Here you will find all available parts and drawings of the 'Hikoki G13SQ'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Hikoki G13SQ
Spare parts list of model Hikoki G13SQ
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Tapping Screw (w/flange) D4x25 (black) | ||||
| 1 | 307028 | 1.05 | 1.27 | |
| Pushing Button | ||||
| 2 | 301944 | 1.04 | 1.26 | |
| Inner Cover | ||||
| 3 | 332529 | 11.85 | 14.34 | |
| Special Nut M6 | ||||
| 4 | 309191 | 1.04 | 1.26 | |
| Ball Bearing 628vvc2ps2-l | ||||
| 5 | 628VVC | 11.85 | 14.34 | |
| Bearing Holder | ||||
| 6 | 327887 | 1.20 | 1.45 | |
| Armature 230v | ||||
| 7 | 360891F | 36.10 | 43.68 | |
| ARMATURE 110 VOLT | ||||
| 7 | 360891C | 33.66 | 40.73 | |
| Fan Guide | ||||
| 8 | 332527 | 1.05 | 1.27 | |
| Hex. Hd. Tapping Screw D4x70 | ||||
| 9 | 982021 | 1.04 | 1.26 | |
| Stator 230v-240v | ||||
| 10 | 340771J | 36.08 | 43.65 | |
| FIELD 110 VOLT | ||||
| 10 | 340771B | 33.66 | 40.73 | |
| Dust Seal | ||||
| 11 | 321722 | 1.35 | 1.63 | |
| Ball Bearing 626vvc2ps2l | ||||
| 12 | 626VVM | 5.70 | 6.90 | |
| Rubber Ring | ||||
| 13 | 309929 | 1.04 | 1.26 | |
| Lock Pin | ||||
| 14 | 301943 | 1.65 | 2.00 | |
| Seal Lock Screw (w/sp. Washer) M4x10 | ||||
| 15 | 987201 | 1.05 | 1.27 | |
| Bearing Cover | ||||
| 16 | 316490 | 1.65 | 2.00 | |
| Ball Bearing 6201vv | ||||
| 17 | 6201VV | 6.45 | 7.80 | |
| Felt Packing | ||||
| 18 | 301946 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| 19 | 316489 | |||
| Seal Lock Screw (w/sp. Washer) M4x12 | ||||
| 20 | 987203 | 1.05 | 1.27 | |
| Woodruff Key | ||||
| 21 | 302047 | 1.05 | 1.27 | |
| Spindle Ass'y | ||||
| 22 | 332536 | 4.20 | 5.08 | |
| Machine Screw (w/sp. Washer) M5x16(black | ||||
| 23 | 308386 | 1.05 | 1.27 | |
| Clamp Ring for Guard | ||||
| 24 | 301949 | 1.04 | 1.26 | |
| Guard | ||||
| 25 | 331766 | 10.80 | 13.07 | |
| No information available, not orderable | ||||
| 26 | 937817Z | |||
| Wheel Washer (c) For Pan (120v) | ||||
| 26A | 334456 | 2.10 | 2.54 | |
| No information available, not orderable | ||||
| 27 | 316822 | |||
| No information available, not orderable | ||||
| 28 | 994324 | |||
| No information available, not orderable | ||||
| 28A | 337329 | |||
| No information available, not orderable | ||||
| 28B | 339579 | |||
| Bevel gear | ||||
| 29 | 327888 | 10.80 | 13.07 | |
| Housing | ||||
| 30 | 332525 | 4.20 | 5.08 | |
| Connector 50091 (10 Pcs.) | ||||
| 32 | 959140 | 3.30 | 3.99 | |
| connecting terminal | ||||
| 33 | 980063 | 1.04 | 1.26 | |
| Pillar Terminal Till 10.1999 For Aus | ||||
| 34 | 938307 | 2.13 | 2.57 | |
| Tail Cover | ||||
| 35 | 332523 | 2.10 | 2.54 | |
| Tail Cover | ||||
| 35 | 332524 | 2.10 | 2.54 | |
| Tapping Screw (w/flange) D4x30 (black) | ||||
| 36 | 305490 | 1.04 | 1.26 | |
| Tapping Screw (w/flange) D4x20 (black) | ||||
| 37 | 301653 | 1.04 | 1.26 | |
| Machine Screw (w/washer) M3.5x6 | ||||
| 38 | 305499 | 1.05 | 1.27 | |
| Switch | ||||
| 39 | 314603 | 11.88 | 14.37 | |
| Interference Suppressor | ||||
| 40 | 317491 | 7.35 | 8.89 | |
| No longer available, no replacement | ||||
| 42 | 332545 | |||
| connecting terminal | ||||
| 43 | 980063 | 1.04 | 1.26 | |
| Cord Clip | ||||
| 44 | 937631 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| 45 | 984750 | |||
| Carbon Brush (1 Pair) | ||||
| 47 | 999005 | 7.80 | 9.44 | |
| Tapping Screw D3x8 | ||||
| 48 | 328210 | 1.20 | 1.45 | |
| Carbon Brush Holder | ||||
| 49A | 333844 | 2.10 | 2.54 | |
| Spring | ||||
| 50 | 332531 | 1.05 | 1.27 | |
| PIN (A) D2.5 | ||||
| 51 | 333136 | 1.05 | 1.27 | |
| Locking plate | ||||
| 52 | 332581 | 3.15 | 3.81 | |
| Spring | ||||
| 53 | 314429 | 1.04 | 1.26 | |
| Shift Knob | ||||
| 54 | 332580 | 1.05 | 1.27 | |
| DETENT | ||||
| 55 | 332530 | 1.05 | 1.27 | |
| Switch Button | ||||
| 56 | 332582 | 1.05 | 1.27 | |
| No information available, not orderable | ||||
| 57 | 332522 | |||
| Spring | ||||
| 58 | 332534 | 1.05 | 1.27 | |
| PIN D2.5 | ||||
| 59 | 332535 | 1.05 | 1.27 | |
| Button AGC 18 | ||||
| 60 | 332533 | 1.05 | 1.27 | |
| Cord Armor D10.1 | ||||
| 61 | 938051 | 1.04 | 1.26 | |
| Cord (cord Armor D8.8) For Uae (240v) | ||||
| 62 | 500461Z | 17.88 | 21.63 | |
| Cord (cord Armor D8.8) For Mex | ||||
| 62 | 500240Z | 13.18 | 15.94 | |
| Cord (cord Armor D8.8) For Pan | ||||
| 62 | 500447Z | 6.60 | 7.99 | |
| SNOER 10.7 (USE 714500=2X1 5M) | ||||
| 62 | 500247Z | 6.18 | 7.48 | |
| No information available, not orderable | ||||
| 501 | 938332Z | |||
| Side Handle G13sr3 | ||||
| 502 | 318312 | 7.50 | 9.08 | |
| No information available, not orderable | ||||
| 502A | 994322 | |||
| No information available, not orderable | ||||
| 601 | 314062 | |||
| No information available, not orderable | ||||
| 602 | 314063 | |||
| No information available, not orderable | ||||
| 603 | 314064 | |||
| No information available, not orderable | ||||
| 604 | 314065 | |||
| No information available, not orderable | ||||
| 605 | 314066 | |||
| No information available, not orderable | ||||
| 606 | 314067 | |||
| No information available, not orderable | ||||
| 607 | 314068 | |||
| No information available, not orderable | ||||
| 608 | 314069 | |||
| No information available, not orderable | ||||
| 609 | 314070 | |||
| No information available, not orderable | ||||
| 610 | 314071 | |||
| No information available, not orderable | ||||
| 611 | 314072 | |||
| No information available, not orderable | ||||
| 612 | 938318 | |||
| No information available, not orderable | ||||
| 613 | 938317 | |||
