Here you will find all available parts and drawings of the 'Makita 1902'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Makita 1902
Spare parts list of model Makita 1902
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Screw 4x16 A | ||||
| 001 | 911526-6 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 002 | 152122-3 | |||
| No longer available, no replacement | ||||
| 002A | 152122-3 | |||
| Knob 46 | ||||
| 003 | 271231-0 | 3.60 | 4.36 | |
| No information available, not orderable | ||||
| 004 | 812004-8 | |||
| Ring 10 1902 * | ||||
| 005 | 253796-4 | 1.20 | 1.45 | |
| Washer 10x1.6mm 1901/02 | ||||
| 005-1 | 941251-5 | 1.00 | 1.21 | |
| Frame 1902 * | ||||
| 006 | 159983-2 | 41.80 | 50.58 | |
| Brush holder * | ||||
| 006A | 643556-6 | 3.60 | 4.36 | |
| No information available, not orderable | ||||
| 007 | 859017-8 | |||
| Cable grommet 8-85 | ||||
| 008 | 682502-4 | 2.40 | 2.90 | |
| Cable grommet 8-85 | ||||
| 008A | 682502-4 | 2.40 | 2.90 | |
| Power cord 2x1.00 2.2mtr | ||||
| 009 | 665383-1 | 10.80 | 13.07 | |
| No information available, not orderable | ||||
| 009A | 666066-6 | |||
| Clamp Bracket | ||||
| 010 | 687053-2 | 1.00 | 1.21 | |
| Clamp Bracket | ||||
| 010 | 687124-5 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 010A | 687063-9 | |||
| Screw 4X18 | ||||
| 011 | 911133-5 | 1.00 | 1.21 | |
| Switch | ||||
| 012 | 651239-4 | 8.40 | 10.16 | |
| Switch | ||||
| 012B | 651239-4 | 8.40 | 10.16 | |
| Handle Cover | ||||
| 013 | 411170-4 | 8.40 | 10.16 | |
| Screw 4x25 | ||||
| 014 | 911148-2 | 1.00 | 1.21 | |
| Ball bearing 6000llb | ||||
| 015 | 211061-7 | 8.40 | 10.16 | |
| Retaining Ring E-9 | ||||
| 016 | 961015-1 | 1.00 | 1.21 | |
| Fan 52 | ||||
| 017 | 241510-0 | 2.40 | 2.90 | |
| Armature | ||||
| 018 | 511938-9 | 48.40 | 58.56 | |
| Insulation ring | ||||
| 019 | 681614-0 | 1.00 | 1.21 | |
| Ball bearing 627llb | ||||
| 020 | 210025-8 | 3.60 | 4.36 | |
| Field | ||||
| 021 | 599314-7 | 29.70 | 35.94 | |
| Stator spring Cb 9 | ||||
| 021A | 654018-9 | 1.20 | 1.45 | |
| Clamping bushing for statorv. 1.25mm | ||||
| 021B | 654501-6 | 0.83 | 1.00 | |
| Field | ||||
| 021E | 599314-7 | 29.70 | 35.94 | |
| Screw 4x16 A | ||||
| 022 | 911526-6 | 1.00 | 1.21 | |
| Intermediate Plate | ||||
| 023 | 411153-4 | 1.20 | 1.45 | |
| CARBON BRUSH SET CB-51 A | ||||
| 024 | 194963-1 | 3.12 | 3.78 | |
| Brush holder cap | ||||
| 025 | 643550-8 | 1.20 | 1.45 | |
| Compression Spring 18 | ||||
| 026 | 231004-3 | 1.20 | 1.45 | |
| Rubber Gasket | ||||
| 027 | 421007-7 | 2.40 | 2.90 | |
| Fore sole 1902 | ||||
| 028 | 316963-3 | 19.80 | 23.96 | |
| Screw 5x18 | ||||
| 029 | 911230-7 | 1.20 | 1.45 | |
| Sole plate 1902 * | ||||
| 030 | 316964-1 | 23.10 | 27.95 | |
| Ball Bearing 608Zz A | ||||
| 031 | 210046-0 | 1.20 | 1.45 | |
| Chisel roller | ||||
| 032 | 161061-6 | 26.40 | 31.94 | |
| Screw 4X55 | ||||
| 033 | 911586-8 | 1.20 | 1.45 | |
| Bearing sheet | ||||
| 034 | 152565-9 | 10.80 | 13.07 | |
| Screw 4x25 | ||||
| 035 | 911148-2 | 1.00 | 1.21 | |
| Screw 4x25 | ||||
| 035-1A | 911148-2 | 1.00 | 1.21 | |
| Screw 4x25 | ||||
| 035-1B | 911148-2 | 1.00 | 1.21 | |
| Screw 4x20 | ||||
| 035A | 911138-5 | 1.00 | 1.21 | |
| Belt Pulley 4-18L 1902 * | ||||
| 036 | 222145-6 | 4.80 | 5.81 | |
| Belt Pulley 4-18L 1902 * | ||||
| 036-1 | 222145-6 | 4.80 | 5.81 | |
| Guard | ||||
| 037 | 411019-8 | 3.60 | 4.36 | |
| Rubber Pin 4 | ||||
| 038 | 263002-9 | 1.00 | 1.21 | |
| Screw 4x25 | ||||
| 039 | 911148-2 | 1.00 | 1.21 | |
| V-belt 4-241 | ||||
| 040 | 225071-8 | 8.40 | 10.16 | |
| Belt Pulley 4-38l | ||||
| 041 | 222146-4 | 8.40 | 10.16 | |
| Belt Pulley 4-38l | ||||
| 041-1 | 222146-4 | 8.40 | 10.16 | |
| Ball bearing 6000rd | ||||
| 042 | 211062-5 | 4.80 | 5.81 | |
| Rubber Pin 4 | ||||
| 043 | 263002-9 | 1.00 | 1.21 | |
| HM WISSELBEITELSET 82MM | ||||
| 044 | D-07951 | 8.00 | 9.68 | |
| Adjustment plate | ||||
| 045 | 347027-2 | 4.56 | 5.52 | |
| No information available, not orderable | ||||
| 046 | 251246-3 | |||
| Chisel Clamp Set | ||||
| 047 | 187679-5 | 10.80 | 13.07 | |
| Chisel Clamp Set | ||||
| 047-1 | 187679-5 | 10.80 | 13.07 | |
| Flange bolt M6x17 | ||||
| 048 | 251609-3 | 1.00 | 1.21 | |
