Here you will find all available parts and drawings of the 'Hikoki M12SC'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Hikoki M12SC
Spare parts list of model Hikoki M12SC
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Machine Screw (w/sp. Washer) M4x10 | ||||
| 1 | 307635 | 1.05 | 1.27 | |
| Machine Screw (w/washers) M4x8 (black) | ||||
| 2 | 317200 | 1.65 | 2.00 | |
| No information available, not orderable | ||||
| 3 | 323306 | |||
| No information available, not orderable | ||||
| 4 | 323266 | |||
| Machine Screw (black) M4x16 | ||||
| 5 | 333163 | 1.80 | 2.18 | |
| Cord Clip | ||||
| 6 | 937631 | 1.04 | 1.26 | |
| Connector 50092 (10 Pcs.) | ||||
| 7 | 959141 | 3.75 | 4.54 | |
| Machine Screw (w/sp. Washer) M4x6 | ||||
| 8 | 317333 | 1.50 | 1.82 | |
| Cord Armor D10.1 | ||||
| 9 | 938051 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| 10 | 500451Z | |||
| Machine Screw (w/washer) M3.5x6 | ||||
| 11 | 305499 | 1.05 | 1.27 | |
| SCHAKELAAR | ||||
| 12 | 314603 | 11.88 | 14.37 | |
| Machine Screw (w/washers) M4x12 (black) | ||||
| 13 | 307081 | 1.05 | 1.27 | |
| No information available, not orderable | ||||
| 14 | 323274 | |||
| Brush Cap | ||||
| 15 | 935829 | 1.05 | 1.27 | |
| Carbon Brush (1 Pair) | ||||
| 16 | 999043 | 4.50 | 5.44 | |
| Brush Holder (2) | ||||
| 17 | 957051 | 5.25 | 6.35 | |
| Hex Adjustment Screw M5x8 | ||||
| 18 | 938477 | 1.05 | 1.27 | |
| No information available, not orderable | ||||
| 19 | 323256 | |||
| No information available, not orderable | ||||
| 20 | 930706 | |||
| No information available, not orderable | ||||
| 21 | 323552 | |||
| Rubber Ring | ||||
| 22 | 323420 | 1.05 | 1.27 | |
| Ball Bearing 608vvc2ps2l | ||||
| 23 | 608VVM | 5.70 | 6.90 | |
| Brush Terminal | ||||
| 24 | 930703 | 2.40 | 2.90 | |
| connecting terminal | ||||
| 25 | 980063 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| 26 | 340595E | |||
| No information available, not orderable | ||||
| 27 | 943430 | |||
| No information available, not orderable | ||||
| 28 | 360668E | |||
| No information available, not orderable | ||||
| 29 | 323255 | |||
| Ball Bearing 6004vvcmps2l | ||||
| 30 | 6004VV | 8.55 | 10.35 | |
| No information available, not orderable | ||||
| 31 | 323257 | |||
| No information available, not orderable | ||||
| 32 | 323258 | |||
| No information available, not orderable | ||||
| 33B | 325199 | |||
| No information available, not orderable | ||||
| 34 | 323260 | |||
| No information available, not orderable | ||||
| 35 | 323264 | |||
| No information available, not orderable | ||||
| 36 | 323259 | |||
| No information available, not orderable | ||||
| 37 | 323263 | |||
| No information available, not orderable | ||||
| 38 | 323261 | |||
| No information available, not orderable | ||||
| 39 | 323262 | |||
| No information available, not orderable | ||||
| 40 | 323423 | |||
| No information available, not orderable | ||||
| 41 | 323422 | |||
| No information available, not orderable | ||||
| 42 | 323265 | |||
| Flat Hd. Screw M5x12 (10 Pcs.) | ||||
| 43 | 949332 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| 45 | 323270 | |||
| Steel Ball 5/32 (10 Pcs.) | ||||
| 46 | 335297 | 1.04 | 1.26 | |
| Spring | ||||
| 47 | 982454 | 1.04 | 1.26 | |
| Hex Adjustment Screw M5x8 | ||||
| 48 | 938477 | 1.05 | 1.27 | |
| No information available, not orderable | ||||
| 49 | 323268 | |||
| No information available, not orderable | ||||
| 50 | 323269 | |||
| Spring | ||||
| 51 | 306024 | 1.35 | 1.63 | |
| No information available, not orderable | ||||
| 52 | 323271 | |||
| No information available, not orderable | ||||
| 53 | 323348 | |||
| No information available, not orderable | ||||
| 501 | 325212 | |||
| No information available, not orderable | ||||
| 502 | 944458 | |||
| Screw | ||||
| 503 | 956793 | 5.25 | 6.35 | |
| Hex. Socket Hd. Bolt M5x10 (10 Pcs.) | ||||
| 504 | 949819 | 2.55 | 3.09 | |
| Machine Screw M5x6 (10 Pcs.) | ||||
| 505 | 949234 | 1.05 | 1.27 | |
| No information available, not orderable | ||||
| 506 | 956790 | |||
| No information available, not orderable | ||||
| 507 | 323294 | |||
| No information available, not orderable | ||||
| 508 | 323295 | |||
| No information available, not orderable | ||||
| 509 | 323345 | |||
| Wing Bolt M6x15 | ||||
| 510 | 301806 | 1.05 | 1.27 | |
| No information available, not orderable | ||||
| 511 | 323344 | |||
| No information available, not orderable | ||||
| 512 | 323343 | |||
| No information available, not orderable | ||||
| 601 | 956808 | |||
| No information available, not orderable | ||||
| 602 | 323349 | |||
| No information available, not orderable | ||||
| 603 | 323346 | |||
| No information available, not orderable | ||||
| 604 | 323347 | |||
| Machine Screw M5x16 (black) | ||||
| 605 | 302317 | 1.05 | 1.27 | |
