Here you will find all available parts and drawings of the 'Hikoki G23SWU2'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Hikoki G23SWU2
Spare parts list of model Hikoki G23SWU2
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Guard | ||||
| *24 | 338292 | 8.10 | 9.80 | |
| Threaded cable sleeve | ||||
| *42 | 981373 | 1.05 | 1.27 | |
| Cord Armor D10.7 | ||||
| *44 | 940778 | 2.10 | 2.54 | |
| Cable gland D8.2 (old 958049z) | ||||
| *44 | 958049 | 1.04 | 1.26 | |
| SNOER 2.5M 2 X 1.0 H05VV-F W/PLUG 13A/250V (OLD 50 | ||||
| *46 | 500423Z | 12.87 | 15.57 | |
| CORD (CORD ARMOR D10.7) | ||||
| *46 | 500492Z | 6.45 | 7.80 | |
| Pushing Button | ||||
| 1 | 337641 | 1.04 | 1.26 | |
| Spring | ||||
| 2 | 320219 | 1.35 | 1.63 | |
| Felt Washer | ||||
| 3 | 937033 | 1.04 | 1.26 | |
| Special Nut M10 | ||||
| 4 | 320226 | 1.35 | 1.63 | |
| Ball Bearing 6301ddcmps2l | ||||
| 5 | 6301DD | 6.75 | 8.17 | |
| Rubber Ring | ||||
| 6 | 330031 | 1.20 | 1.45 | |
| Washer (1) | ||||
| 7 | 337642 | 1.04 | 1.26 | |
| Retaining Ring For D40 Hole | ||||
| 8 | 948391 | 1.65 | 2.00 | |
| Fan Guide (b) | ||||
| 9 | 337640 | 1.04 | 1.26 | |
| Armature 230v | ||||
| 10 | 360982E | 41.25 | 49.91 | |
| Tapping Screw (w/flange) D5x35 (black) | ||||
| 11 | 323209 | 1.35 | 1.63 | |
| Gear Cover | ||||
| 12 | 337650 | 15.95 | 19.30 | |
| Lock Pin | ||||
| 13 | 306890 | 1.80 | 2.18 | |
| Spring Washer D12 (10 pieces) | ||||
| 14 | 939542 | 1.50 | 1.82 | |
| Machine Screw M5x10 (10 Pcs.) For Irl | ||||
| 15 | 949236 | 1.05 | 1.27 | |
| Bearing Cover (b) | ||||
| 16 | 320229 | 1.35 | 1.63 | |
| Ball Bearing 6302vvcmps2l | ||||
| 17 | 6302VV | 9.30 | 11.25 | |
| Felt Packing | ||||
| 18 | 990852 | 1.04 | 1.26 | |
| AS | ||||
| 19A | 378127 | 3.66 | 4.43 | |
| Seal Plate | ||||
| 20 | 320228 | 1.35 | 1.63 | |
| PACKING GLAND | ||||
| 21 | 339726 | 4.50 | 5.44 | |
| Hex. Socket Hd. Bolt (w/flange) M5x16 | ||||
| 22 | 994192 | 1.04 | 1.26 | |
| Hex. Socket Hd. Bolt M8x25 (10 Pcs.) | ||||
| 23 | 949760 | 5.55 | 6.72 | |
| No information available, not orderable | ||||
| 25 | 937907Z | |||
| No information available, not orderable | ||||
| 26 | 373779 | |||
| Gear And Pinion Set | ||||
| 27 | 330688 | 24.75 | 29.95 | |
| Fan Guide (a) | ||||
| 28 | 337639 | 1.04 | 1.26 | |
| Stator 220v-230v | ||||
| 29A | 340888E | 30.25 | 36.60 | |
| Dust Seal | ||||
| 30 | 330029 | 1.80 | 2.18 | |
| Ball Bearing 6000vvcmps2l | ||||
| 31 | 6000VV | 6.15 | 7.44 | |
| Housing (1) | ||||
| 32A | 337643 | 11.10 | 13.43 | |
| BRUSH HOLDER | ||||
| 33 | 337646 | 2.10 | 2.54 | |
| No information available, not orderable | ||||
| 34 | 984750 | |||
| Carbon Brush (1 Pair) | ||||
| 35 | 999059 | 3.30 | 3.99 | |
| BRUSH COVER | ||||
| 36 | 337649 | 1.04 | 1.26 | |
| Tapping Screw (w/flange) D4x16 (black) | ||||
| 37 | 305812 | 1.04 | 1.26 | |
| Handle (a) | ||||
| 40 | 337644 | 3.30 | 3.99 | |
| Switch | ||||
| 41A | 373756 | 49.64 | 60.06 | |
| SCHAKELAAR (OUD 373756) | ||||
| 41B | 381429 | 25.80 | 31.22 | |
| Cord Clip | ||||
| 43 | 331336 | 1.20 | 1.45 | |
| Handle (b) | ||||
| 45 | 337645 | 3.30 | 3.99 | |
| SWITCH STATOR SET (OLD 341025E + 374787) | ||||
| 47 | 376617 | 72.88 | 88.18 | |
| No information available, not orderable | ||||
| 501 | 937981 | |||
| No information available, not orderable | ||||
| 502A | 376127 | |||
| No information available, not orderable | ||||
| 503 | 872422 | |||
| No information available, not orderable | ||||
| 504 | 378126 | |||
| No information available, not orderable | ||||
| 601 | 316825 | |||
| No information available, not orderable | ||||
| 602 | 310337 | |||
| Pipe Handle Set Includ.602 | ||||
| 603 | 323993 | 63.66 | 77.03 | |
| Bolt | ||||
| 604 | 985597 | 2.85 | 3.45 | |
| No information available, not orderable | ||||
| 605 | 332797 | |||
