Here you will find all available parts and drawings of the 'Hikoki NP18DSL'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Hikoki NP18DSL
Spare parts list of model Hikoki NP18DSL
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Machine Screw (w/washer) M5x20(black) | ||||
| 1 | 329171 | 1.80 | 2.18 | |
| Tapping Screw (w/flange) D3x16 (black) | ||||
| 2 | 313687 | 1.04 | 1.26 | |
| Label (a) | ||||
| 3 | 331185 | 1.80 | 2.18 | |
| Lock Nut M4 (black) | ||||
| 4 | 327002 | 1.80 | 2.18 | |
| Gasket | ||||
| 5 | 331186 | 1.80 | 2.18 | |
| Guide Piece Holder Set | ||||
| 6 | 333987 | 28.46 | 34.44 | |
| Spindle Ass'y | ||||
| 7 | 329158 | 6.75 | 8.17 | |
| Guide Rail | ||||
| 8 | 329160 | 25.03 | 30.28 | |
| Final Gear | ||||
| 9 | 329157 | 7.35 | 8.89 | |
| Retaining Ring (d8) | ||||
| 10 | 329159 | 1.80 | 2.18 | |
| Second Gear | ||||
| 11 | 329154 | 7.35 | 8.89 | |
| No information available, not orderable | ||||
| 12 | 334989 | |||
| Metal | ||||
| 13 | 329156 | 1.80 | 2.18 | |
| Socket | ||||
| 14 | 329165 | 3.45 | 4.17 | |
| Drum | ||||
| 15 | 329164 | 1.80 | 2.18 | |
| Plunger | ||||
| 16 | 331189 | 73.29 | 88.68 | |
| Damper | ||||
| 17 | 329142 | 3.45 | 4.17 | |
| Damper Washer | ||||
| 18 | 330144 | 1.80 | 2.18 | |
| Damper | ||||
| 19 | 329145 | 1.80 | 2.18 | |
| Washer (a) | ||||
| 20 | 330142 | 1.80 | 2.18 | |
| Spring | ||||
| 21 | 329146 | 25.03 | 30.28 | |
| Washer (b) | ||||
| 22 | 330143 | 3.45 | 4.17 | |
| Switch Lever (t) | ||||
| 23 | 329107 | 1.80 | 2.18 | |
| Plunger Spring | ||||
| 24 | 329106 | 1.80 | 2.18 | |
| Striker | ||||
| 25 | 329105 | 3.45 | 4.17 | |
| Trigger Spring | ||||
| 26 | 329104 | 1.80 | 2.18 | |
| Trigger | ||||
| 27 | 329100 | 1.80 | 2.18 | |
| Retaining Ring (e-type) For D2.5 Shaft | ||||
| 28 | 874759 | 1.04 | 1.26 | |
| Roll Pin D2x16 | ||||
| 29 | 880093 | 1.04 | 1.26 | |
| Pushing Lever (b) | ||||
| 30 | 329135 | 6.75 | 8.17 | |
| Needle Roller | ||||
| 31 | 329108 | 1.80 | 2.18 | |
| Trigger Piece | ||||
| 32 | 882896 | 1.65 | 2.00 | |
| Trigger Arm Spring | ||||
| 33 | 329102 | 1.80 | 2.18 | |
| Trigger Arm | ||||
| 34A | 884201 | 12.30 | 14.88 | |
| Roll Pin D2.5x16 | ||||
| 35 | 881951 | 1.80 | 2.18 | |
| Needle Roller | ||||
| 36 | 329103 | 1.80 | 2.18 | |
| Pushing Lever (d) | ||||
| 37 | 329136 | 5.10 | 6.17 | |
| Adjuster | ||||
| 38 | 884221 | 7.80 | 9.44 | |
| Pushing Lever (c) | ||||
| 39 | 329134 | 10.35 | 12.52 | |
| Retaining Ring (e-type) For D3 Shaft Till 6.1998 | ||||
| 40 | 872971 | 1.05 | 1.27 | |
| Second Gear | ||||
| 41 | 329155 | 12.15 | 14.70 | |
| Ball Bearing 695vv | ||||
| 42 | 329153 | 5.10 | 6.17 | |
| Washer (p) | ||||
| 43 | 329150 | 1.80 | 2.18 | |
| Ring | ||||
| 44 | 329151 | 12.00 | 14.52 | |
| Micro Switch Holder | ||||
| 45 | 330145 | 1.80 | 2.18 | |
| Nylock Hex. Socket Hd. Bolt M3 | ||||
| 46 | 331184 | 1.80 | 2.18 | |
| Pulley (b) | ||||
| 47 | 329149 | 11.70 | 14.16 | |
| First Gear | ||||
| 48 | 329152 | 10.35 | 12.52 | |
| O-ring (1ap-12) | ||||
| 49 | 996407 | 1.05 | 1.27 | |
| No longer available, no replacement | ||||
| 50 | 872654 | |||
| Motor | ||||
| 51 | 334990 | 14.30 | 17.30 | |
| Screw (w/washers) M3x10 | ||||
| 52 | 331172 | 1.80 | 2.18 | |
| Light Holder | ||||
| 53 | 331174 | 7.80 | 9.44 | |
| Micro Switch Holder (b) | ||||
| 54 | 335025 | 1.20 | 1.45 | |
| Hex. Socket Hd. Bolt M5x20 (10 Pcs.) For Europe | ||||
| 55 | 949757 | 3.00 | 3.63 | |
| Holding Plate | ||||
| 56 | 331183 | 6.75 | 8.17 | |
| Needle Pin D3 | ||||
| 57 | 331181 | 5.10 | 6.17 | |
| Spring (l) | ||||
| 58 | 331182 | 1.80 | 2.18 | |
| Pushing Lever Spring | ||||
| 59 | 329133 | 1.80 | 2.18 | |
| Blade Guide | ||||
| 60A | 337786 | 59.40 | 71.87 | |
| Magazine Holder | ||||
| 61 | 331141 | 3.45 | 4.17 | |
| NYLOCK HEX.SOCKET HD.BOLT M4X8 | ||||
| 62 | 878614 | 1.04 | 1.26 | |
| Washer (m) | ||||
| 63 | 329140 | 1.80 | 2.18 | |
| Distance Piece | ||||
| 64 | 329137 | 1.80 | 2.18 | |
| Switch Arm | ||||
| 65 | 329138 | 3.45 | 4.17 | |
| No information available, not orderable | ||||
| 66 | 334993 | |||
| Roll Pin D2.5x12 | ||||
| 67 | 878791 | 1.04 | 1.26 | |
| Magazine | ||||
| 68 | 329111 | 48.81 | 59.06 | |
| Feeder Piece | ||||
| 69 | 329125 | 142.86 | 172.86 | |
| No information available, not orderable | ||||
| 70 | 329114 | |||
| Roll Pin D2.5x5 | ||||
| 71 | 329128 | 1.80 | 2.18 | |
| Magazine Cover (b) | ||||
| 72 | 329113 | 7.35 | 8.89 | |
| Seal Lock Hex. Socket Hd. Bolt M3x12 | ||||
| 73 | 318832 | 1.65 | 2.00 | |
| Magazine Stay | ||||
| 74 | 329120 | 7.35 | 8.89 | |
| Roll Pin D2x6 | ||||
| 75 | 880585 | 1.05 | 1.27 | |
| Feeder Guide | ||||
| 76 | 329118 | 6.75 | 8.17 | |
| Hex. Socket Hd. Bolt M4x12 (10 Pcs.) | ||||
| 77 | 949813 | 1.65 | 2.00 | |
| Roll Pin D2.5x18 (10 Pcs.) | ||||
| 78 | 949863 | 1.80 | 2.18 | |
| Feed Spring | ||||
| 79 | 329115 | 1.80 | 2.18 | |
| Guide Bar Spring | ||||
| 80 | 329119 | 1.80 | 2.18 | |
| Stop Lever | ||||
| 81 | 331121 | 3.45 | 4.17 | |
| Bushing Spring | ||||
| 82 | 329126 | 1.80 | 2.18 | |
| Magazine Cover (a) | ||||
| 83 | 329112 | 6.75 | 8.17 | |
| Roll Pin D3x20 (10 Pcs.) | ||||
| 85 | 949685 | 2.55 | 3.09 | |
| Nylon Nut M5 | ||||
| 86 | 877371 | 1.05 | 1.27 | |
| Machine Screw (w/washer) M5x10 (black) | ||||
| 87 | 329127 | 1.80 | 2.18 | |
| No information available, not orderable | ||||
| 88 | 329124 | |||
| Guide Bar | ||||
| 89 | 329116 | 1.80 | 2.18 | |
| Spring Plate (1) | ||||
| 90 | 329117 | 1.80 | 2.18 | |
| Nail Plate | ||||
| 91 | 329121 | 1.80 | 2.18 | |
| Magazine Guide | ||||
| 92 | 329123 | 9.00 | 10.89 | |
| Hex. Socket Hd. Bolt M5x8 (10 Pcs.) | ||||
| 94 | 949818 | 2.40 | 2.90 | |
| Hex. Socket Hd. Bolt (w/button) M6x7 | ||||
| 95 | 884215 | 5.10 | 6.17 | |
| Nose | ||||
| 96 | 329131 | 20.21 | 24.46 | |
| Guide Plate (b) | ||||
| 97 | 331108 | 10.35 | 12.52 | |
| Guide Plate (a) | ||||
| 98 | 331107 | 17.46 | 21.13 | |
| Pushing Lever | ||||
| 99A | 337787 | 36.44 | 44.09 | |
| Low Head Hex. Socket Bolt M4x8 | ||||
| 100 | 331109 | 1.80 | 2.18 | |
| Brand Plate | ||||
| 101 | 886342 | 1.80 | 2.18 | |
| Hook | ||||
| 102 | 332824 | 4.58 | 5.54 | |
| Truss Hd. Screw M4 (black) | ||||
| 103 | 327001 | 1.80 | 2.18 | |
| Switch | ||||
| 104 | 334992 | 67.93 | 82.19 | |
| No information available, not orderable | ||||
| 105 | 334421 | |||
| No information available, not orderable | ||||
| 105A | 370171 | |||
| Drum Damper | ||||
| 106 | 336988 | 1.04 | 1.26 | |
| Nose Cap (a) | ||||
| 502 | 886713 | 1.80 | 2.18 | |
| No information available, not orderable | ||||
| 503 | 944458 | |||
| No information available, not orderable | ||||
| 504A | 339043 | |||
| No information available, not orderable | ||||
| 505 | 875769 | |||
| Battery Cover | ||||
| 506 | 329897 | 1.80 | 2.18 | |
