Here you will find all available parts and drawings of the 'Hikoki H90SC'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Hikoki H90SC

Spare parts list of model Hikoki H90SC

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
Retainer
1 305618 282.84 342.23
Roll Pin D6x36 (10 Pcs.)
2 949874 5.85 7.08
Pivot Pin
3 305620 26.40 31.94
No information available, not orderable
4A 306373
Front Case
5 305619 373.18 451.54
Retainer Damper
6 305621 18.15 21.96
O-ring
7 993188 14.71 17.80
O-ring (s-90)
8 877316 2.55 3.09
No information available, not orderable
9 305617
O-ring (d)
10 992865 8.70 10.53
O-ring (a)
11 956503 5.85 7.08
Hammer Holder
12 305616 110.83 134.10
Damper
13 992859 25.99 31.44
Cylinder Case
15 305615 422.81 511.60
Nylock Bolt M10x45
16A 306372 4.50 5.44
Washer M10 (10 Pcs.)
17 949445 1.35 1.63
O-ring
18 993195 2.40 2.90
Striker
19 305612 64.21 77.70
No information available, not orderable
20 305611
Piston Pin
21 305614 21.31 25.79
O-ring (p-46)
22 878716 1.65 2.00
Connecting Rod
23 305613 102.16 123.62
Bearing
24 956485 16.36 19.80
Pin
25 992870 5.25 6.35
Switch Lever
26 992869 8.70 10.53
Retaining Ring (e-type) For D4 Shaft
27 968643 1.95 2.36
Seal Lock Hex Socket Bolt M6x30
28 993496 1.05 1.27
Handle (a)
29 305636 19.39 23.46
No longer available, no replacement
30 500391Z
Cord 3m 2 X 1.5 H07rn-f W/plug 16a Cee Form 2p+e F
30A 500466Z 38.50 46.58
Cord (cord Armor D8.8)
30B 500450Z 31.63 38.27
SNOER 10.7 (USE 714500=2X1 5M)
30C 500247Z 6.18 7.48
Cord Armor D10.7
31 940778 2.10 2.54
Cable gland D8.2 (old 958049z)
31 958049 1.04 1.26
Noise Suppressor
32 994273 4.29 5.19
Holder
33 963243 1.05 1.27
Rubber
33 930153 1.04 1.26
Connector 50091 (10 Pcs.)
34 959140 3.30 3.99
Connector 50092 (10 Pcs.)
35 959141 3.75 4.54
Pillar Terminal Till 10.1999 For Aus
36 938307 2.13 2.57
No information available, not orderable
37 958308Z
Vinyl Tube (a) (i.d.7xt0.5x50)
38 996438 1.05 1.27
Internal wire
39 981974 1.65 2.00
Terminal M4.0 (10 Pcs.)
40 930804 3.00 3.63
connecting terminal
40 980063 1.04 1.26
Terminal For Cord
40 992810 1.04 1.26
Cord Clip
41 960266 1.04 1.26
Tapping Screw (w/washer) D4x20
42A 982095 1.04 1.26
Switch (a) (1p Screw Type) W/o Lock
43 992891 22.83 27.62
Washer M4 (10 Pcs.)
44 949423 1.05 1.27
No information available, not orderable
45 990082
Handle Holder (b)
46 305634 122.51 148.24
Washer M8 (10 Pcs.)
47 949426 1.05 1.27
No information available, not orderable
48 305632
Handle (b)
49 305631 18.15 21.96
Tapping Screw (w/flange) D4x20 (black)
50 301653 1.04 1.26
Chute
51 305624 148.78 180.02
No information available, not orderable
52 305598
No information available, not orderable
53 305623
Handle Damper
54 305622 1.65 2.00
No information available, not orderable
55 305633
No information available, not orderable
56 305625
Rivet D2.5x4.8 (10 Pcs.) Three-phase
57 949510 1.04 1.26
Seal Lock Hex. Socket Hd. Bolt M10x60
59 992851 2.40 2.90
Gear Cover Ass'y (metallic Silver Green) Includ.5
60A 336338 136.13 164.71
Hex. Socket Hd. Bolt M4x20 (10 Pcs.)
61 949699 2.55 3.09
Stopper
62 305629 7.65 9.26
Ball Bearing 6204vvcmps2l
63 6204VV 9.15 11.07
Distance Ring (a)
64 305609 7.65 9.26
Final Gear
65 305608 110.83 134.10
Distance Ring (b)
66 305607 9.30 11.25
Seal Lock Hex. Socket Hd. Bolt M10x55
67 996433 2.10 2.54
Ball Bearing 6201vv
68 6201VV 6.45 7.80
No information available, not orderable
69 305605
Second Gear
70 305604 55.41 67.05
Feather Key 4x4x10
71 930511 2.40 2.90
Seal Lock Hd. Allen bolt M5x12
72 991690 1.05 1.27
No information available, not orderable
73 305600
Ball Bearing 6203ddcmps2l
74A 6203DD 7.65 9.26
Bearing Washer
75 992841 1.05 1.27
Pin D8x14 (10 Pcs.)
76 949480 3.30 3.99
Inner Cover (metallic Silver Green)
77A 336337 130.76 158.22
Distance Ring (c)
78 305602 20.76 25.12
Ball Bearing 6305vvcmps2s
79 6305VV 13.89 16.80
O-ring (a)
80 992847 3.60 4.36
Bearing Boss
81 305601 69.99 84.68
Seal Lock Hex. Socket Hd. Bolt M8x18
82A 305603 1.04 1.26
Oil Seal
83 992846 2.40 2.90
Feather Key 4x4x12
84 931008 1.05 1.27
No information available, not orderable
85 305606
Housing Ass'y (metallic Silver Green) Includ.52.9
86A 336339 315.98 382.33
O-ring (s-38)
87 980717 1.35 1.63
Oil Cap Ass'y Includ.13
88A 990945 3.90 4.72
Cap Rubber
89 992894 4.20 5.08
Seal Lock Hex. Socket Hd. Bolt M4x10
90 878356 1.05 1.27
Cap Cover
91 305635 5.85 7.08
Brush Cap
92 937949 1.35 1.63
Auto-stop Carbon Brushes (2 Pieces)
93B 999086 15.26 18.47
Brush Holder
94 305597 6.45 7.80
Hex Adjustment Screw M5x8
95 938477 1.05 1.27
Internal Wire Holder
96 305627 4.20 5.08
No information available, not orderable
97 305630
Seal Lock Hex Socket Bolt M6x16
98 990935 1.05 1.27
Fan
99 996370 14.03 16.97
Armature 230v
100 360262E 250.80 303.47
Armature Ass'y 240v
100 360262F 250.80 303.47
No information available, not orderable
101 993185
Washer
102 956764 1.04 1.26
No information available, not orderable
103 305798
Fan Guide
104 305610 12.75 15.43
Brush Terminal
105 945932 1.05 1.27
Stator 220v-230v
106 340238E 84.56 102.32
Stator Ass'y 240v Includ.103
106 340238F 84.56 102.32
Bearing Washer
107 944954 1.05 1.27
Housing Cover
108 305628 32.18 38.93
Collar
109 996437 1.05 1.27
Hex. Socket Hd. Bolt (w/flange) M6x16
110 301582 1.05 1.27
No information available, not orderable
501 943277
No information available, not orderable
502 944459
No information available, not orderable
503 993740
No information available, not orderable
601 993180
No information available, not orderable
602 993181
No information available, not orderable
603 993182
No information available, not orderable
604 993183
Grease For Hammer.hammer Drill (500g)
605 980927 73.01 88.35
No information available, not orderable
606 936728
No information available, not orderable
607 305880
No information available, not orderable
608 305881
No information available, not orderable
609 993204
