Here you will find all available parts and drawings of the 'Makita 4302C'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita 4302C
Spare parts list of model Makita 4302C
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Switch Sw-17 | ||||
| 001 | 651204-3 | 8.40 | 10.16 | |
| No information available, not orderable | ||||
| 002 | 182197-8 | |||
| Pen 5 * | ||||
| 003 | 256171-3 | 2.40 | 2.90 | |
| Pen 5 * | ||||
| 004 | 256169-0 | 2.40 | 2.90 | |
| No information available, not orderable | ||||
| 005 | 267034-8 | |||
| Role 4302C * | ||||
| 006 | 321988-4 | 3.60 | 4.36 | |
| No information available, not orderable | ||||
| 007 | 267034-8 | |||
| No information available, not orderable | ||||
| 008 | 256172-1 | |||
| Pen 5 * | ||||
| 009 | 256171-3 | 2.40 | 2.90 | |
| Compression spring 5 * | ||||
| 010 | 231429-1 | 1.00 | 1.21 | |
| Spring Guide 4302C * | ||||
| 011 | 322105-9 | 3.60 | 4.36 | |
| Steel ball 6 | ||||
| 012 | 216030-3 | 1.00 | 1.21 | |
| Spacer 4302C * | ||||
| 013 | 343424-0 | 1.20 | 1.45 | |
| Pen 4 * | ||||
| 014 | 256167-4 | 2.40 | 2.90 | |
| Screw 5X45 * | ||||
| 018 | 911266-6 | 1.00 | 1.21 | |
| Steel ball 4 | ||||
| 020 | 216008-6 | 1.00 | 1.21 | |
| Compression Spring 4 | ||||
| 021 | 231314-8 | 1.00 | 1.21 | |
| Handel 25 4302C * | ||||
| 022 | 272225-8 | 7.20 | 8.71 | |
| No information available, not orderable | ||||
| 023 | 168182-5 | |||
| No information available, not orderable | ||||
| 024 | 913312-1 | |||
| No information available, not orderable | ||||
| 025 | 343408-8 | |||
| Seal * | ||||
| 026 | 421318-0 | 1.20 | 1.45 | |
| Thin Washer 9 * | ||||
| 027 | 253340-7 | 1.00 | 1.21 | |
| Plastic Washer 9 * | ||||
| 028 | 261080-3 | 1.00 | 1.21 | |
| Needle Bearing 607 | ||||
| 029 | 212010-7 | 13.20 | 15.97 | |
| Washer 6 | ||||
| 030 | 253804-1 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 031 | 256170-5 | |||
| Washer 6 | ||||
| 032 | 253804-1 | 1.00 | 1.21 | |
| Base plate holder 4302C * | ||||
| 033 | 343377-3 | 3.60 | 4.36 | |
| No longer available, no replacement | ||||
| 034 | 164829-9 | |||
| Plate | ||||
| 035 | 315953-3 | 2.40 | 2.90 | |
| Hex bolt 4x16 | ||||
| 036 | 922127-5 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 037 | 522648-3 | |||
| Ball bearing 608llb | ||||
| 038 | 210043-6 | 2.40 | 2.90 | |
| No information available, not orderable | ||||
| 039 | 681627-1 | |||
| No information available, not orderable | ||||
| 040 | 512908-1 | |||
| Ball bearing 608llb | ||||
| 042 | 210043-6 | 2.40 | 2.90 | |
| No information available, not orderable | ||||
| 043 | 152304-7 | |||
| Washer 8 | ||||
| 044 | 253165-9 | 1.00 | 1.21 | |
| Needle Bearing 810 | ||||
| 045 | 212043-2 | 3.60 | 4.36 | |
| Needle Bearing 810 | ||||
| 046 | 212043-2 | 3.60 | 4.36 | |
| No information available, not orderable | ||||
| 047 | 221752-2 | |||
| Pressure plate 4302C * | ||||
| 049 | 343379-9 | 3.60 | 4.36 | |
| Washer 6 | ||||
| 050 | 253804-1 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 051 | 256170-5 | |||
| Washer 35 * | ||||
| 052 | 253880-5 | 2.40 | 2.90 | |
| Weight block 4302C * | ||||
| 053 | 343380-4 | 9.60 | 11.62 | |
| Weight block 4302C * | ||||
| 054 | 343380-4 | 9.60 | 11.62 | |
| Washer 26 * | ||||
| 055 | 253122-7 | 1.00 | 1.21 | |
| Washer 6 | ||||
| 056 | 253804-1 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 057 | 182243-1 | |||
| Screw 5x16 | ||||
| 058 | 911224-2 | 1.00 | 1.21 | |
| Screw 5x25 | ||||
| 060 | 911241-2 | 1.00 | 1.21 | |
| Rubber Pin 4 | ||||
| 062 | 263002-9 | 1.00 | 1.21 | |
| Lock ring S-6 | ||||
| 063 | 961002-0 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 064 | 256640-4 | |||
| Roller holder | ||||
| 065 | 343378-1 | 6.00 | 7.26 | |
| No information available, not orderable | ||||
| 066 | 321989-2 | |||
| Dust seal * | ||||
| 067 | 421353-8 | 1.20 | 1.45 | |
| Stopring E-3 | ||||
| 069 | 961017-7 | 1.00 | 1.21 | |
| Pen 5 * | ||||
| 070 | 256171-3 | 2.40 | 2.90 | |
| Cable grommet 10-85 | ||||
| 071 | 682504-0 | 2.40 | 2.90 | |
| Power cord 2x1.00 2.2mtr | ||||
| 072 | 665383-1 | 10.80 | 13.07 | |
| Clamp Bracket | ||||
| 073 | 687031-2 | 1.00 | 1.21 | |
| Screw 4X18 | ||||
| 074 | 911131-9 | 1.00 | 1.21 | |
| Carbon brush set CB-113 P | ||||
| 075 | 194978-8 | 12.00 | 14.52 | |
| Brush Holder | ||||
| 076 | 643605-9 | 1.20 | 1.45 | |
| No information available, not orderable | ||||
| 079 | 631080-1 | |||
| No information available, not orderable | ||||
| 080 | 414131-3 | |||
