Here you will find all available parts and drawings of the 'Hikoki PF-3300'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Hikoki PF-3300
Spare parts list of model Hikoki PF-3300
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Spark Plug Cap Ass'y Till G165840 | ||||
| 1 | 6687468 | 2.31 | 2.80 | |
| No information available, not orderable | ||||
| 2A | 6699323 | |||
| Cylinder Set (old 001-07250-90) | ||||
| 3 | 6685491 | 60.35 | 73.02 | |
| Hex. Hole Bolt M5x16/s | ||||
| 4 | 6684903 | 2.15 | 2.60 | |
| Cylinder Gasket | ||||
| 5 | 6685749 | 1.15 | 1.39 | |
| No longer available, no replacement | ||||
| 6 | 6685331 | |||
| Piston Set | ||||
| 7 | 6685898 | 24.20 | 29.28 | |
| Circlip | ||||
| 8 | 6685078 | 1.15 | 1.39 | |
| Piston Pin | ||||
| 9 | 6686008 | 2.31 | 2.80 | |
| Crank Shaft Comp | ||||
| 10 | 6696499 | 67.00 | 81.07 | |
| Woodruff Key 3x13x4.5 Till B023800 | ||||
| 11 | 6684899 | 2.15 | 2.60 | |
| Woodruff Key 3x13x4.5 Till B023800 | ||||
| 12 | 6684899 | 2.15 | 2.60 | |
| No information available, not orderable | ||||
| 13 | 6687876 | |||
| Hex. Hole Bolt 4x15/ps | ||||
| 14 | 6684682 | 2.15 | 2.60 | |
| Hex. Hole Bolt M4x18/ws Till H124040 | ||||
| 14A | 6684599 | 2.15 | 2.60 | |
| Hex. Hole Bolt M4x18/ws Till H124040 | ||||
| 15 | 6684599 | 2.15 | 2.60 | |
| Washer T1.6 | ||||
| 15 | 6684600 | 2.15 | 2.60 | |
| Hex. Hole Bolt 4x15/ps | ||||
| 15 | 6684682 | 2.15 | 2.60 | |
| Ignition Coil Ass'y For (p),(lp),(sp),(slp) | ||||
| 16 | 6699773 | 18.00 | 21.78 | |
| No information available, not orderable | ||||
| 17 | 6687889 | |||
| Rubber Cap | ||||
| 18 | 6684602 | 2.15 | 2.60 | |
| Washer T1.6 | ||||
| 19 | 6684600 | 2.15 | 2.60 | |
| Gear Shaft Shim 0.20 | ||||
| 31 | 6684604 | 2.15 | 2.60 | |
| Gear Shaft Shim 0.30 | ||||
| 31 | 6684605 | 2.15 | 2.60 | |
| Gear shaft shim 0.10 (old 330-00200-21) | ||||
| 31 | 6689177 | 1.15 | 1.39 | |
| Gear shaft shim 0.15 (old 330-00200-22) | ||||
| 31 | 6689178 | 1.15 | 1.39 | |
| Magneto Rotor Comp. | ||||
| 32 | 6687375 | 20.11 | 24.34 | |
| Hex. Nut M8 | ||||
| 33 | 6684612 | 2.15 | 2.60 | |
| Ring | ||||
| 34 | 6695184 | 1.15 | 1.39 | |
| No information available, not orderable | ||||
| 35 | 6699351 | |||
| Crank Case Ass'y Since J014621 | ||||
| 35A | 6699279 | 29.80 | 36.06 | |
| Oil Seal | ||||
| 36 | 6684607 | 4.29 | 5.19 | |
| Ball Bearing 6001 C3 | ||||
| 37 | 6684608 | 3.80 | 4.60 | |
| No information available, not orderable | ||||
| 38 | 6686723 | |||
| Crank Case Gasket Since J014621 | ||||
| 38A | 6699280 | 1.04 | 1.26 | |
| Hex. Hole Bolt M5x16/s | ||||
| 39 | 6684903 | 2.15 | 2.60 | |
| Hex. Hole Bolt M5x16/s | ||||
| 39A | 6684903 | 2.15 | 2.60 | |
| Bolt Washer M8 | ||||
| 40 | 6684611 | 2.15 | 2.60 | |
| Starter Pulley Ass'y | ||||
| 41 | 6693394 | 7.59 | 9.18 | |
| Starter Pawl | ||||
| 42 | 6693299 | 2.31 | 2.80 | |
| Starter Pawl Spring | ||||
| 43 | 6693345 | 2.31 | 2.80 | |
| Hex. Hole Bolt 4x18ws Till H124040 | ||||
| 44 | 6695508 | 1.15 | 1.39 | |
| Inlet Manifold Gasket | ||||
| 61 | 6689895 | 1.15 | 1.39 | |
| Insulator Set | ||||
| 62 | 6689972 | 6.28 | 7.59 | |
| Hex. Hole Bolt M5x25ws | ||||
| 63 | 6695515 | 1.15 | 1.39 | |
| Carburetor Packing | ||||
| 64 | 6684616 | 2.15 | 2.60 | |
| Carburetor Packing | ||||
| 65 | 6684616 | 2.15 | 2.60 | |
| Choke Plate 2.0 | ||||
| 65 | 6691276 | 1.15 | 1.39 | |
| Choke Plate 2.0 | ||||
| 66 | 6691276 | 1.15 | 1.39 | |
| Cleaner Sponge | ||||
| 67 | 6690365 | 1.15 | 1.39 | |
| Cleaner Sponge | ||||
| 68 | 6690365 | 1.15 | 1.39 | |
| No information available, not orderable | ||||
| 69 | 6690402 | |||
| Cover Fixing Bolt Comp. | ||||
| 70 | 6698730 | 3.15 | 3.81 | |
| Hex. Hole Bolt 5x55 | ||||
| 70 | 6695056 | 1.15 | 1.39 | |
| S.washer 5 | ||||
| 71 | 6684662 | 2.15 | 2.60 | |
| Hex. Hole Bolt 5x55 | ||||
| 71 | 6695056 | 1.15 | 1.39 | |
| Small Washer 5 | ||||
| 72 | 6684864 | 2.15 | 2.60 | |
| Carburetor Set Wyj318 | ||||
| 73 | 6690465 | 58.39 | 70.65 | |
| Choke Control Lever | ||||
| 74 | 6691239 | 1.15 | 1.39 | |
| Tank F T | ||||
| 75A | 6699336 | 24.20 | 29.28 | |
| Collar 5.8 Till G103930 | ||||
| 76 | 6692244 | 1.15 | 1.39 | |
| Return Grommet Till 7.2014 | ||||
| 77 | 6697846 | 1.04 | 1.26 | |
| Return Grommet Till 7.2014 | ||||
| 77A | 6697846 | 1.04 | 1.26 | |
| No longer available, no replacement | ||||
| 78 | 6684880 | |||
| No information available, not orderable | ||||
| 79 | 6684620 | |||
| Clip,6.3 Dia. | ||||
| 80 | 6684619 | 2.15 | 2.60 | |
| Clip D6 | ||||
| 80 | 6685198 | 1.15 | 1.39 | |
| No longer available, no replacement | ||||
| 81 | 6684618 | |||
| SHIELD TUBE ASS'Y | ||||
| 81A | 6697939 | 15.07 | 18.23 | |
| Hex. Hole Bolt M5x25/s | ||||
| 82 | 6684709 | 2.15 | 2.60 | |
| Hex. Hole Bolt 5x16/ps | ||||
| 83 | 6695504 | 1.15 | 1.39 | |
| Tank Cap D Ass'y Since K032881 | ||||
| 84 | 6691748 | 7.59 | 9.18 | |
| Tap Screw 4x14 P | ||||
| 85 | 6695280 | 1.15 | 1.39 | |
| Ring | ||||
| 86 | 6685070 | 1.15 | 1.39 | |
| Washer M5 (black) | ||||
| 87 | 6684918 | 2.15 | 2.60 | |
| Tank Fixing Collar | ||||
| 88 | 6692183 | 1.15 | 1.39 | |
| S.washer 5 | ||||
| 89 | 6684662 | 2.15 | 2.60 | |
| Cylinder Cover Blk | ||||
| 101 | 6685689 | 5.78 | 6.99 | |
| Hex. Hole Bolt 5x16/ps | ||||
| 102 | 6695504 | 1.15 | 1.39 | |
| Hex.hole Bolt 6x65 (old 990-51060-653) | ||||
| 103 | 6695067 | 1.15 | 1.39 | |
| Ring | ||||
| 104 | 6684639 | 2.15 | 2.60 | |
| No information available, not orderable | ||||
| 105 | 6692572 | |||
| Tail Pipe Set (old 734-07250-91) New | ||||
| 106 | 6692714 | 3.00 | 3.63 | |
| Screw M4x8/ws | ||||
| 107 | 6684651 | 2.15 | 2.60 | |
| No information available, not orderable | ||||
| 108 | 6692701 | |||
| No longer available, no replacement | ||||
| 109 | 6692888 | |||
| Muffler Protector Black (old 738-07250-20) | ||||
| 110 | 6692811 | 10.40 | 12.58 | |
| Heat Shield | ||||
| 110 | 6687263 | 4.45 | 5.38 | |
| Muffler Protector Black (old 738-07250-20) | ||||
| 111 | 6692811 | 10.40 | 12.58 | |
| Screw 4x18/ps Since H124041 | ||||
| 111 | 6695375 | 1.15 | 1.39 | |
| Plug Cover For (p),(lp),(sp) | ||||
| 112 | 6688351 | 2.31 | 2.80 | |
| Hex. Hole Bolt 4x18ws Till H124040 | ||||
| 112 | 6695508 | 1.15 | 1.39 | |
| Plug Cover For (p),(lp),(sp) | ||||
| 113 | 6688351 | 2.31 | 2.80 | |
| Ring | ||||
| 113 | 6689645 | 1.15 | 1.39 | |
| Clutch Arm Comp. | ||||
| 114 | 6688610 | 7.59 | 9.18 | |
| Ring | ||||
| 114 | 6689645 | 1.15 | 1.39 | |
| Clutch Arm Comp. | ||||
| 115 | 6688610 | 7.59 | 9.18 | |
| Clutch Spring | ||||
| 115 | 6689420 | 2.31 | 2.80 | |
| Clutch Spring | ||||
| 116 | 6689420 | 2.31 | 2.80 | |
| Clutch Step Bolt | ||||
| 116 | 6689628 | 2.31 | 2.80 | |
| Clutch Step Bolt | ||||
| 117 | 6689628 | 2.31 | 2.80 | |
| Washer | ||||
| 117 | 6695203 | 1.15 | 1.39 | |
| Clutch Set Ass'y | ||||
| 118 | 6688482 | 12.88 | 15.58 | |
| Hex. Hole Bolt M5x18/ws | ||||
| 118 | 6684647 | 2.15 | 2.60 | |
| Hex. Hole Bolt M5x18/ws | ||||
| 119 | 6684647 | 2.15 | 2.60 | |
| Washer | ||||
| 119 | 6695203 | 1.15 | 1.39 | |
| Fan Housing | ||||
| 120 | 6687023 | 16.64 | 20.13 | |
| Hex. Hole Bolt 4x15/ps | ||||
| 120 | 6684682 | 2.15 | 2.60 | |
| Fan Housing | ||||
| 121 | 6687023 | 16.64 | 20.13 | |
| Primary Cord Grommet | ||||
| 121 | 6688057 | 1.15 | 1.39 | |
| Heat Shield | ||||
| 122 | 6687263 | 4.45 | 5.38 | |
| Primary Cord Grommet | ||||
| 122 | 6688057 | 1.15 | 1.39 | |
| Hex. Hole Bolt 4x15/ps | ||||
| 123 | 6684682 | 2.15 | 2.60 | |
| Recoil Starter Ass'y | ||||
| 141 | 6692969 | 22.24 | 26.91 | |
| Starter Handle | ||||
| 142 | 6693227 | 3.30 | 3.99 | |
| Rope Guide | ||||
| 143 | 6693135 | 3.30 | 3.99 | |
| Recoil Starter Body (old 772-06150-21/6693035) | ||||
| 144 | 6693036 | 10.23 | 12.37 | |
| Recoil Spring | ||||
| 145 | 6693111 | 7.93 | 9.59 | |
| Rope 3.5x890 | ||||
| 146 | 6693157 | 2.31 | 2.80 | |
| Starter Rope Reel (old 774-0162v-20) | ||||
| 147 | 6693057 | 4.45 | 5.38 | |
| Ring | ||||
| 148 | 6693419 | 1.15 | 1.39 | |
| Set Screw | ||||
| 149 | 6693632 | 1.15 | 1.39 | |
| Screw 4x18/ps Since H124041 | ||||
| 150 | 6695375 | 1.15 | 1.39 | |
| Starter Pulley Ass'y | ||||
| 151 | 6693394 | 7.59 | 9.18 | |
| Starter Pawl | ||||
| 152 | 6693299 | 2.31 | 2.80 | |
| Starter Pawl Spring | ||||
| 153 | 6693345 | 2.31 | 2.80 | |
| Pump Body Comp. | ||||
| 161 | 6684879 | 62.16 | 75.22 | |
| Priming Pump Comp. | ||||
| 162 | 6684687 | 16.34 | 19.77 | |
| Diaphragm Cover | ||||
| 163 | 6684688 | 8.58 | 10.38 | |
| Priming Body | ||||
| 164 | 6684689 | 6.44 | 7.79 | |
| Metering Diaphragm Comp. | ||||
| 165 | 6690830 | 11.88 | 14.37 | |
| Diaphragm Gasket | ||||
| 166 | 6684691 | 8.58 | 10.38 | |
| Pump Diaphragm | ||||
| 167 | 6684693 | 8.58 | 10.38 | |
| Pump Gasket (old 577-25100-20) | ||||
| 168 | 6691457 | 7.10 | 8.59 | |
| Main Jet #38.5 (old 599-200bw-38/6691874) | ||||
| 169 | 6696130 | 5.78 | 6.99 | |
| O-RING (old 550-25100-20) | ||||
| 170 | 6684695 | 4.29 | 5.19 | |
| Pump Body Comp. | ||||
| 171 | 6684879 | 62.16 | 75.22 | |
| Stop Ring | ||||
| 171 | 6684696 | 2.15 | 2.60 | |
| Priming Pump Comp. | ||||
| 172 | 6684687 | 16.34 | 19.77 | |
| Swivel | ||||
| 172 | 6684697 | 6.44 | 7.79 | |
| Diaphragm Cover | ||||
| 173 | 6684688 | 8.58 | 10.38 | |
| Throttle Set Screw | ||||
| 173 | 6684870 | 2.15 | 2.60 | |
| Cable Adjuster Stay | ||||
| 174 | 6684873 | 6.44 | 7.79 | |
| Priming Body | ||||
| 174 | 6684689 | 6.44 | 7.79 | |
| Metering Diaphragm Comp. | ||||
| 175 | 6690830 | 11.88 | 14.37 | |
| Lock Nut M6 | ||||
| 175 | 6684872 | 2.15 | 2.60 | |
| Diaphragm Gasket | ||||
| 176 | 6684691 | 8.58 | 10.38 | |
| Cable Adjuster | ||||
| 176 | 6684871 | 4.29 | 5.19 | |
| Pump Diaphragm | ||||
| 177 | 6684693 | 8.58 | 10.38 | |
| Cleaner Packing | ||||
| 177 | 6684875 | 4.29 | 5.19 | |
| Pump Gasket (old 577-25100-20) | ||||
| 178 | 6691457 | 7.10 | 8.59 | |
| Set Screw | ||||
| 178 | 6684699 | 2.15 | 2.60 | |
| Main Jet #38.5 (old 599-200bw-38/6691874) | ||||
| 179 | 6696130 | 5.78 | 6.99 | |
| Thrust Washer | ||||
| 179 | 6684874 | 2.15 | 2.60 | |
| Inlet Screen | ||||
| 180 | 6684700 | 4.29 | 5.19 | |
| O-RING (old 550-25100-20) | ||||
| 180 | 6684695 | 4.29 | 5.19 | |
| Stop Ring | ||||
| 181 | 6684696 | 2.15 | 2.60 | |
| Swivel | ||||
| 182 | 6684697 | 6.44 | 7.79 | |
| Throttle Set Screw | ||||
| 183 | 6684870 | 2.15 | 2.60 | |
| Cable Adjuster Stay | ||||
| 184 | 6684873 | 6.44 | 7.79 | |
| Lock Nut M6 | ||||
| 185 | 6684872 | 2.15 | 2.60 | |
| Cable Adjuster | ||||
| 186 | 6684871 | 4.29 | 5.19 | |
| Cleaner Packing | ||||
| 187 | 6684875 | 4.29 | 5.19 | |
| Set Screw | ||||
| 188 | 6684699 | 2.15 | 2.60 | |
| Thrust Washer | ||||
| 189 | 6684874 | 2.15 | 2.60 | |
| Inlet Screen | ||||
| 190 | 6684700 | 4.29 | 5.19 | |
| No information available, not orderable | ||||
| 501 | 6684764 | |||
| Name Plate Pf-3300 (old 906-07252-20) New | ||||
| 601 | 6694233 | 2.10 | 2.54 | |
