| Screw 4x12 | ||||
| 039 | 911116-5 | 1.00 | 1.21 | |
| Washer 6 | ||||
| 040 | 253715-0 | 1.20 | 1.45 | |
| Washer 6 | ||||
| 043 | 253715-0 | 1.20 | 1.45 | |
| Gear Cover | ||||
| 044 | 151594-9 | 55.00 | 66.55 | |
| Tapping screw Pt4x20 | ||||
| 045 | 266045-0 | 1.00 | 1.21 | |
| Gearbox cover gasket | ||||
| 046 | 442123-2 | 1.20 | 1.45 | |
| Lock ring S-8 | ||||
| 047 | 961004-6 | 1.00 | 1.21 | |
| Hexagon socket bolt M4x16 | ||||
| 048 | 922126-7 | 1.00 | 1.21 | |
| Compression Spring 4 | ||||
| 049 | 231314-8 | 1.00 | 1.21 | |
| Stopring E-3 | ||||
| 050 | 961017-7 | 1.00 | 1.21 | |
| Pin 4 | ||||
| 051 | 256693-3 | 2.40 | 2.90 | |
| Tapping screw Pf 4x55 | ||||
| 052 | 266147-2 | 1.20 | 1.45 | |
| Support wheel compl. | ||||
| 053 | 152947-5 | 14.30 | 17.30 | |
| Pin 4 | ||||
| 053A | 268074-9 | 2.40 | 2.90 | |
| ROLLER | ||||
| 053B | 152950-6 | 8.40 | 10.16 | |
| Stopring E-3 | ||||
| 053C | 961017-7 | 1.00 | 1.21 | |
| Screw 4x35 | ||||
| 054 | 266351-3 | 1.00 | 1.21 | |
| Handle Set 4304 * | ||||
| 055 | 182680-5 | 18.70 | 22.63 | |
| Plunger | ||||
| 056 | 165089-6 | 59.40 | 71.87 | |
| Hex socket head bolt M6x8 | ||||
| 057 | 265894-2 | 1.00 | 1.21 | |
| Guide Plate | ||||
| 058 | 344137-6 | 2.40 | 2.90 | |
| Adjustment Button | ||||
| 059 | 272231-3 | 8.40 | 10.16 | |
| Compression Spring 4 | ||||
| 060 | 231314-8 | 1.00 | 1.21 | |
| Steel ball 4 | ||||
| 061 | 216008-6 | 1.00 | 1.21 | |
| Retaining Ring E-5 | ||||
| 062 | 961018-5 | 1.00 | 1.21 | |
| Rubber Pin 4 | ||||
| 063 | 263002-9 | 1.00 | 1.21 | |
| Foot pad | ||||
| 064 | 316883-1 | 26.40 | 31.94 | |
| Holding Plate | ||||
| 065 | 331435-7 | 2.40 | 2.90 | |
| Hexagon socket screw 4x25 | ||||
| 066 | 922146-1 | 1.20 | 1.45 | |
| Cover plate for sole | ||||
| 067 | 344443-9 | 15.40 | 18.63 | |
| Intermediate plate 4304 * | ||||
| 068 | 415535-2 | 1.20 | 1.45 | |
| Field | ||||
| 069 | 633288-3 | 18.70 | 22.63 | |
| Hexagon Bolt 5x8 | ||||
| 070 | 266055-7 | 1.00 | 1.21 | |
| Motor Housing 4304 * | ||||
| 071 | 415748-5 | 13.20 | 15.97 | |
| Brush Set CB-419 | ||||
| 072 | 195015-1 | 4.80 | 5.81 | |
| Brush Holder | ||||
| 073 | 643923-5 | 1.18 | 1.43 | |
| Tail Cover | ||||
| 075 | 415532-8 | 8.40 | 10.16 | |
| Self Tapping Screw Pt4x30 | ||||
| 076 | 266050-7 | 1.00 | 1.21 | |
| Cover Cap 4304 * | ||||
| 078 | 415538-6 | 2.40 | 2.90 | |
| Self Tapping Screw Pt4X60 * | ||||
| 079 | 266052-3 | 1.20 | 1.45 | |
| Rubber Ring 19 | ||||
| 080 | 421494-0 | 4.80 | 5.81 | |
| Protection Spring | ||||
| 081 | 322893-8 | 2.40 | 2.90 | |
| Holding Plate | ||||
| 082 | 344784-3 | 1.00 | 1.21 | |
| Sealing felt | ||||
| 083 | 443106-5 | 1.00 | 1.21 | |
