Here you will find all available parts and drawings of the 'Hikoki DH24PG2'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Hikoki DH24PG2
Spare parts list of model Hikoki DH24PG2
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| ARMATURE (C) 220-230 VOLT | ||||
| *56 | 361110E | 21.45 | 25.95 | |
| ANKER (C) 110 VOLT | ||||
| *56 | 361110C | 19.91 | 24.09 | |
| VELD (C) 110 VOLT (W/CR) | ||||
| *58 | 341031C | 19.25 | 23.29 | |
| FIELD (C) 220-230 VOLT | ||||
| *58 | 341031K | 17.33 | 20.96 | |
| SWITCH 220-240 VOLT | ||||
| *68 | 374610 | 15.54 | 18.80 | |
| SWITCH 100-127 VOLT | ||||
| *68 | 374611 | 15.54 | 18.80 | |
| SNOER 10.7 (USE 714500=2X1 5M) | ||||
| *70 | 500247Z | 6.18 | 7.48 | |
| Cord Armor D10.1 | ||||
| *71 | 938051 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| 1 | 306345 | |||
| Spring retaining ring | ||||
| 2 | 306340 | 1.35 | 1.63 | |
| Grip | ||||
| 3 | 374436 | 1.04 | 1.26 | |
| BALL HOLDER | ||||
| 4 | 374437 | 1.50 | 1.82 | |
| HOLDER PLATE | ||||
| 5 | 374435 | 1.04 | 1.26 | |
| Spring | ||||
| 6 | 322812 | 1.65 | 2.00 | |
| Oil Seal | ||||
| 8 | 335259 | 2.85 | 3.45 | |
| No information available, not orderable | ||||
| 9 | 6805BB | |||
| Pushing Button | ||||
| 10 | 322789 | 4.80 | 5.81 | |
| Pushing Spring | ||||
| 11 | 317223 | 1.65 | 2.00 | |
| Change Lever | ||||
| 12 | 334011 | 2.10 | 2.54 | |
| O-ring (s-18) | ||||
| 13 | 878885 | 1.05 | 1.27 | |
| Gear Cover | ||||
| 14 | 374620 | 14.71 | 17.80 | |
| Gear Cover Ass'y Includ.3,17 | ||||
| 15 | 375017 | 14.44 | 17.47 | |
| Spring (e) | ||||
| 16 | 335800 | 1.04 | 1.26 | |
| Ball Bearing 608vvc2ps2l | ||||
| 17 | 608VVM | 5.70 | 6.90 | |
| Steel Ball D7.0 (10 Pcs.) | ||||
| 18 | 335300 | 1.04 | 1.26 | |
| CYLINDER | ||||
| 19 | 374426 | 19.25 | 23.29 | |
| Second Gear | ||||
| 20 | 335265 | 6.15 | 7.44 | |
| Spring (b) | ||||
| 21 | 374430 | 1.20 | 1.45 | |
| Ring | ||||
| 22 | 301679 | 1.20 | 1.45 | |
| Retaining Ring For D30 Shaft | ||||
| 23 | 948310 | 1.35 | 1.63 | |
| Oil Seal (A) | ||||
| 24 | 335262 | 1.80 | 2.18 | |
| HAMMER HOLDER (B) | ||||
| 25 | 374431 | 1.20 | 1.45 | |
| HOLDER SLEEVE | ||||
| 26 | 374427 | 2.55 | 3.09 | |
| Second Hammer | ||||
| 27 | 374432 | 2.70 | 3.27 | |
| HAMMER HOLDER (A) | ||||
| 28 | 374429 | 2.25 | 2.72 | |
| DEMPERRING (A) | ||||
| 29 | 322805 | 1.65 | 2.00 | |
| O-ring (c) | ||||
| 30 | 322808 | 1.65 | 2.00 | |
| Damper Holder | ||||
| 31 | 324524 | 6.45 | 7.80 | |
| STOPPER RING | ||||
| 32 | 322807 | 1.65 | 2.00 | |
| Striker | ||||
| 33 | 374443 | 3.90 | 4.72 | |
| O-Ring | ||||
| 34 | 372816 | 3.00 | 3.63 | |
| PISTON | ||||
| 35 | 372817 | 9.90 | 11.98 | |
| Piston Pin | ||||
| 36 | 335793 | 3.15 | 3.81 | |
| Piston Washer | ||||
| 37 | 335794 | 1.20 | 1.45 | |
| SECOND SHAFT | ||||
| 38 | 374621 | 5.70 | 6.90 | |
| Washer (c) | ||||
| 39 | 335251 | 1.04 | 1.26 | |
| Clutch Spring | ||||
| 40 | 323182 | 1.65 | 2.00 | |
| Clutch | ||||
| 41 | 375022 | 3.90 | 4.72 | |
| Ring | ||||
| 42 | 331315 | 1.05 | 1.27 | |
| Change Plate | ||||
| 43 | 335252 | 1.04 | 1.26 | |
| Reciprocating Bearing | ||||
| 44 | 335249 | 13.65 | 16.52 | |
| First Gear | ||||
| 45 | 374441 | 3.75 | 4.54 | |
| BEARING WASHER | ||||
| 46 | 374442 | 1.04 | 1.26 | |
| O-ring D72.2 | ||||
| 47 | 335245 | 1.20 | 1.45 | |
| INNER COVER | ||||
| 48 | 374433 | 8.10 | 9.80 | |
| Air Cap | ||||
| 49 | 334008 | 1.20 | 1.45 | |
| Felt Packing | ||||
| 50 | 324543 | 1.65 | 2.00 | |
| Felt Packing | ||||
| 51 | 322816 | 1.65 | 2.00 | |
| Packing Washer | ||||
| 52 | 322818 | 3.30 | 3.99 | |
| O-ring (p-22) | ||||
| 53 | 876796 | 1.05 | 1.27 | |
| Ball Bearing 608dd | ||||
| 54 | 608DDM | 5.55 | 6.72 | |
| Washer (a) | ||||
| 55 | 982631 | 1.04 | 1.26 | |
| Hex. Hd. Tapping Screw D4x45 | ||||
| 57 | 981824 | 1.05 | 1.27 | |
| BEHUIZING (OUD 374632+374633) | ||||
| 59A | 376298 | 8.52 | 10.31 | |
| Brush Holder | ||||
| 60 | 955203 | 2.40 | 2.90 | |
| Carbon Brush (1 Pair) | ||||
| 61 | 999041 | 4.50 | 5.44 | |
| Carbon Brush (auto Stop Type) (1 Pair) | ||||
| 62 | 999072 | 14.40 | 17.42 | |
| CHOKE COIL (BROWN) | ||||
| 63 | 374615 | 3.45 | 4.17 | |
| No information available, not orderable | ||||
| 64 | 374613 | |||
| No information available, not orderable | ||||
| 65 | 374612 | |||
| CHOKE COIL (BLUE) | ||||
| 66 | 374614 | 3.45 | 4.17 | |
| Pushing Button | ||||
| 67 | 322853 | 1.05 | 1.27 | |
| SCREW | ||||
| 69 | 301654 | 1.05 | 1.27 | |
| Cord Clip | ||||
| 72 | 937631 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| 73 | 984750 | |||
| Noise Suppressor | ||||
| 74 | 930039 | 1.95 | 2.36 | |
| Tapping Screw (w/flange) D4x20 (black) | ||||
| 76 | 301653 | 1.04 | 1.26 | |
| GRIP SET | ||||
| 77 | 375363 | 2.85 | 3.45 | |
| No information available, not orderable | ||||
| 501 | 374619 | |||
| No information available, not orderable | ||||
| 502 | 324548 | |||
| No information available, not orderable | ||||
| 503 | 303709 | |||
| No information available, not orderable | ||||
| 504 | 337739 | |||
| No information available, not orderable | ||||
| 505 | 336472 | |||
| No information available, not orderable | ||||
| 506 | 336473 | |||
| No information available, not orderable | ||||
| 507 | 336474 | |||
| No information available, not orderable | ||||
| 508 | 337741 | |||
| No information available, not orderable | ||||
| 601 | 306885 | |||
| No information available, not orderable | ||||
| 602 | 986802 | |||
| STOFVANGER | ||||
| 603 | 986803 | 6.54 | 7.91 | |
| Seal | ||||
| 604 | 986804 | 3.38 | 4.08 | |
| Retaining Ring For D30 Shaft | ||||
| 605 | 948310 | 1.35 | 1.63 | |
| RING | ||||
| 606 | 958063 | 1.00 | 1.21 | |
| Steel Ball D6.35 (10 pieces) | ||||
| 607 | 959150 | 1.35 | 1.63 | |
| OUTER RACE | ||||
| 608 | 986805 | 4.26 | 5.15 | |
| Socket | ||||
| 609 | 986806 | 5.10 | 6.17 | |
| Socket Adapter (b) | ||||
| 610 | 306910 | 4.50 | 5.44 | |
| No information available, not orderable | ||||
| 611 | 971787 | |||
| No information available, not orderable | ||||
| 612 | 931844 | |||
| No information available, not orderable | ||||
| 613 | 321814 | |||
| Flat Hd. Screw (left Hand) M6x20 | ||||
| 614 | 331966 | 6.75 | 8.17 | |
| No information available, not orderable | ||||
| 615 | 321813 | |||
| No information available, not orderable | ||||
| 616 | 971511Z | |||
| No information available, not orderable | ||||
| 617 | 971512Z | |||
| No information available, not orderable | ||||
| 618 | 971794 | |||
| No information available, not orderable | ||||
| 619 | 971795 | |||
| No information available, not orderable | ||||
| 620 | 971796 | |||
| No information available, not orderable | ||||
| 621 | 971797 | |||
| No information available, not orderable | ||||
| 622 | 971798 | |||
| No information available, not orderable | ||||
| 623 | 971799 | |||
| No information available, not orderable | ||||
| 624 | 971800 | |||
| No information available, not orderable | ||||
| 625 | 971801 | |||
| No information available, not orderable | ||||
| 626 | 971802 | |||
| No information available, not orderable | ||||
| 627 | 971803 | |||
| No information available, not orderable | ||||
| 628 | 320859 | |||
| No information available, not orderable | ||||
| 629 | 944477 | |||
| No information available, not orderable | ||||
| 630 | 982684 | |||
| No information available, not orderable | ||||
| 631 | 982685 | |||
| Grease For Rotary Hammer (500g) | ||||
| 632 | 335781 | 67.24 | 81.36 | |
| Grease For Rotary Hammer (60g) | ||||
| 633 | 335782 | 13.50 | 16.34 | |
