Here you will find all available parts and drawings of the 'Hikoki RP3608DB'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Hikoki RP3608DB
Spare parts list of model Hikoki RP3608DB
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Earth Chain | ||||
| *17 | 325870 | 1.65 | 2.00 | |
| Caster D50 | ||||
| *19 | 325858 | 6.75 | 8.17 | |
| Caster D50 (w/stopper) | ||||
| *22 | 325859 | 7.05 | 8.53 | |
| Tapping Screw (w/flange) D4x30 (black) | ||||
| *28 | 305490 | 1.04 | 1.26 | |
| Machine screw M4x10 (10 pieces) (OLD 949216Z) | ||||
| *8 | 949216 | 1.05 | 1.27 | |
| POWDER FILTER 8-15L | ||||
| 1 | 337460 | 43.73 | 52.91 | |
| POWDER FILTER (A) NEW | ||||
| 1 | 377775 | 20.18 | 24.42 | |
| TEXTILE FILTER | ||||
| 2 | 337462 | 6.60 | 7.99 | |
| CLOTH FILTER NEW | ||||
| 2 | 377777 | 4.38 | 5.30 | |
| FILTER DAMPER NEW | ||||
| 3 | 377776 | 11.99 | 14.51 | |
| FILTER DAMPER | ||||
| 3 | 337463 | 8.25 | 9.98 | |
| PRE FILTER (D) NEW | ||||
| 4A | 377774 | 34.82 | 42.13 | |
| Hex. Cap Nut M4 | ||||
| 5 | 311839 | 1.05 | 1.27 | |
| Spring Washer M4 (10 pieces) | ||||
| 6 | 949453 | 1.05 | 1.27 | |
| Washer M4 (10 Pcs.) | ||||
| 7 | 949423 | 1.05 | 1.27 | |
| Machine Screw M4x14 (10 Pcs.) | ||||
| 8 | 949218 | 1.05 | 1.27 | |
| TANK (8L) NEW | ||||
| 9 | 377770 | 20.08 | 24.30 | |
| Cap Nut M8 | ||||
| 10 | 975597 | 1.05 | 1.27 | |
| Bolt Washer M8 (10 Pcs.) | ||||
| 11 | 949433 | 1.05 | 1.27 | |
| Hose Joint | ||||
| 12 | 337451 | 5.55 | 6.72 | |
| Hose Stopper | ||||
| 13 | 321014 | 1.65 | 2.00 | |
| Joint Cover (a) | ||||
| 14 | 337449 | 2.10 | 2.54 | |
| JOINT COVER PACKING D.62 (OLD 339182) | ||||
| 15A | 377772 | 1.50 | 1.82 | |
| Bumper | ||||
| 16 | 337446 | 11.55 | 13.98 | |
| No information available, not orderable | ||||
| 17 | 329872 | |||
| Nut M4 (10 Pieces) | ||||
| 18 | 949554 | 1.05 | 1.27 | |
| Caster (d50) | ||||
| 19 | 337438 | 2.55 | 3.09 | |
| No information available, not orderable | ||||
| 20 | 338453 | |||
| CASTER HOLDER | ||||
| 21 | 338454 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| 22 | 337439 | |||
| SPECIAL NUT | ||||
| 23 | 373590 | 2.70 | 3.27 | |
| Washer (1) | ||||
| 24 | 374772 | 1.04 | 1.26 | |
| FLANGE COLLAR NEW | ||||
| 24 | 377773 | 1.00 | 1.21 | |
| Poly Guide (a) | ||||
| 25 | 337452 | 1.65 | 2.00 | |
| Earth Plate | ||||
| 26 | 337454 | 1.04 | 1.26 | |
| Internal Wire For Model (s) | ||||
| 27 | 329183 | 3.15 | 3.81 | |
| Tapping Screw (w/flange) D4x25 (black) | ||||
| 28 | 307028 | 1.05 | 1.27 | |
| SPECIAL BOLT | ||||
| 29 | 373589 | 1.80 | 2.18 | |
| P-tite Screw D4x20 Since 7.2016 | ||||
| 29 | 994806 | 1.04 | 1.26 | |
| Clamping Saddle | ||||
| 30 | 337455 | 4.80 | 5.81 | |
| Machine Screw M4x16 (10 Pcs.) | ||||
| 31 | 949219 | 1.20 | 1.45 | |
| SLEEVE (B) ID28 | ||||
| 32 | 338478 | 1.35 | 1.63 | |
| SLEEVE (B) ID28 NEW | ||||
| 32 | 377781 | 1.00 | 1.21 | |
| HOSE ASS'Y ID28 (W/HOSE COVER) (OLD 374775) | ||||
| 33A | 377779 | 41.14 | 49.78 | |
| CLICK RING (FOR D28) | ||||
| 34 | 337515 | 1.05 | 1.27 | |
| SCREW RING (ID 28) | ||||
| 35 | 337514 | 1.05 | 1.27 | |
| SCREW RING (B) ID 28 NEW | ||||
| 35 | 377780 | 1.00 | 1.21 | |
| Sleeve (A) ID38 | ||||
| 36 | 374776 | 1.20 | 1.45 | |
| Motor Ass'y Includ.49,50 | ||||
| 37 | 373569 | 121.55 | 147.08 | |
| Bearing Bushing Since 6.1996 | ||||
| 38A | 376160 | 2.40 | 2.90 | |
| STATOR FET PCB | ||||
| 39 | 341051 | 56.10 | 67.88 | |
| FAN BASE | ||||
| 40 | 373573 | 7.20 | 8.71 | |
| ROTOR | ||||
| 41 | 361091 | 43.31 | 52.41 | |
| Ball Bearing 608vv | ||||
| 42 | 333945 | 1.80 | 2.18 | |
| BEARING HOLDER | ||||
| 43 | 339180 | 1.04 | 1.26 | |
| Flange Washer | ||||
| 44 | 339174 | 1.05 | 1.27 | |
| FAN | ||||
| 45 | 339166 | 3.00 | 3.63 | |
| CASING | ||||
| 46 | 339177 | 3.00 | 3.63 | |
| SPECIAL WASHER | ||||
| 47 | 339178 | 1.04 | 1.26 | |
| LOCK NUT M8 | ||||
| 48 | 339175 | 1.04 | 1.26 | |
| Support Ring (b) Since 4.2012 | ||||
| 49 | 334977 | 13.75 | 16.64 | |
| Silent filter (H) | ||||
| 50 | 374771 | 1.35 | 1.63 | |
| No information available, not orderable | ||||
| 51 | 337475 | |||
| MOTOR BASE ASS'Y | ||||
| 52 | 373897 | 22.55 | 27.29 | |
| Tapping Screw (w/flange) D4x45 (black) | ||||
| 53 | 301815 | 1.05 | 1.27 | |
| GUARD PLATE | ||||
| 54 | 338484 | 1.20 | 1.45 | |
| Screw (plastic Tie) D4x16 | ||||
| 55 | 994810 | 1.05 | 1.27 | |
| Tapping Screw (w/flange) D4x20 (black) | ||||
| 56 | 301653 | 1.04 | 1.26 | |
| PANEL SHEET (D) | ||||
| 57 | 373902 | 4.80 | 5.81 | |
| SWITCH HOLDER | ||||
| 58A | 373901 | 24.34 | 29.45 | |
| SWITCH COVER | ||||
| 59 | 373576 | 1.04 | 1.26 | |
| SWITCH PACKING | ||||
| 60 | 373578 | 1.04 | 1.26 | |
| SWITCH | ||||
| 61 | 373577 | 13.80 | 16.70 | |
| No information available, not orderable | ||||
| 63 | 370077 | |||
| TAPPING SCREW D3X12 (W/FLANGE) | ||||
| 64 | 372288 | 1.20 | 1.45 | |
| CONTROLLER MAIN ASS'Y | ||||
| 65B | 373895 | 168.16 | 203.48 | |
| Plug Connector | ||||
| 66 | 374773 | 1.05 | 1.27 | |
| No information available, not orderable | ||||
| 67 | 371750 | |||
| BATTERY GUARD ASS'Y | ||||
| 68 | 373572 | 20.76 | 25.12 | |
| CLAMP LEVER (A) | ||||
| 69 | 373613 | 1.04 | 1.26 | |
| CLAMP SPRING | ||||
| 70 | 373610 | 1.04 | 1.26 | |
| CORD COVER | ||||
| 71 | 373607 | 1.20 | 1.45 | |
| HANDLE | ||||
| 72 | 373604 | 6.45 | 7.80 | |
| BATTERY TERMINAL HOLDER | ||||
| 73 | 373605 | 3.30 | 3.99 | |
| HEAD COVER ASS'Y | ||||
| 74 | 373896 | 21.59 | 26.12 | |
| HEAD COVER PACKING (A) | ||||
| 76 | 373898 | 2.25 | 2.72 | |
| HEAD COVER PACKING (C) | ||||
| 77 | 373602 | 1.04 | 1.26 | |
| HEAD COVER PACKING (D) | ||||
| 78 | 373603 | 1.04 | 1.26 | |
| HEAD COVER PACKING (C) NEW | ||||
| 79 | 373601 | 1.05 | 1.27 | |
| HEAD COVER PACKING (B) NEW | ||||
| 80 | 373600 | 1.35 | 1.63 | |
| Silent Filter (d) | ||||
| 81 | 373619 | 1.20 | 1.45 | |
| SILENT FILTER (C) | ||||
| 82 | 373616 | 1.04 | 1.26 | |
| SILENT FILTER (B) | ||||
| 83 | 373615 | 1.04 | 1.26 | |
| SILENT FILTER (L) | ||||
| 84 | 373626 | 1.20 | 1.45 | |
| Motor Cover (1) | ||||
| 85 | 373597 | 17.60 | 21.30 | |
| SILENT FILTER (F) NEW | ||||
| 86 | 373623 | 1.04 | 1.26 | |
| Silent Filter (e) | ||||
| 87 | 373621 | 1.04 | 1.26 | |
| MOTOR PACKING (A) | ||||
| 88 | 373596 | 3.45 | 4.17 | |
| SILENT FILTER (J) | ||||
| 89 | 373625 | 1.04 | 1.26 | |
| SILENT FILTER (M) | ||||
| 90 | 373624 | 1.04 | 1.26 | |
| SILENT FILTER (C) | ||||
| 91 | 373617 | 1.04 | 1.26 | |
| Silent Filter (d) | ||||
| 92 | 373618 | 1.04 | 1.26 | |
| SILENT FILTER (A) | ||||
| 93 | 373614 | 1.04 | 1.26 | |
| Silent Filter (e) | ||||
| 94 | 373620 | 1.04 | 1.26 | |
| SILENT FILTER (F) | ||||
| 95 | 373622 | 1.04 | 1.26 | |
| HOUSING PACKING (A) | ||||
| 96 | 373570 | 1.04 | 1.26 | |
| Tapping Screw (w/flange) D4x35 (black) | ||||
| 97 | 303694 | 1.04 | 1.26 | |
| Tapping Screw (w/flange) D4x20 (black) | ||||
| 98 | 301653 | 1.04 | 1.26 | |
| Housing | ||||
| 99 | 338902 | 6.30 | 7.62 | |
| No information available, not orderable | ||||
| 100 | 377081 | |||
| No information available, not orderable | ||||
| 101 | 377080 | |||
| TANK ASS'Y (8L) (OLD 373591) | ||||
| 102 | 378011 | 43.67 | 52.84 | |
| TOOL HOLDER | ||||
| 501 | 373588 | 9.30 | 11.25 | |
| Battery Cover | ||||
| 503 | 329897 | 1.80 | 2.18 | |
| No information available, not orderable | ||||
| 504A | 375679 | |||
| REDUCER (A) | ||||
| 505 | 337524 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| 506 | 337527 | |||
| JOINT (H) NEW | ||||
| 510 | 377785 | 1.00 | 1.21 | |
| Handle with air control | ||||
| 511 | 373581 | 4.50 | 5.44 | |
| No information available, not orderable | ||||
| 512 | 377081 | |||
| No information available, not orderable | ||||
| 513 | 377782 | |||
| No information available, not orderable | ||||
| 514 | 337523 | |||
| TOOL BAG 410X330 NEW | ||||
| 515 | 66A2942 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 516 | 337519 | |||
