Here you will find all available parts and drawings of the 'Hikoki C1806DUM'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Hikoki C1806DUM
Spare parts list of model Hikoki C1806DUM
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| COVER NEW | ||||
| 1 | 338914 | 1.04 | 1.26 | |
| No information available, not orderable | ||||
| 2 | 307811 | |||
| Machine Screw (w/washers) M5x30 (black) | ||||
| 3 | 880881 | 1.05 | 1.27 | |
| Machine Screw (w/washers) M5x50 (black) | ||||
| 4 | 997841 | 1.05 | 1.27 | |
| HOUSING SET (GREEN) NEW | ||||
| 6 | 379497 | 15.29 | 18.50 | |
| KNOB NEW | ||||
| 7 | 379531 | 1.00 | 1.21 | |
| Spring (f) | ||||
| 8 | 301631 | 1.04 | 1.26 | |
| TRIGGER NEW | ||||
| 9 | 379530 | 1.00 | 1.21 | |
| SWITCH NEW | ||||
| 10 | 379415 | 13.42 | 16.24 | |
| Machine Screw (w/washer) M4x8 (black) | ||||
| 11 | 315500 | 1.35 | 1.63 | |
| STATOR SENSOR PCB ASS'Y (A) NEW | ||||
| 12 | 341145 | 79.70 | 96.44 | |
| LED NEW | ||||
| 13 | 379536 | 10.20 | 12.34 | |
| Spring | ||||
| 14 | 334225 | 1.80 | 2.18 | |
| KNURLED KNOB M6 NEW | ||||
| 15 | 380800 | 1.08 | 1.31 | |
| VEER NIEUW | ||||
| 16 | 377691 | 1.00 | 1.21 | |
| HEX. SOCKET PIN M5 NEW | ||||
| 17 | 379533 | 1.00 | 1.21 | |
| NYLOCK SET SCREW M6 NEW | ||||
| 18 | 379529 | 1.00 | 1.21 | |
| GEAR COVER NEW | ||||
| 19 | 380801 | 13.92 | 16.84 | |
| Cushion | ||||
| 20 | 310842 | 1.05 | 1.27 | |
| Special Bolt Till 7.2017 | ||||
| 21 | 333664 | 1.80 | 2.18 | |
| No information available, not orderable | ||||
| 22 | 378683 | |||
| FAN GUIDE NEW | ||||
| 23 | 379542 | 1.00 | 1.21 | |
| ROTOR ASS'Y (B) NEW | ||||
| 24 | 361204 | 22.28 | 26.96 | |
| Ball Bearing 606vv | ||||
| 25 | 606ZZM | 15.40 | 18.63 | |
| Ball bearing 609vvmc2ps2s | ||||
| 26 | 609VVM | 6.00 | 7.26 | |
| Machine Screw M4x8 (black) | ||||
| 27 | 323211 | 1.05 | 1.27 | |
| PLATE (L) NEW | ||||
| 28 | 379516 | 1.00 | 1.21 | |
| LOCK LEVER NEW | ||||
| 29 | 379515 | 1.00 | 1.21 | |
| O-ring (s-24) | ||||
| 30 | 878609 | 1.05 | 1.27 | |
| Washer Spring | ||||
| 31 | 942827 | 1.04 | 1.26 | |
| LEVER NEW | ||||
| 32 | 379519 | 1.00 | 1.21 | |
| SPRING PLATE NEW | ||||
| 33 | 379521 | 1.00 | 1.21 | |
| LOCK NUT (B) NEW | ||||
| 34 | 379518 | 1.92 | 2.32 | |
| GAUGE PLATE (A) NEW | ||||
| 35 | 380789 | 1.00 | 1.21 | |
| SPACER (A) NEW | ||||
| 36 | 379520 | 1.00 | 1.21 | |
| WASHER (S) NEW | ||||
| 37 | 379517 | 1.00 | 1.21 | |
| BOUT M6 (SQUARE) | ||||
| 38 | 372747 | 1.04 | 1.26 | |
| LINK NEW | ||||
| 39 | 379523 | 2.88 | 3.48 | |
| NYLOCK SET SCREW M6 NEW | ||||
| 40 | 379529 | 1.00 | 1.21 | |
| SPRING NEW | ||||
| 41 | 379526 | 1.00 | 1.21 | |
| Washer (a) | ||||
| 42 | 329975 | 6.45 | 7.80 | |
| BEARING HOLDER ASS'Y NEW | ||||
| 43 | 379543 | 20.84 | 25.22 | |
| SECOND SHAFT (A) NEW | ||||
| 44 | 379548 | 8.94 | 10.82 | |
| Ball Bearing 606vv | ||||
| 45 | 606ZZM | 15.40 | 18.63 | |
| Bearing Holder | ||||
| 46 | 338921 | 5.55 | 6.72 | |
| SPINDLE GEAR SET (A) NEW | ||||
| 47 | 379547 | 8.10 | 9.80 | |
| Machine Screw M3x8 (10 Pcs.) Since 9.2012 For Eur | ||||
| 48 | 949203 | 1.05 | 1.27 | |
| Bearing Cover | ||||
| 49 | 338922 | 1.04 | 1.26 | |
| Ball Bearing 6901vv-n | ||||
| 50 | 323118 | 6.75 | 8.17 | |
| Machine Screw (w/sp. Washer) M4x12 | ||||
| 51 | 951039 | 1.05 | 1.27 | |
| Return Spring | ||||
| 52 | 373078 | 1.04 | 1.26 | |
| Washer Spring | ||||
| 53 | 939548 | 4.65 | 5.63 | |
| Ring | ||||
| 54 | 339257 | 1.04 | 1.26 | |
| LOWER GUARD NEW | ||||
| 55 | 380798 | 2.10 | 2.54 | |
| Knob | ||||
| 56 | 338927 | 1.04 | 1.26 | |
| Tapping Screw D4x10 (black) | ||||
| 57 | 302090 | 1.05 | 1.27 | |
| WASHER (A) (OLD 338915) | ||||
| 58 | 376366 | 1.20 | 1.45 | |
| WASHER (B) (OLD 338916) | ||||
| 59 | 376367 | 1.04 | 1.26 | |
| Hex Flange Bolt | ||||
| 60 | 338917 | 1.04 | 1.26 | |
| NOZZLE COVER NEW | ||||
| 61 | 379509 | 1.00 | 1.21 | |
| FLOW GUIDE (C) NEW | ||||
| 62 | 379537 | 1.00 | 1.21 | |
| No information available, not orderable | ||||
| 63 | 338935 | |||
| FT MACHINE SCREW M4X14 NEW | ||||
| 64 | 380145 | 1.00 | 1.21 | |
| O-RING (S-26) | ||||
| 65 | 872470 | 1.65 | 2.00 | |
| DUST NOZZLE (B) NEW | ||||
| 66 | 379510 | 1.92 | 2.32 | |
| SAW COVER (B) NEW | ||||
| 67 | 379551 | 3.24 | 3.92 | |
| Machine Screw (w/washer) M4x12 (black) | ||||
| 68 | 333781 | 1.20 | 1.45 | |
| Special Nut M6 | ||||
| 69 | 333660 | 1.80 | 2.18 | |
| Washer Spring | ||||
| 70 | 942827 | 1.04 | 1.26 | |
| Lever | ||||
| 71 | 333659 | 1.80 | 2.18 | |
| GAUGE PLATE (B) NEW | ||||
| 73 | 380793 | 1.00 | 1.21 | |
| SCREW (W/WASHERS) M5X12 (BLACK) NEW | ||||
| 74 | 380796 | 1.00 | 1.21 | |
| BEVEL PLATE (A) NEW | ||||
| 75 | 380785 | 5.52 | 6.68 | |
| SPECIAL BOLT NEW | ||||
| 76 | 380795 | 1.00 | 1.21 | |
| INDICATOR NEW | ||||
| 77 | 380794 | 1.62 | 1.96 | |
| SUB HANDLE ASS'Y NEW | ||||
| 78 | 380799 | 1.08 | 1.31 | |
| NYLON MOER M5 | ||||
| 79 | 377291 | 1.00 | 1.21 | |
| Washer | ||||
| 80 | 995634 | 1.05 | 1.27 | |
| KNOB BOLT M6X17 NEW | ||||
| 81 | 379538 | 1.00 | 1.21 | |
| Spring | ||||
| 82 | 324876 | 1.80 | 2.18 | |
| Machine Screw (w/washer) M4x8 (black) | ||||
| 83 | 315500 | 1.35 | 1.63 | |
| GUIDE PIECE NEW | ||||
| 84 | 380797 | 1.00 | 1.21 | |
| BASE NEW | ||||
| 85 | 380783 | 22.94 | 27.76 | |
| NYLOCK SET SCREW M6 NEW | ||||
| 86 | 379529 | 1.00 | 1.21 | |
| HINGE SHAFT NEW | ||||
| 87 | 379532 | 1.92 | 2.32 | |
| BEVEL PLATE (B) NEW | ||||
| 88 | 380786 | 17.05 | 20.63 | |
| SPECIAL BOLT (SHOULDER) M4 NEW | ||||
| 89 | 380906 | 1.00 | 1.21 | |
| NYLON NUT M4 NEW | ||||
| 90 | 380907 | 1.00 | 1.21 | |
| WASHER D4 | ||||
| 91 | 371062 | 1.04 | 1.26 | |
| LINK PLATE (B) NEW | ||||
| 92 | 380788 | 1.86 | 2.25 | |
| BEVEL PLATE (C) NEW | ||||
| 93 | 380787 | 5.16 | 6.24 | |
| Super Lock Washer M6 Single-phase | ||||
| 94 | 948167 | 1.04 | 1.26 | |
| BOLT WASHER D6 NEW | ||||
| 95 | 380792 | 1.00 | 1.21 | |
| WING NUT M6 NEW | ||||
| 96 | 380791 | 1.00 | 1.21 | |
| Battery Cover | ||||
| 502 | 329897 | 1.80 | 2.18 | |
| No information available, not orderable | ||||
| 503 | 944459 | |||
| No information available, not orderable | ||||
| 504 | 302756 | |||
| No information available, not orderable | ||||
| 505 | 380802 | |||
| No information available, not orderable | ||||
| 506 | 337528 | |||
| No information available, not orderable | ||||
| 507 | 336472 | |||
| No information available, not orderable | ||||
| 508 | 336473 | |||
| No information available, not orderable | ||||
| 509 | 336474 | |||
| No information available, not orderable | ||||
| 601 | 379259 | |||
| No information available, not orderable | ||||
| 602 | 379264 | |||
