Here you will find all available parts and drawings of the 'Hikoki G23SWA'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Hikoki G23SWA
Spare parts list of model Hikoki G23SWA
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Wheel Guard Ass'y Includ.32-38 For Europe | ||||
| *23 | 337225 | 14.03 | 16.97 | |
| No information available, not orderable | ||||
| *503 | 937981 | |||
| Tapping Screw (w/flange) D5x35 (black) | ||||
| 1 | 323209 | 1.35 | 1.63 | |
| Pushing Button | ||||
| 2 | 337641 | 1.04 | 1.26 | |
| Spring | ||||
| 3 | 320219 | 1.35 | 1.63 | |
| Felt Washer | ||||
| 4 | 937033 | 1.04 | 1.26 | |
| Special Nut M10 | ||||
| 5 | 320226 | 1.35 | 1.63 | |
| Ball Bearing 6301vvcmps2l | ||||
| 6 | 6301VV | 8.55 | 10.35 | |
| Rubber Ring | ||||
| 7 | 330031 | 1.20 | 1.45 | |
| Washer (1) | ||||
| 8 | 337642 | 1.04 | 1.26 | |
| Retaining Ring For D40 Hole | ||||
| 9 | 948391 | 1.65 | 2.00 | |
| Fan Guide (b) | ||||
| 10 | 337640 | 1.04 | 1.26 | |
| ANKER 230 VOLT | ||||
| 11 | 361174E | 30.47 | 36.87 | |
| LUCHTGELEIDER | ||||
| 12 | 378123 | 1.00 | 1.21 | |
| TANKWIELDEKSEL | ||||
| 13 | 378121 | 11.34 | 13.72 | |
| Spring Washer D12 (10 pieces) | ||||
| 14 | 939542 | 1.50 | 1.82 | |
| Machine Screw M5x10 (10 Pcs.) For Irl | ||||
| 15 | 949236 | 1.05 | 1.27 | |
| Bearing Cover (b) | ||||
| 16 | 320229 | 1.35 | 1.63 | |
| Ball Bearing 6302vvcmps2l | ||||
| 17 | 6302VV | 9.30 | 11.25 | |
| Felt Packing | ||||
| 18 | 990852 | 1.04 | 1.26 | |
| AS | ||||
| 19 | 378127 | 3.66 | 4.43 | |
| Seal Plate | ||||
| 20 | 320228 | 1.35 | 1.63 | |
| PACKING GLAND | ||||
| 21 | 339726 | 4.50 | 5.44 | |
| Hex. Socket Hd. Bolt (w/flange) M5x16 | ||||
| 22 | 994192 | 1.04 | 1.26 | |
| Label | ||||
| 24 | 311492 | 1.20 | 1.45 | |
| Set Pin | ||||
| 25 | 321546 | 3.00 | 3.63 | |
| Lever | ||||
| 26 | 321545 | 3.00 | 3.63 | |
| Hex. Socket Hd. Bolt M8x25 (10 Pcs.) | ||||
| 27 | 949760 | 5.55 | 6.72 | |
| Set Piece | ||||
| 28 | 321544 | 1.50 | 1.82 | |
| Ring | ||||
| 29 | 673489 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| 30 | 937907Z | |||
| No information available, not orderable | ||||
| 31 | 373779 | |||
| Lock Pin | ||||
| 32 | 306890 | 1.80 | 2.18 | |
| Gear And Pinion Set | ||||
| 33 | 330688 | 24.75 | 29.95 | |
| Stator 220v-230v | ||||
| 34 | 340888E | 30.25 | 36.60 | |
| Dust Seal | ||||
| 35 | 330029 | 1.80 | 2.18 | |
| Ball Bearing 6000vvcmps2l | ||||
| 36 | 6000VV | 6.15 | 7.44 | |
| BEHUIZING | ||||
| 37 | 378131 | 7.26 | 8.78 | |
| Tapping Screw (w/flange) D4x16 (black) | ||||
| 39 | 305812 | 1.04 | 1.26 | |
| AFDEKPLAAT VOOR KOOLBORSTEL | ||||
| 40 | 378124 | 1.00 | 1.21 | |
| Carbon Brush (1 Pair) | ||||
| 41 | 999059 | 3.30 | 3.99 | |
| No information available, not orderable | ||||
| 42 | 984750 | |||
| BRUSH HOLDER | ||||
| 43 | 337646 | 2.10 | 2.54 | |
| Handle (a) | ||||
| 44 | 337644 | 3.30 | 3.99 | |
| Switch (off Lock Type) | ||||
| 45 | 337648 | 12.60 | 15.25 | |
| Threaded cable sleeve | ||||
| 46 | 981373 | 1.05 | 1.27 | |
| Cord Clip | ||||
| 47 | 331336 | 1.20 | 1.45 | |
| Cord Armor D10.7 | ||||
| 48 | 940778 | 2.10 | 2.54 | |
| Handle (b) | ||||
| 49 | 337645 | 3.30 | 3.99 | |
| CORD (CORD ARMOR D10.7) | ||||
| 50 | 500492Z | 6.45 | 7.80 | |
| No information available, not orderable | ||||
| 501 | 376127 | |||
| No information available, not orderable | ||||
| 502 | 872422 | |||
| No information available, not orderable | ||||
| 503A | 381402 | |||
| No information available, not orderable | ||||
| 504 | 378126 | |||
| KUNSTSTOF KOFFER | ||||
| 506 | 378125 | 25.96 | 31.41 | |
| No information available, not orderable | ||||
| 602 | 316825 | |||
| No information available, not orderable | ||||
| 603 | 310337 | |||
| Pipe Handle Set Includ.602 | ||||
| 604 | 323993 | 63.66 | 77.03 | |
| Bolt | ||||
| 605 | 985597 | 2.85 | 3.45 | |
| No information available, not orderable | ||||
| 606 | 332797 | |||
