Here you will find all available parts and drawings of the 'Makita 3608B'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita 3608B
Spare parts list of model Makita 3608B
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Rivet 0,5 | ||||
| 001-1 | 953106-2 | 0.83 | 1.00 | |
| Nameplate 3608B | ||||
| 002 | 815094-0 | 2.58 | 3.12 | |
| No information available, not orderable | ||||
| 003 | 156964-7 | |||
| Brush Holder | ||||
| 004 | 643601-7 | 1.67 | 2.02 | |
| Brush Set CB-106 M3601 A | ||||
| 005-1 | 194976-2 | 4.45 | 5.38 | |
| No information available, not orderable | ||||
| 006 | 411471-0 | |||
| Rubber Pin 4 | ||||
| 007-1 | 263014-2 | 0.83 | 1.00 | |
| Screw 4x35 | ||||
| 008 | 911163-6 | 0.83 | 1.00 | |
| No information available, not orderable | ||||
| 009 | 528763-1 | |||
| Insulation terminal | ||||
| 009C10 | 654038-3 | 0.83 | 1.00 | |
| No information available, not orderable | ||||
| 010 | 411472-8 | |||
| Washer 14 | ||||
| 011 | 253192-6 | 0.83 | 1.00 | |
| No information available, not orderable | ||||
| 012 | 211033-2 | |||
| Insulation ring | ||||
| 013 | 681613-2 | 0.83 | 1.00 | |
| No information available, not orderable | ||||
| 014 | 911280-2 | |||
| No information available, not orderable | ||||
| 015 | 512618-0 | |||
| Fan 66 * | ||||
| 016 | 241627-9 | 12.19 | 14.75 | |
| Ball Bearing 6003ddw | ||||
| 017 | 210301-0 | 5.80 | 7.02 | |
| Rubber pen 6 | ||||
| 018 | 263005-3 | 0.83 | 1.00 | |
| No information available, not orderable | ||||
| 019 | 152217-2 | |||
| Spantang 8mm bovenfrees | ||||
| 020 | 763618-5 | 4.00 | 4.84 | |
| Spanmoer bovenfrees | ||||
| 021 | 763615-1 | 5.00 | 6.05 | |
| Screw 4x25 | ||||
| 022 | 911146-6 | 0.83 | 1.00 | |
| No information available, not orderable | ||||
| 023 | 666066-6 | |||
| Cable grommet 8-85 | ||||
| 024 | 682502-4 | 1.67 | 2.02 | |
| Clamp Bracket | ||||
| 025 | 687001-1 | 0.83 | 1.00 | |
| Screw 4X18 | ||||
| 026 | 911133-5 | 0.83 | 1.00 | |
| Capacitor 0,1uf | ||||
| 027 | 645105-5 | 2.71 | 3.28 | |
| Switch Sw-85 | ||||
| 028 | 651232-8 | 5.71 | 6.91 | |
| No information available, not orderable | ||||
| 029 | 152211-4 | |||
| Rubber Pin 4 | ||||
| 030 | 263002-9 | 0.83 | 1.00 | |
| Hex Nut M6 | ||||
| 031 | 931302-2 | 0.83 | 1.00 | |
| Base Sole 3608B | ||||
| 032 | 411470-2 | 12.53 | 15.16 | |
| No information available, not orderable | ||||
| 033 | 411473-6 | |||
| Washer 6x12mm | ||||
| 034 | 941151-9 | 0.83 | 1.00 | |
| Screw m6x10 | ||||
| 035 | 251870-2 | 2.71 | 3.28 | |
| Screw 5x10 | ||||
| 036 | 911209-8 | 0.83 | 1.00 | |
| No information available, not orderable | ||||
| 037 | 911207-2 | |||
