Here you will find all available parts and drawings of the 'Hikoki NV38AB2'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Hikoki NV38AB2
Spare parts list of model Hikoki NV38AB2
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Lock Lever Cover | ||||
| 1 | 880191 | 7.05 | 8.53 | |
| HEX SOCKET HEAD BOLT M5X28 | ||||
| 2 | 878115 | 1.00 | 1.21 | |
| Exhaust Cap | ||||
| 3A | 880200 | 51.15 | 61.89 | |
| Gasket (a) | ||||
| 4 | 880196 | 1.65 | 2.00 | |
| Head Valve Spring | ||||
| 5 | 880190 | 2.55 | 3.09 | |
| O-ring | ||||
| 6 | 878600 | 1.05 | 1.27 | |
| Head Valve (a) | ||||
| 7 | 880410 | 14.70 | 17.79 | |
| Piston Ring | ||||
| 8 | 878596 | 14.70 | 17.79 | |
| Piston O-ring | ||||
| 9 | 880195 | 1.05 | 1.27 | |
| Piston pin | ||||
| 10 | 880188 | 116.74 | 141.25 | |
| Cylinder Gasket | ||||
| 11A | 881103 | 3.60 | 4.36 | |
| Cylinder Ring | ||||
| 12 | 880187 | 4.20 | 5.08 | |
| O-ring (p-32) | ||||
| 13 | 986374 | 1.65 | 2.00 | |
| Cylinder | ||||
| 14 | 881124 | 105.05 | 127.11 | |
| Piston Damper | ||||
| 15 | 880185 | 10.80 | 13.07 | |
| BODY ASSEMBLY | ||||
| 16A | 881127 | 102.63 | 124.18 | |
| WARNING LABEL | ||||
| 17A | 881128 | 1.38 | 1.67 | |
| Retaining Ring (e-type) For D6 Shaft | ||||
| 18 | 955479 | 1.05 | 1.27 | |
| Trigger (a) | ||||
| 20A | 880674 | 11.85 | 14.34 | |
| PUSHING LEVER GUIDE | ||||
| 21 | 880194 | 3.72 | 4.50 | |
| NAIL GUIDE SHIFT | ||||
| 22 | 880161 | 3.06 | 3.70 | |
| O-ring (1ap-3) | ||||
| 23 | 873093 | 1.05 | 1.27 | |
| STOPPER | ||||
| 24 | 880176 | 4.56 | 5.52 | |
| Nose | ||||
| 25 | 881120 | 371.80 | 449.88 | |
| Hex. Socket Hd. Bolt M6x20 (10 Pcs.) | ||||
| 26 | 949660 | 3.30 | 3.99 | |
| Needle Roller | ||||
| 27 | 983545 | 1.05 | 1.27 | |
| Roll Pin D4x14 (10 Pcs.) | ||||
| 28 | 949770 | 2.55 | 3.09 | |
| Feeder Arm | ||||
| 29 | 878132 | 40.84 | 49.41 | |
| Feeder Spring | ||||
| 30 | 878340 | 1.05 | 1.27 | |
| Feed mechanism Nv38ab | ||||
| 31 | 880167 | 35.06 | 42.43 | |
| PUSHING LEVER SPRING | ||||
| 32 | 880204 | 4.56 | 5.52 | |
| Pushing Lever (b) | ||||
| 33 | 880171 | 46.75 | 56.57 | |
| Adjuster (b) | ||||
| 34 | 880383 | 10.20 | 12.34 | |
| ADJUSTMENT SPRING | ||||
| 35 | 880175 | 1.00 | 1.21 | |
| Steel Ball D3.175 (10 Pcs.) | ||||
| 36 | 959148 | 1.05 | 1.27 | |
| Pushing Lever | ||||
| 37 | 881090 | 34.51 | 41.76 | |
| Ring | ||||
| 38 | 880081 | 1.04 | 1.26 | |
| Hex. Socket Hd. Bolt M6x12 (10 Pcs.) | ||||
| 39 | 949657 | 3.00 | 3.63 | |
| Nose Cap (a) | ||||
| 40 | 881092 | 6.45 | 7.80 | |
| Machine Screw M5x20 (black) | ||||
| 41 | 302196 | 1.05 | 1.27 | |
| O-ring (i.d 37.2) | ||||
| 42 | 880183 | 1.05 | 1.27 | |
| Baffle | ||||
| 43 | 880379 | 28.05 | 33.94 | |
| Dust Cap | ||||
| 44 | 872035 | 1.04 | 1.26 | |
| Roll Pin D3x18 (10 Pcs.) | ||||
| 45 | 949518 | 2.40 | 2.90 | |
| Roll Pin D3x25 (10 Pcs.) | ||||
| 46 | 949539 | 2.25 | 2.72 | |
| Steel Ball D3.97 (10 Pcs.) | ||||
| 47 | 959155 | 1.04 | 1.26 | |
| Spring | ||||
| 48 | 982454 | 1.04 | 1.26 | |
| Change Button (b) | ||||
| 49 | 880086 | 23.10 | 27.95 | |
| HEAD VALVE O-RING (I.D.16.8) | ||||
| 50 | 877699 | 1.05 | 1.27 | |
| Valve Bushing (b) | ||||
| 51 | 878881 | 39.74 | 48.08 | |
| O-ring (s-18) | ||||
| 52 | 878885 | 1.05 | 1.27 | |
| O-ring (I.D. 8.8) | ||||
| 53 | 878925 | 1.05 | 1.27 | |
| O-RING (S-4) | ||||
| 54 | 981317 | 1.05 | 1.27 | |
| Valve Piston (b) | ||||
| 55 | 880672 | 32.18 | 38.93 | |
| O-Ring (I.D.11) | ||||
| 56 | 878887 | 1.65 | 2.00 | |
| Plunger Spring | ||||
| 57 | 878884 | 1.65 | 2.00 | |
| Plunger (a) | ||||
| 58 | 880673 | 14.71 | 17.80 | |
| O-RING (I.D.1.8) | ||||
| 59 | 878888 | 1.05 | 1.27 | |
| Valve Bushing (a) | ||||
| 60 | 880671 | 23.65 | 28.62 | |
| O-ring (p-9) | ||||
| 61 | 872645 | 1.65 | 2.00 | |
| No information available, not orderable | ||||
| 62 | 880168 | |||
| O-ring (P-18) | ||||
| 63 | 873570 | 1.35 | 1.63 | |
| SPRING | ||||
| 64 | 880169 | 1.50 | 1.82 | |
| Damper | ||||
| 65 | 877476 | 2.40 | 2.90 | |
| Feed Piston Cover | ||||
| 66 | 880170 | 2.25 | 2.72 | |
| Locking Ring for D24 | ||||
| 67 | 983748 | 1.05 | 1.27 | |
| Magazine Bushing | ||||
| 68 | 880177 | 1.65 | 2.00 | |
| Guide Lock | ||||
| 69 | 878103 | 11.85 | 14.34 | |
| Spring | ||||
| 70 | 880446 | 1.35 | 1.63 | |
| O-ring (p-4) | ||||
| 71 | 874436 | 1.05 | 1.27 | |
| GUIDE | ||||
| 72 | 880162 | 69.52 | 84.12 | |
| Nail Stopper (a) | ||||
| 73 | 880163 | 1.65 | 2.00 | |
| Locking spring | ||||
| 74 | 878575 | 1.05 | 1.27 | |
| Nail Stopper (b) | ||||
| 75 | 880164 | 2.55 | 3.09 | |
| Nail Guide Cover | ||||
| 76 | 880165 | 1.95 | 2.36 | |
| NAIL GUIDE COVER (B) | ||||
| 77 | 880201 | 11.77 | 14.24 | |
| Protective plate Nv38ab | ||||
| 78 | 880166 | 6.75 | 8.17 | |
| Sleeve (b) | ||||
| 79 | 878337 | 3.00 | 3.63 | |
| Nylock Hex. Socket Hd. Bolt M4x10 | ||||
| 80 | 880413 | 1.05 | 1.27 | |
| WARNING LABEL | ||||
| 81 | 880476 | 1.98 | 2.40 | |
| MAGAZINE | ||||
| 82 | 881091 | 8.04 | 9.73 | |
| Nylon Nut M5 | ||||
| 83 | 877371 | 1.05 | 1.27 | |
| Magazine Cover | ||||
| 84 | 881122 | 6.15 | 7.44 | |
| Retaining Ring (e-type) For D3 Shaft Till 6.1998 | ||||
| 85 | 872971 | 1.05 | 1.27 | |
| Hinge Pin (old 878953) | ||||
| 86 | 877152 | 3.60 | 4.36 | |
| MAGAZINE ASSEMBLY | ||||
| 87 | 881121 | 18.64 | 22.55 | |
| GRIP TAPE | ||||
| 88 | 880408 | 11.10 | 13.43 | |
| No information available, not orderable | ||||
| 89A | 888213 | |||
| Warning Label (a) | ||||
| 90 | 883513 | 1.65 | 2.00 | |
| No information available, not orderable | ||||
| 501 | 944459 | |||
| No information available, not orderable | ||||
| 502 | 944458 | |||
| No information available, not orderable | ||||
| 503 | 943277 | |||
| No information available, not orderable | ||||
| 504 | 877153 | |||
| No information available, not orderable | ||||
| 505A | 875769 | |||
| CASE | ||||
| 506 | 878676 | 34.92 | 42.25 | |
| Grease (attolub No.2) 500g | ||||
| 601 | 317918 | 32.18 | 38.93 | |
