Here you will find all available parts and drawings of the 'Hikoki UC18YSL3'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Hikoki UC18YSL3
Spare parts list of model Hikoki UC18YSL3
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Brand Label | ||||
| *11 | 339340 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| *16 | 500548Z | |||
| SNOER UC18YSL3 (OUD 500506Z) | ||||
| *16A | 500551Z | 3.18 | 3.85 | |
| Tapping Screw (w/flange) D2x8 (black) | ||||
| *2 | 339341 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| *5A | 379440 | |||
| Case (a) | ||||
| 1 | 338710 | 7.35 | 8.89 | |
| Case (a) | ||||
| 1A | 338710 | 7.35 | 8.89 | |
| Tapping Screw (w/flange) D2x8 (black) | ||||
| 2 | 339341 | 1.04 | 1.26 | |
| Led-switch Pcb | ||||
| 3 | 339339 | 2.85 | 3.45 | |
| LED PCB (OUD 339339) | ||||
| 3A | 382067 | 2.22 | 2.69 | |
| No longer available, no replacement | ||||
| 4 | 338726 | |||
| Pcb Assembly (Europe, Aus, Asia) Includ.4 | ||||
| 5 | 338721 | 43.73 | 52.91 | |
| PRINTED CIRCUITBOARD (OUD 379439) | ||||
| 5B | 382064 | 46.48 | 56.24 | |
| Air Filter | ||||
| 6 | 338725 | 1.35 | 1.63 | |
| Case (b) | ||||
| 7 | 338712 | 2.40 | 2.90 | |
| No information available, not orderable | ||||
| 7A | 379442 | |||
| Tapping Screw (w/flange) D3x18 | ||||
| 8 | 326358 | 1.20 | 1.45 | |
| TP. TORX SCHROEF D3X18 | ||||
| 8A | 376623 | 1.00 | 1.21 | |
| Rubber (a) | ||||
| 9 | 338717 | 1.04 | 1.26 | |
| Brand Label | ||||
| 11 | 339340 | 1.04 | 1.26 | |
| Cover | ||||
| 12 | 338715 | 1.35 | 1.63 | |
| Air Duct | ||||
| 14 | 338716 | 1.35 | 1.63 | |
| Tp Tapping Screw D3x8 | ||||
| 15 | 327174 | 1.65 | 2.00 | |
| Cord | ||||
| 16 | 500506Z | 3.30 | 3.99 | |
| Usb Cap | ||||
| 17 | 338718 | 1.04 | 1.26 | |
| Usb Pcb (b) | ||||
| 18 | 339338 | 1.95 | 2.36 | |
| USB PCB (B) (OUD 339338) | ||||
| 18A | 382066 | 2.22 | 2.69 | |
| Fan | ||||
| 19 | 338724 | 6.15 | 7.44 | |
| No information available, not orderable | ||||
| 19A | 379444 | |||
| USB PCB (A) (OUD 339337) | ||||
| 20A | 382065 | 15.12 | 18.30 | |
| Cushion | ||||
| 21A | 370493 | 1.65 | 2.00 | |
| Ferrite Core | ||||
| 22 | 339342 | 1.20 | 1.45 | |
