Here you will find all available parts and drawings of the 'Hikoki CM6'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Hikoki CM6
Spare parts list of model Hikoki CM6
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Stator 220v-230v | ||||
| *11 | 983859E | 43.86 | 53.07 | |
| O-RING (S-9) | ||||
| *33 | 875806 | 1.00 | 1.21 | |
| Cord Armor D10.2 Till 11.1982 For Aus | ||||
| *34 | 930026 | 3.00 | 3.63 | |
| SNOER 10.7 (USE 714500=2X1 5M) | ||||
| *35 | 500247Z | 6.18 | 7.48 | |
| RING | ||||
| *44 | 983860 | 12.98 | 15.71 | |
| RUBBER COVER (B) | ||||
| 1 | 956866 | 1.00 | 1.21 | |
| HANDGREEPDEKSEL | ||||
| 2A | 983857 | 11.34 | 13.72 | |
| No information available, not orderable | ||||
| 2B | 956856Z | |||
| Brush Cap | ||||
| 3 | 961781 | 2.55 | 3.09 | |
| Carbon Brush (1 Pair) | ||||
| 4 | 999043 | 4.50 | 5.44 | |
| Brush Holder | ||||
| 5 | 981586 | 6.45 | 7.80 | |
| Armature | ||||
| 6 | 983860E | 125.40 | 151.73 | |
| Fan Guide | ||||
| 7A | 954584 | 1.80 | 2.18 | |
| Brush Terminal | ||||
| 8 | 930703 | 2.40 | 2.90 | |
| SEAL PACKING | ||||
| 10 | 983858 | 1.00 | 1.21 | |
| Stator 220v-230v | ||||
| 11 | 983859E | 43.86 | 53.07 | |
| Rubber Cover (a) | ||||
| 12 | 956882 | 1.50 | 1.82 | |
| O-ring (1ap-20) | ||||
| 13 | 944486 | 1.05 | 1.27 | |
| Switch | ||||
| 14 | 971667Z | 20.21 | 24.46 | |
| Switch | ||||
| 14A | 958400Z | 18.98 | 22.96 | |
| Switch | ||||
| 14A | 963756Z | 13.20 | 15.97 | |
| Noise Suppressor | ||||
| 15 | 500262Z | 6.45 | 7.80 | |
| Threaded cable sleeve | ||||
| 16 | 981373 | 1.05 | 1.27 | |
| Terminal For Noise Suppressor For Hol | ||||
| 17 | 961419Z | 1.04 | 1.26 | |
| HUIS | ||||
| 18B | 983840 | 36.08 | 43.66 | |
| Tapping Screw (w/washer) D4x20 | ||||
| 20 | 982095 | 1.04 | 1.26 | |
| Hex. Socket Set Screw M5x6 Till 2.1986 | ||||
| 21 | 962782 | 1.04 | 1.26 | |
| Washer M5 (10 Pcs.) | ||||
| 22 | 949424 | 1.05 | 1.27 | |
| Spring Washer M5 (10 pieces) | ||||
| 23 | 949454 | 1.04 | 1.26 | |
| MACHINE SCREW M5X50 (10 PCS.) | ||||
| 24 | 949250 | 1.26 | 1.52 | |
| Dust Seal (a) Till 2.1995 | ||||
| 25 | 956387 | 2.10 | 2.54 | |
| RUBBER PIN (OLD 976441) | ||||
| 26 | 946362 | 1.05 | 1.27 | |
| Ball Bearing 608vvc2ps2l | ||||
| 27 | 608VVM | 5.70 | 6.90 | |
| Tail Cover | ||||
| 28 | 956880 | 1.80 | 2.18 | |
| Hex. Hd. Tapping Screw D5x65 | ||||
| 29 | 960251 | 1.05 | 1.27 | |
| Washer | ||||
| 30 | 956764 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| 31A | 984750 | |||
| Cord Clip | ||||
| 32 | 937631 | 1.04 | 1.26 | |
| O-RING (S-9) | ||||
| 33 | 875806 | 1.00 | 1.21 | |
| O-RING (S-7) | ||||
| 33 | 876316 | 1.00 | 1.21 | |
| Cord Armor D10.2 Till 11.1982 For Aus | ||||
| 34 | 930026 | 3.00 | 3.63 | |
| Cord Armor D8.2 | ||||
| 34 | 930487 | 2.25 | 2.72 | |
| SNOER 10.7 (USE 714500=2X1 5M) | ||||
| 35 | 500247Z | 6.18 | 7.48 | |
| SNOER 2.5M 2 X 1.0 H05VV-F W/PLUG 13A/250V (OLD 50 | ||||
| 35A | 500423Z | 12.87 | 15.57 | |
| Machine Screw M5X14 (10 pieces) | ||||
| 36 | 949238 | 1.05 | 1.27 | |
| HITACHI LABEL | ||||
| 37 | 983865 | 1.00 | 1.21 | |
| Machine Screw M4x14 (10 Pcs.) | ||||
| 38 | 949218 | 1.05 | 1.27 | |
| DEKSEL | ||||
| 39 | 983864 | 8.40 | 10.16 | |
| Bolt (left Hand) W/washer M7x17.5 | ||||
| 40A | 998335 | 1.05 | 1.27 | |
| Washer | ||||
| 42 | 957064 | 4.50 | 5.44 | |
| No information available, not orderable | ||||
| 43 | 310854 | |||
| Ring | ||||
| 44 | 983856 | 17.33 | 20.96 | |
| RING | ||||
| 44 | 983860 | 12.98 | 15.71 | |
| Machine Screw M4x12 (10 Pcs.) | ||||
| 45 | 949217 | 1.05 | 1.27 | |
| Spring Washer M4 (10 pieces) | ||||
| 46 | 949453 | 1.05 | 1.27 | |
| LAGERDEKSEL | ||||
| 47 | 983846 | 3.84 | 4.65 | |
| X-ring | ||||
| 48 | 971134 | 2.25 | 2.72 | |
| BUS | ||||
| 49 | 983853 | 3.72 | 4.50 | |
| O-Ring (s-42) | ||||
| 50 | 983852 | 1.95 | 2.36 | |
| Ball Bearing 6302vvcmps2l | ||||
| 51 | 6302VV | 9.30 | 11.25 | |
| Spindle Ass'y | ||||
| 52 | 983843 | 40.84 | 49.41 | |
| Gear | ||||
| 53 | 983844 | 14.71 | 17.80 | |
| Machine Screw M4x8 (10 Pcs.) | ||||
| 54 | 949215 | 1.05 | 1.27 | |
| PLATE | ||||
| 55 | 983845 | 1.00 | 1.21 | |
| TANDWIELHUISDEKSEL | ||||
| 56 | 983841 | 41.47 | 50.18 | |
| KAP | ||||
| 57 | 940831 | 1.00 | 1.21 | |
| Ball Bearing 6001vv | ||||
| 58 | 6001VV | 6.60 | 7.99 | |
| Gasket | ||||
| 59 | 983847 | 2.55 | 3.09 | |
| Needle Bearing (hk0810) | ||||
| 60 | 670714 | 6.45 | 7.80 | |
| RUBBEREN BUS | ||||
| 61 | 930426 | 1.00 | 1.21 | |
| Roll Pin D6x36 (10 Pcs.) | ||||
| 62 | 949874 | 5.85 | 7.08 | |
| Base | ||||
| 63 | 983861 | 11.10 | 13.43 | |
| HANDEL | ||||
| 64 | 983863 | 1.38 | 1.67 | |
| Washer M8 (10 Pcs.) | ||||
| 65 | 949426 | 1.05 | 1.27 | |
| LINKSBOUT | ||||
| 66 | 983862 | 2.22 | 2.69 | |
| Spring Washer D14 (10 Pieces) | ||||
| 67 | 939543 | 2.55 | 3.09 | |
| AFDICHT RING | ||||
| 69 | 983866 | 1.00 | 1.21 | |
| Threaded cable sleeve | ||||
| 70 | 981373 | 1.05 | 1.27 | |
| INTERNAL WIRE | ||||
| 71 | 983869 | 1.00 | 1.21 | |
| INTERNAL WIRE ASS'Y | ||||
| 72 | 983880 | 1.00 | 1.21 | |
| Connector 50091 (10 Pcs.) | ||||
| 73 | 959140 | 3.30 | 3.99 | |
| No information available, not orderable | ||||
| 501 | 940543 | |||
| No information available, not orderable | ||||
| 502 | 941057 | |||
| No information available, not orderable | ||||
| 601 | 980804 | |||
| No information available, not orderable | ||||
| 602 | 310853 | |||
| No information available, not orderable | ||||
| 604 | 306914 | |||
| No information available, not orderable | ||||
| 605 | 306915 | |||
| No information available, not orderable | ||||
| 606 | 306916 | |||
