Here you will find all available parts and drawings of the 'Hikoki DH45MR'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Hikoki DH45MR
Spare parts list of model Hikoki DH45MR
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Front Cap | ||||
| 1 | 321306 | 3.30 | 3.99 | |
| Grip | ||||
| 2 | 321305 | 4.80 | 5.81 | |
| Spring retaining ring | ||||
| 3 | 318590 | 1.65 | 2.00 | |
| Needle Holder | ||||
| 4 | 321304 | 22.83 | 27.62 | |
| Spring washer | ||||
| 5 | 321303 | 4.80 | 5.81 | |
| Spring Holder (a) | ||||
| 6 | 321302 | 4.80 | 5.81 | |
| Seal Lock Hex. Socket Hd. Bolt M6x25 | ||||
| 7 | 981942 | 1.65 | 2.00 | |
| Front Case | ||||
| 8 | 321300 | 20.49 | 24.79 | |
| O-ring (1as-60) Since 9.1979 | ||||
| 9 | 956996 | 3.00 | 3.63 | |
| O-ring (jaso2060) | ||||
| 9A | 878867 | 3.30 | 3.99 | |
| Oil Seal | ||||
| 10 | 321301 | 6.45 | 7.80 | |
| Rubber Ring | ||||
| 11 | 325229 | 3.30 | 3.99 | |
| Urethane Washer Holder | ||||
| 12 | 315868 | 3.30 | 3.99 | |
| Washer Spring | ||||
| 13 | 948131 | 1.65 | 2.00 | |
| Ball Bearing 6007dduav2s | ||||
| 14 | 6007DD | 14.25 | 17.24 | |
| Bearing Washer | ||||
| 15 | 321297 | 3.30 | 3.99 | |
| Needle Roller D8x20 | ||||
| 16 | 313421 | 5.25 | 6.35 | |
| No longer available, no replacement | ||||
| 17 | 324919 | |||
| O-ring (c) | ||||
| 18 | 324921 | 3.30 | 3.99 | |
| Second Hammer | ||||
| 19 | 324920 | 14.10 | 17.06 | |
| Damper Washer | ||||
| 20 | 324922 | 6.45 | 7.80 | |
| Damper | ||||
| 21 | 324923 | 3.30 | 3.99 | |
| Damper Holder | ||||
| 22 | 324924 | 6.45 | 7.80 | |
| Needle Pin D6x6 | ||||
| 23 | 313057 | 4.20 | 5.08 | |
| Cylinder | ||||
| 24 | 324925 | 87.59 | 105.98 | |
| Holding Spring | ||||
| 25 | 324930 | 1.65 | 2.00 | |
| Lock Sleeve | ||||
| 26 | 324931 | 4.80 | 5.81 | |
| Spring Holder (b) | ||||
| 27 | 324927 | 6.45 | 7.80 | |
| Clutch Spring | ||||
| 28 | 324928 | 1.65 | 2.00 | |
| Striker | ||||
| 29 | 324926 | 14.10 | 17.06 | |
| O-ring | ||||
| 30A | 325297 | 3.30 | 3.99 | |
| Clutch | ||||
| 31 | 324929 | 55.41 | 67.05 | |
| Piston Pin | ||||
| 32 | 324917 | 4.80 | 5.81 | |
| Piston | ||||
| 33 | 324915 | 6.45 | 7.80 | |
| Connecting Rod | ||||
| 34 | 324916 | 6.45 | 7.80 | |
| No longer available, no replacement | ||||
| 35 | 324932 | |||
| Hex. Socket Hd. Bolt (w/flange) M6x25 | ||||
| 36 | 991712 | 1.05 | 1.27 | |
| Gear | ||||
| 37 | 324933 | 43.86 | 53.07 | |
| Seal Lock Hex. Socket Hd. Bolt M4x12 For Switch H | ||||
| 39 | 983162 | 1.05 | 1.27 | |
| Change Lever (old 321309) | ||||
| 40A | 331545 | 3.75 | 4.54 | |
| Lever Holder | ||||
| 41 | 324935 | 3.30 | 3.99 | |
| Retaining Ring (1) | ||||
| 42 | 311229 | 1.05 | 1.27 | |
| Lever Shaft | ||||
| 43 | 324934 | 20.49 | 24.79 | |
| O-ring (p-16) | ||||
| 44 | 873095 | 1.04 | 1.26 | |
| Spring | ||||
| 45 | 321310 | 1.65 | 2.00 | |
| Pushing Button | ||||
| 46 | 321311 | 1.65 | 2.00 | |
| Pin D2x10 | ||||
| 47 | 321312 | 1.65 | 2.00 | |
| Spring Washer D10 (10 pieces) | ||||
| 48 | 939540 | 1.95 | 2.36 | |
| No information available, not orderable | ||||
| 49 | 324909 | |||
| Feather Key 3x3x20 Till 4.2002 | ||||
| 50 | 971750 | 1.05 | 1.27 | |
| Retaining Ring For D40 Hole | ||||
| 51 | 948391 | 1.65 | 2.00 | |
| Ball Bearing 6203ddcmps2l | ||||
| 52 | 6203DD | 7.65 | 9.26 | |
| O-ring (s-40) | ||||
| 53 | 996363 | 1.65 | 2.00 | |
| Oil Seal | ||||
| 54 | 971745 | 4.50 | 5.44 | |
| Seal Lock Hex. Socket Hd. Bolt M6x45 | ||||
| 55 | 986940 | 1.05 | 1.27 | |
| Hex. Socket Hd. Bolt (w/flange) M5x16 | ||||
| 56 | 994192 | 1.04 | 1.26 | |
| No longer available, no replacement | ||||
| 57 | 324937 | |||
| No information available, not orderable | ||||
| 58 | 324912 | |||
| Feather Key 3x3x8 | ||||
| 59 | 944109 | 1.70 | 2.06 | |
| Bevel Pinion | ||||
| 60 | 324913 | 17.05 | 20.63 | |
| Ring | ||||
| 61 | 321279 | 8.40 | 10.16 | |
| Oil Seal | ||||
| 62 | 313050 | 3.90 | 4.72 | |
| Ball Bearing 6002ddcmps2l | ||||
| 63 | 6002DD | 7.05 | 8.53 | |
| Ring | ||||
| 64 | 313058 | 1.05 | 1.27 | |
| Washer (a) | ||||
| 65 | 313053 | 3.60 | 4.36 | |
| Gear Holder | ||||
| 66 | 321281 | 17.88 | 21.63 | |
| Spring | ||||
| 67 | 321282 | 1.65 | 2.00 | |
| No information available, not orderable | ||||
| 68 | 320343 | |||
| Second Gear | ||||
| 69 | 324914 | 32.18 | 38.93 | |
| Spacer | ||||
| 70 | 321283 | 14.30 | 17.30 | |
| Ball Bearing 629vv | ||||
| 71 | 629VVM | 5.85 | 7.08 | |
| Ring | ||||
| 72 | 944525 | 1.05 | 1.27 | |
| Gasket | ||||
| 73 | 325230 | 3.30 | 3.99 | |
| Gear Cover | ||||
| 74 | 324944 | 32.18 | 38.93 | |
| Handle | ||||
| 75 | 324947 | 20.49 | 24.79 | |
| Sds Max Label | ||||
| 77 | 324938 | 1.50 | 1.82 | |
| No information available, not orderable | ||||
| 78 | 313078 | |||
| Handle Holder | ||||
| 79 | 313079 | 16.09 | 19.47 | |
| Hex. Socket Hd. Bolt (w/flange) M5x40 | ||||
| 80 | 980673 | 1.04 | 1.26 | |
| No longer available, no replacement | ||||
| 81 | 313093 | |||
| Pillar Terminal Till 10.1999 For Aus | ||||
| 82 | 938307 | 2.13 | 2.57 | |
| Handle Cover | ||||
| 83 | 324948 | 12.15 | 14.70 | |
| Tapping Screw (w/flange) D4x20 (black) | ||||
| 84 | 301653 | 1.04 | 1.26 | |
| Threaded cable sleeve | ||||
| 85 | 981373 | 1.05 | 1.27 | |
| Terminal M4.0 (10 Pcs.) | ||||
| 86 | 930804 | 3.00 | 3.63 | |
| connecting terminal | ||||
| 86 | 980063 | 1.04 | 1.26 | |
| Cord Clip | ||||
| 87 | 960266 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| 88 | 984750 | |||
| Cord Armor D10.1 | ||||
| 89 | 938051 | 1.04 | 1.26 | |
| No longer available, no replacement | ||||
| 90 | 500391Z | |||
| Handle Bolt | ||||
| 91 | 313080 | 11.85 | 14.34 | |
| No information available, not orderable | ||||
| 92 | 971786 | |||
| Hex. Socket Hd. Bolt (w/flange) M5x12 | ||||
| 93 | 998471 | 1.05 | 1.27 | |
| Hood (a) | ||||
| 94 | 324936 | 14.03 | 16.97 | |
| Crank Case | ||||
| 96 | 324908 | 46.75 | 56.57 | |
| First Gear | ||||
| 97 | 324910 | 23.38 | 28.28 | |
| Second Gear | ||||
| 98 | 324911 | 12.75 | 15.43 | |
| Needle-roller Bearing | ||||
| 99 | 939299 | 10.65 | 12.89 | |
| Hex. Hd. Tapping Screw D5x60 | ||||
| 100 | 961501 | 1.04 | 1.26 | |
| Stator 220v-230v | ||||
| 101 | 340646E | 75.90 | 91.84 | |
| FIELD 110-115 VOLT | ||||
| 101 | 340646C | 64.46 | 78.00 | |
| Housing | ||||
| 103 | 324943 | 87.59 | 105.98 | |
| Brush Cap | ||||
| 104 | 945161 | 1.20 | 1.45 | |
| Carbon Brush (auto Stop Type) (1 Pair) | ||||
| 105 | 999071 | 14.40 | 17.42 | |
| Brush Holder | ||||
| 106 | 962777 | 6.45 | 7.80 | |
| Hex Adjustment Screw M5x8 | ||||
| 107 | 938477 | 1.05 | 1.27 | |
| Tail Cover | ||||
| 108 | 324946 | 9.00 | 10.89 | |
| Seal Lock Hex. Socket Hd. Bolt M5x20 | ||||
| 109 | 984508 | 1.05 | 1.27 | |
| Seal Lock Hex. Socket Hd. Bolt M6x22 | ||||
| 110 | 321313 | 1.65 | 2.00 | |
| Brush Terminal | ||||
| 111 | 937623 | 1.04 | 1.26 | |
| Tube | ||||
| 112 | 321322 | 1.65 | 2.00 | |
| Dust Washer | ||||
| 113 | 985436 | 1.05 | 1.27 | |
| Ball Bearing 6200vvcmps2l | ||||
| 114 | 6200VV | 6.15 | 7.44 | |
| Magnet | ||||
| 115 | 318721 | 17.60 | 21.30 | |
| Ball Bearing 6202dd | ||||
| 116 | 6202DD | 6.75 | 8.17 | |
| Washer | ||||
| 117 | 980700 | 1.04 | 1.26 | |
| Fan | ||||
| 118 | 318918 | 7.95 | 9.62 | |
| ARMATURE 110-115 VOLT | ||||
| 119 | 360737C | 125.34 | 151.66 | |
| Fan Guide | ||||
| 120 | 324945 | 4.80 | 5.81 | |
| Housing (b) Dh45mr | ||||
| 121 | 324942 | 4.80 | 5.81 | |
| SPEED CONTROLLER 110–115 VOLT | ||||
| 122 | 324940 | 99.00 | 119.79 | |
| Internal wire | ||||
| 123 | 317113 | 3.30 | 3.99 | |
| No information available, not orderable | ||||
| 501 | 324820 | |||
| Grease (a) For Hammer.hammer Drill (30g) | ||||
| 502 | 981840 | 8.40 | 10.16 | |
| No information available, not orderable | ||||
| 503 | 944458 | |||
| No information available, not orderable | ||||
| 504 | 944459 | |||
| Grease For Hammer.hammer Drill (70g) | ||||
| 601 | 308471 | 12.75 | 15.43 | |
| Grease For Hammer.hammer Drill (500g) | ||||
| 602 | 980927 | 73.01 | 88.35 | |
| No information available, not orderable | ||||
| 603 | 320859 | |||
| No information available, not orderable | ||||
| 604 | 318085 | |||
| No information available, not orderable | ||||
| 605 | 313448 | |||
| No information available, not orderable | ||||
| 606 | 313456 | |||
| No information available, not orderable | ||||
| 607 | 313449 | |||
| No information available, not orderable | ||||
| 608 | 313457 | |||
| No information available, not orderable | ||||
| 609 | 313450 | |||
| No information available, not orderable | ||||
| 610 | 313458 | |||
| No information available, not orderable | ||||
| 611 | 313451 | |||
| No information available, not orderable | ||||
| 612 | 313459 | |||
| No information available, not orderable | ||||
| 613 | 313452 | |||
| No information available, not orderable | ||||
| 614 | 313460 | |||
| No information available, not orderable | ||||
| 615 | 313453 | |||
| No information available, not orderable | ||||
| 616 | 313461 | |||
| No information available, not orderable | ||||
| 617 | 313454 | |||
| No information available, not orderable | ||||
| 618 | 313462 | |||
| No information available, not orderable | ||||
| 619 | 313455 | |||
| No information available, not orderable | ||||
| 620 | 313463 | |||
| No information available, not orderable | ||||
| 621 | 944460 | |||
| No information available, not orderable | ||||
| 622 | 944461 | |||
| No information available, not orderable | ||||
| 623 | 993038 | |||
| No information available, not orderable | ||||
| 625 | 944500 | |||
| No information available, not orderable | ||||
| 628 | 944477 | |||
| No information available, not orderable | ||||
| 629 | 313465 | |||
| No information available, not orderable | ||||
| 630 | 955994 | |||
| No information available, not orderable | ||||
| 631 | 955995 | |||
| No information available, not orderable | ||||
| 632 | 955996 | |||
| No information available, not orderable | ||||
| 633 | 955997 | |||
| No information available, not orderable | ||||
| 634 | 955998 | |||
| No information available, not orderable | ||||
| 635 | 955999 | |||
| No information available, not orderable | ||||
| 636 | 956000 | |||
| No information available, not orderable | ||||
| 637 | 956001 | |||
| No information available, not orderable | ||||
| 638 | 955154 | |||
| No information available, not orderable | ||||
| 639 | 955166 | |||
| No information available, not orderable | ||||
| 640 | 955155 | |||
| No information available, not orderable | ||||
| 641 | 955167 | |||
| No information available, not orderable | ||||
| 642 | 956002 | |||
| No information available, not orderable | ||||
| 643 | 956003 | |||
| No information available, not orderable | ||||
| 644 | 955157 | |||
| No information available, not orderable | ||||
| 645 | 955168 | |||
| No information available, not orderable | ||||
| 646 | 956004 | |||
| No information available, not orderable | ||||
| 647 | 956005 | |||
| No information available, not orderable | ||||
| 648 | 955159 | |||
| No information available, not orderable | ||||
| 649 | 955169 | |||
| No information available, not orderable | ||||
| 650 | 313466 | |||
| No information available, not orderable | ||||
| 651 | 313467 | |||
| No information available, not orderable | ||||
| 652 | 956009 | |||
| No information available, not orderable | ||||
| 653 | 955165 | |||
| No information available, not orderable | ||||
| 654 | 321813 | |||
| No information available, not orderable | ||||
| 655 | 313468 | |||
| No information available, not orderable | ||||
| 656 | 303334 | |||
| No information available, not orderable | ||||
| 657 | 313469 | |||
| No information available, not orderable | ||||
| 658 | 313470 | |||
| No information available, not orderable | ||||
| 659 | 313471 | |||
| No information available, not orderable | ||||
| 660 | 313472 | |||
| No information available, not orderable | ||||
| 661 | 313473 | |||
| No information available, not orderable | ||||
| 662 | 313474 | |||
| No information available, not orderable | ||||
| 663 | 313475 | |||
| No information available, not orderable | ||||
| 664 | 313476 | |||
| No information available, not orderable | ||||
| 665 | 313478 | |||
| No information available, not orderable | ||||
| 666 | 313477 | |||
| No information available, not orderable | ||||
| 667 | 313479 | |||
| No information available, not orderable | ||||
| 668 | 956006 | |||
| No information available, not orderable | ||||
| 669 | 956007 | |||
