Here you will find all available parts and drawings of the 'Makita 3704'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita 3704
Spare parts list of model Makita 3704
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| SCREW M4X40 | ||||
| 002 | 911168-6 | 1.00 | 1.21 | |
| Tap screw 4x18 | ||||
| 003 | 265A48-7 | 1.00 | 1.21 | |
| Clamp Bracket | ||||
| 004 | 687124-5 | 1.00 | 1.21 | |
| Tail Cover | ||||
| 005 | 410062-4 | 7.20 | 8.71 | |
| Power cord 2x1.00 2.2mtr | ||||
| 006 | 665383-1 | 10.80 | 13.07 | |
| Cable grommet 8-85 | ||||
| 007 | 682502-4 | 2.40 | 2.90 | |
| Motor End Housing | ||||
| 008 | 153707-8 | 13.20 | 15.97 | |
| Brush holder 6x9mm * | ||||
| 008A | 643932-4 | 3.60 | 4.36 | |
| Brush holder cap | ||||
| 009 | 643550-8 | 1.20 | 1.45 | |
| Brush Set CB411 RT0702C | ||||
| 010 | 195010-1 | 4.80 | 5.81 | |
| Field | ||||
| 011 | 593148-0 | 30.80 | 37.27 | |
| Ball bearing 627llb | ||||
| 012 | 210025-8 | 3.60 | 4.36 | |
| Insulation ring | ||||
| 013 | 681614-0 | 1.00 | 1.21 | |
| Screw M4X70 * | ||||
| 014 | 911596-5 | 1.20 | 1.45 | |
| Armature | ||||
| 015 | 511918-5 | 72.60 | 87.85 | |
| Fan 52 | ||||
| 016 | 241615-6 | 8.40 | 10.16 | |
| Ball bearing 6002llu | ||||
| 017 | 211223-7 | 10.80 | 13.07 | |
| Spring Washer 23 | ||||
| 018 | 253905-5 | 1.00 | 1.21 | |
| Motor Housing | ||||
| 019 | 414567-6 | 17.60 | 21.30 | |
| Rubber Pin 4 | ||||
| 020 | 263014-2 | 1.00 | 1.21 | |
| Switch holder 3705 * | ||||
| 021 | 410069-0 | 2.40 | 2.90 | |
| Switch Sw-90 | ||||
| 022 | 651467-1 | 18.70 | 22.63 | |
| Capacitor 0,1uf | ||||
| 023 | 645105-5 | 3.60 | 4.36 | |
| Screw 5x33 | ||||
| 024 | 251890-6 | 8.40 | 10.16 | |
| SPANTANG 6MM KANTENFREES | ||||
| 025 | 763607-0 | 3.00 | 3.63 | |
| No information available, not orderable | ||||
| 026 | 763606-2 | |||
| Gear assistant guide | ||||
| 027 | 226217-9 | 1.20 | 1.45 | |
| Screw 4X10 | ||||
| 028 | 911114-9 | 1.00 | 1.21 | |
| Shoe Sa | ||||
| 029 | 152334-8 | 19.80 | 23.96 | |
| Wing nut M5 * | ||||
| 030 | 934201-7 | 1.00 | 1.21 | |
| Spring washer 5MM DLS211 | ||||
| 031 | 253427-5 | 1.00 | 1.21 | |
| Washer 5mm DSP601 A | ||||
| 032 | 253414-4 | 1.00 | 1.21 | |
| Knob screw 6x18 | ||||
| 033 | 251814-2 | 1.20 | 1.45 | |
| Spring Washer 6 A | ||||
| 034 | 253903-9 | 1.00 | 1.21 | |
| Washer 6x12mm | ||||
| 035 | 941151-9 | 1.00 | 1.21 | |
| Washer 5mm DSP601 A | ||||
| 036 | 253414-4 | 1.00 | 1.21 | |
| Wing Nut M5 | ||||
| 037 | 252632-1 | 4.80 | 5.81 | |
| Wing bolt 5x15 | ||||
| 038 | 924216-2 | 1.00 | 1.21 | |
| Spring washer 5MM DLS211 | ||||
| 039 | 253427-5 | 1.00 | 1.21 | |
| Lock washer 5 | ||||
| 040 | 253807-5 | 1.00 | 1.21 | |
| Trim shoe 3704 * | ||||
| 041 | 414304-8 | 13.20 | 15.97 | |
| Washer 8 | ||||
| 042 | 253022-1 | 1.00 | 1.21 | |
| Bolt 5x25 | ||||
| 043 | 923241-0 | 1.00 | 1.21 | |
