Here you will find all available parts and drawings of the 'Hikoki DV18DEX'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Hikoki DV18DEX
Spare parts list of model Hikoki DV18DEX
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| HEXALOBULA SCREW (LEFT HAND) M6 NEW | ||||
| 1 | 379124 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 2 | 335961 | |||
| GEAR BOX ASS'Y NEW | ||||
| 3 | 379096 | 39.66 | 47.99 | |
| CLUTCH DIAL (V) NEW | ||||
| 4 | 379102 | 4.38 | 5.30 | |
| Click Spring | ||||
| 5 | 327146 | 1.65 | 2.00 | |
| NUT COVER ASS'Y NEW | ||||
| 6 | 379100 | 1.50 | 1.82 | |
| COVER NEW | ||||
| 7 | 379925 | 1.00 | 1.21 | |
| C-RING NEW | ||||
| 8 | 379101 | 1.00 | 1.21 | |
| NUT NEW | ||||
| 9 | 379114 | 1.00 | 1.21 | |
| Spring | ||||
| 10 | 370607 | 3.60 | 4.36 | |
| Thrust Plate | ||||
| 11 | 370603 | 2.25 | 2.72 | |
| SPINDLE NEW | ||||
| 12 | 379099 | 9.30 | 11.25 | |
| Spring (c) | ||||
| 13 | 327136 | 1.65 | 2.00 | |
| Ratchet (b) | ||||
| 14 | 339772 | 2.85 | 3.45 | |
| Washer (a) | ||||
| 15 | 327147 | 1.65 | 2.00 | |
| SLIP BLOCK NEW | ||||
| 16 | 379098 | 1.00 | 1.21 | |
| Spring | ||||
| 17 | 327133 | 1.65 | 2.00 | |
| Shift Arm | ||||
| 18 | 370608 | 1.20 | 1.45 | |
| GEAR CASE NEW | ||||
| 19 | 379097 | 2.88 | 3.48 | |
| NEEDLE ROLLER (A) SET D2.2 NEW | ||||
| 20 | 379268 | 1.00 | 1.21 | |
| Washer (b) | ||||
| 21 | 328717 | 1.80 | 2.18 | |
| Lock Ring | ||||
| 22 | 370609 | 5.40 | 6.53 | |
| Roller | ||||
| 23 | 319744 | 1.65 | 2.00 | |
| Steel Ball D5 | ||||
| 24 | 306936 | 1.05 | 1.27 | |
| RING GEAR NEW | ||||
| 25 | 379116 | 1.08 | 1.31 | |
| CARRIER NEW | ||||
| 26 | 379115 | 1.92 | 2.32 | |
| PLANET GEAR (C) SET NEW | ||||
| 27 | 379267 | 1.08 | 1.31 | |
| SHIFT DOG NEW | ||||
| 28 | 379117 | 3.90 | 4.72 | |
| SLIDE RING GEAR NEW | ||||
| 29 | 379119 | 1.80 | 2.18 | |
| PINION (C) NEW | ||||
| 30 | 379118 | 1.50 | 1.82 | |
| PLANET GEAR (B) SET NEW | ||||
| 31 | 379269 | 1.00 | 1.21 | |
| PINION (B) NEW | ||||
| 32 | 379120 | 1.68 | 2.03 | |
| Planet Gear (a) Set (4 Pcs.) | ||||
| 33 | 370614 | 1.95 | 2.36 | |
| First Ring Gear | ||||
| 34 | 370604 | 1.80 | 2.18 | |
| WASHER (B) NEW | ||||
| 35 | 379121 | 1.00 | 1.21 | |
| MOTOR SPACER NEW | ||||
| 36 | 379122 | 1.00 | 1.21 | |
| STATOR CONTROLLER ASS'Y NEW | ||||
| 37 | 341137 | 53.40 | 64.61 | |
| ROTOR PINION ASS'Y NEW | ||||
| 38 | 361190 | 11.82 | 14.30 | |
| MOTOR PINION NEW | ||||
| 39 | 379110 | 1.26 | 1.52 | |
| SHIFT KNOB NEW | ||||
| 40 | 379104 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 41 | 379103M | |||
| Tapping Screw (w/flange) D3x16 (black) | ||||
| 42 | 313687 | 1.04 | 1.26 | |
| TAIL COVER NEW | ||||
| 43 | 379108 | 1.08 | 1.31 | |
| REAR BUMPER | ||||
| 44 | 373041 | 1.04 | 1.26 | |
| Pushing Button | ||||
| 45 | 339768 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| 46 | 379106M | |||
| DC-SPEED CONTROL SWITCH NEW | ||||
| 47 | 379109 | 8.46 | 10.24 | |
| Battery Terminal | ||||
| 48 | 339769 | 3.00 | 3.63 | |
| HOOK ASS'Y NEW | ||||
| 49 | 379397 | 2.04 | 2.47 | |
| Truss Hd. Screw M4 (black) Except For Europe | ||||
| 50 | 337357 | 1.04 | 1.26 | |
| HOOK | ||||
| 51 | 372229 | 2.85 | 3.45 | |
| No information available, not orderable | ||||
| 52 | 377797M | |||
| Battery Cover | ||||
| 502 | 329897 | 1.80 | 2.18 | |
| No information available, not orderable | ||||
| 503 | 983006 | |||
| No information available, not orderable | ||||
| 504 | 375801M | |||
| No information available, not orderable | ||||
| 601 | 379251M | |||
