Here you will find all available parts and drawings of the 'Hikoki C3606DB'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Hikoki C3606DB
Spare parts list of model Hikoki C3606DB
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Spring (f) | ||||
| *21 | 301631 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| *22 | 379508 | |||
| No information available, not orderable | ||||
| *25 | 379507 | |||
| No information available, not orderable | ||||
| *28 | 307811 | |||
| No information available, not orderable | ||||
| *504 | 379511 | |||
| Spring | ||||
| *69 | 324876 | 1.80 | 2.18 | |
| Washer (a) | ||||
| 1 | 329975 | 6.45 | 7.80 | |
| BEARING HOLDER ASS'Y NEW | ||||
| 2 | 379514 | 21.84 | 26.43 | |
| SECOND SHAFT (A) NEW | ||||
| 3 | 379535 | 9.78 | 11.83 | |
| Ball Bearing 606vv | ||||
| 4 | 606ZZM | 15.40 | 18.63 | |
| Bearing Holder | ||||
| 5 | 338921 | 5.55 | 6.72 | |
| Machine Screw (w/sp. Washer) M4x12 | ||||
| 6 | 951039 | 1.05 | 1.27 | |
| Ring | ||||
| 7 | 339257 | 1.04 | 1.26 | |
| Return Spring | ||||
| 8 | 373078 | 1.04 | 1.26 | |
| Washer Spring | ||||
| 9 | 939548 | 4.65 | 5.63 | |
| WASHER (A) (OLD 338915) | ||||
| 10 | 376366 | 1.20 | 1.45 | |
| SPINDLE GEAR SET (A) NEW | ||||
| 11 | 379534 | 8.10 | 9.80 | |
| Machine Screw M3x8 (10 Pcs.) Since 9.2012 For Eur | ||||
| 12 | 949203 | 1.05 | 1.27 | |
| Bearing Cover | ||||
| 13 | 338922 | 1.04 | 1.26 | |
| Ball Bearing 6901vv-n | ||||
| 14 | 323118 | 6.75 | 8.17 | |
| Lower Guard | ||||
| 15 | 338905 | 3.60 | 4.36 | |
| Knob | ||||
| 16 | 338927 | 1.04 | 1.26 | |
| Tapping Screw D4x10 (black) | ||||
| 17 | 302090 | 1.05 | 1.27 | |
| No information available, not orderable | ||||
| 18 | 338935 | |||
| WASHER (B) (OLD 338916) | ||||
| 19 | 376367 | 1.04 | 1.26 | |
| Hex Flange Bolt | ||||
| 20 | 338917 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| 23 | 379504 | |||
| Machine Screw (w/washer) M4x12 (black) | ||||
| 24 | 333781 | 1.20 | 1.45 | |
| FLOW GUIDE (C) NEW | ||||
| 26 | 379537 | 1.00 | 1.21 | |
| Machine Screw (w/washer) M4x8 (black) | ||||
| 27 | 315500 | 1.35 | 1.63 | |
| STATOR SENSOR PCB ASS'Y (A) NEW | ||||
| 34 | 341148 | 79.70 | 96.44 | |
| No information available, not orderable | ||||
| 34A | 341256 | |||
| LED NEW | ||||
| 35 | 379536 | 10.20 | 12.34 | |
| FAN GUIDE NEW | ||||
| 36 | 379506 | 1.00 | 1.21 | |
| ROTOR ASS'Y (A) NEW | ||||
| 37 | 361202 | 22.28 | 26.96 | |
| Ball Bearing 606vv | ||||
| 38 | 606ZZM | 15.40 | 18.63 | |
| Ball bearing 609vvmc2ps2s | ||||
| 39 | 609VVM | 6.00 | 7.26 | |
| LOCK LEVER NEW | ||||
| 40 | 379515 | 1.00 | 1.21 | |
| O-ring (s-24) | ||||
| 41 | 878609 | 1.05 | 1.27 | |
| LINK NEW | ||||
| 42 | 379523 | 2.88 | 3.48 | |
| GAUGE PLATE (A) NEW | ||||
| 43 | 379527 | 1.00 | 1.21 | |
| NYLOCK SET SCREW M6 NEW | ||||
| 44 | 379529 | 1.00 | 1.21 | |
| HEX. SOCKET PIN M5 NEW | ||||
| 45 | 379533 | 1.00 | 1.21 | |
| GEAR COVER NEW | ||||
| 46A | 380801 | 13.92 | 16.84 | |
| Cushion | ||||
| 47 | 310842 | 1.05 | 1.27 | |
| Flat Hd. Screw M5x20 (10 Pcs.) | ||||
| 48 | 949793 | 1.35 | 1.63 | |
| Special Bolt Till 7.2017 | ||||
| 48A | 333664 | 1.80 | 2.18 | |
| Machine Screw M4x8 (black) | ||||
| 49 | 323211 | 1.05 | 1.27 | |
| PLATE (L) NEW | ||||
| 50 | 379516 | 1.00 | 1.21 | |
| Spring | ||||
| 51 | 334225 | 1.80 | 2.18 | |
| Washer Spring | ||||
| 52 | 942827 | 1.04 | 1.26 | |
| LEVER NEW | ||||
| 53 | 379519 | 1.00 | 1.21 | |
| SPRING PLATE NEW | ||||
| 54 | 379521 | 1.00 | 1.21 | |
| LOCK NUT (B) NEW | ||||
| 55 | 379518 | 1.92 | 2.32 | |
| SPRING NEW | ||||
| 56 | 379526 | 1.00 | 1.21 | |
| SPACER (A) NEW | ||||
| 57 | 379520 | 1.00 | 1.21 | |
| WASHER (S) NEW | ||||
| 58 | 379517 | 1.00 | 1.21 | |
| BOUT M6 (SQUARE) | ||||
| 59 | 372747 | 1.04 | 1.26 | |
| Machine Screw (w/washer) M4x8 (black) | ||||
| 60 | 315500 | 1.35 | 1.63 | |
| Guide Piece (1) | ||||
| 61 | 338913 | 1.04 | 1.26 | |
| WING SCREW (A) | ||||
| 62 | 307937 | 1.05 | 1.27 | |
| Super Lock Washer M6 Single-phase | ||||
| 63 | 948167 | 1.04 | 1.26 | |
| Bolt Washer M6 (10 Pcs.) | ||||
| 64 | 949432 | 1.05 | 1.27 | |
| NEEDLE D5X23.8 NEW | ||||
| 65 | 379528 | 1.00 | 1.21 | |
| Stopper Lever | ||||
| 66 | 333657 | 3.45 | 4.17 | |
| Spring (b) | ||||
| 67 | 339259 | 1.80 | 2.18 | |
| KNOB BOLT M6X17 NEW | ||||
| 68 | 379538 | 1.00 | 1.21 | |
| HEX. SOCKET SET SCREW M5X10 NEW | ||||
| 70 | 377288 | 1.00 | 1.21 | |
| Spring Plate (1) | ||||
| 71 | 376621 | 1.04 | 1.26 | |
| BASE NEW | ||||
| 72 | 379502 | 17.66 | 21.37 | |
| HEX. SOCKET SET SCREW M5X18 NEW | ||||
| 73 | 377289 | 1.00 | 1.21 | |
| NYLON MOER M5 | ||||
| 74 | 377291 | 1.00 | 1.21 | |
| BEVEL PIECE NEW | ||||
| 75 | 379522 | 4.62 | 5.59 | |
| HINGE SHAFT NEW | ||||
| 76 | 379532 | 1.92 | 2.32 | |
| Seal Lock Hex. Socket Set Screw M5x6 | ||||
| 77 | 319541 | 1.50 | 1.82 | |
| Bolt (square) M6x22 | ||||
| 78 | 314623 | 1.80 | 2.18 | |
| Step Pin D6x13 | ||||
| 79 | 320163 | 1.50 | 1.82 | |
| Washer (b) | ||||
| 80 | 322852 | 1.05 | 1.27 | |
| SPECIAL BOLT NEW | ||||
| 81 | 379525 | 1.00 | 1.21 | |
| SUB LINK NEW | ||||
| 82 | 379524 | 1.38 | 1.67 | |
| Wing Bolt M6x18 | ||||
| 83 | 307898 | 1.65 | 2.00 | |
| Wing Nut M6 | ||||
| 84 | 375026 | 1.20 | 1.45 | |
| Tapping Screw (w/flange) D4x30 (black) | ||||
| 85 | 305490 | 1.04 | 1.26 | |
| Machine Screw (w/washers) M5x30 (black) | ||||
| 86 | 880881 | 1.05 | 1.27 | |
| Machine Screw (w/washers) M5x50 (black) | ||||
| 87 | 997841 | 1.05 | 1.27 | |
| MV LABEL (A) (2) NEW | ||||
| 89 | 379349 | 1.00 | 1.21 | |
| KNOB NEW | ||||
| 90 | 379531 | 1.00 | 1.21 | |
| TRIGGER NEW | ||||
| 91 | 379530 | 1.00 | 1.21 | |
| SWITCH NEW | ||||
| 92 | 379415 | 13.42 | 16.24 | |
| ZIJHANDGREEP | ||||
| 93 | 377950 | 2.76 | 3.34 | |
| MV LABEL (B) (2) NEW | ||||
| 94 | 379350 | 1.00 | 1.21 | |
| HOUSING SET (GREEN) NEW | ||||
| 95 | 379497 | 15.29 | 18.50 | |
| HOUSING SET (GREEN) NEW | ||||
| 95A | 379497 | 15.29 | 18.50 | |
| No information available, not orderable | ||||
| 96 | 376072 | |||
| BASE ASS'Y NEW | ||||
| 97 | 379501 | 35.58 | 43.05 | |
| No information available, not orderable | ||||
| 502 | 944459 | |||
| Battery Cover | ||||
| 503 | 329897 | 1.80 | 2.18 | |
| No information available, not orderable | ||||
| 505 | 337528 | |||
| No information available, not orderable | ||||
| 506 | 336474 | |||
| No information available, not orderable | ||||
| 507 | 336473 | |||
| No information available, not orderable | ||||
| 508 | 336472 | |||
| No information available, not orderable | ||||
| 509 | 379560 | |||
| No information available, not orderable | ||||
| 601 | 375630 | |||
| Long Guide (650mm) | ||||
| 602 | 316104 | 91.58 | 110.81 | |
| No information available, not orderable | ||||
| 603 | 962175 | |||
| Wing Bolt M6x18 | ||||
| 604 | 307898 | 1.65 | 2.00 | |
| Spring | ||||
| 605 | 941056 | 1.05 | 1.27 | |
| FLUORINE PLATE ASS'Y NEW | ||||
| 606 | 379784 | 23.87 | 28.88 | |
| Special Bolt | ||||
| 607 | 321996 | 1.65 | 2.00 | |
| No information available, not orderable | ||||
| 608 | 338935 | |||
