Festool Systainer T-Loc 1-5 / Maxi / Sortainer spare parts and technical drawings

Here you will find all available parts and drawings of the 'Festool 498432 (SystainerT-LOC1-5/Maxi/Sortainer)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes 5 to 10 working days. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Festool 498432 (SystainerT-LOC1-5/Maxi/Sortainer)

Spare parts list of model Festool 498432 (SystainerT-LOC1-5/Maxi/Sortainer)

Pos.	Description	Price excl. VAT	Price incl. VAT
Prices shown include VAT

Cover SYS TL SG2-D11-003
1	700572	35.45	42.89

Handle SYS
2	446249	28.07	33.96

BOLT SYS
3	446250	1.51	1.83

Cross arm SYS-TL ET-BG
4	201893	9.58	11.59

SNAP CLIP GREY SV-SYS 1-5/MAXI MP-4
5	491837	15.61	18.89

BUTTON Sortainer
9	492511	11.75	14.22

Lettering set SYS 3 SORT 10x
10	491694	11.42	13.82

COVER SYS MAXI
11	460289	46.34	56.07

SNAP CLIP GREY SV-SYS MAX I MP-2
12	491840	14.76	17.86

SNAP CLIP GREY SV-SYS 3 SORT MP-4
13	491838	15.37	18.60

SCHUBLADE SYS3 SORT 1B2T1H/KPL
14	491555	22.51	27.24

drawer SYS3 SORT 2B2T1H/KPL
15	491554	26.02	31.48

SCHUBLADE SYS3 SORT 4B2T2H/KPL
16	491553	36.54	44.21

Dividers SYS 3 SORT QUER 1B1H 10x
17	491691	19.48	23.57

Dividers SYS 3 SORT QUER 2B1H 5x
18	491692	15.13	18.31

Dividers SYS 3 SORT QUER 2T2H 2x
19	491693	17.79	21.53

Transparent fla SYS TL-DF
20	702083	35.70	43.20

Separator SYS-DF
21	477478	9.94	12.03

Cover SYS TL-DF
22	702082	44.41	53.74

Closure SYS TL-DF kpl
23	702081	4.25	5.14

Handle SYS TL SG2-G11-005
24	700573	24.44	29.57

plastic tab SYS T-LOC SG2-T12-004
25	700579	1.51	1.83

Bolt SYS T-LOC
26	700574	1.80	2.18

Closure SYS TL kpl- SG2-T01-002
27	497819	15.00	18.15

Adapter Sys TL
28	701315	11.88	14.37

Partition wall Domino-Sort D belbox
29	700716	3.17	3.84

Reservoir Milling machine
30	700715	16.70	20.21

Cover SYS TL SG2-A11-006
31	700576	1.51	1.83

Cover SYS-MIDI 3 TL
32	705119	43.08	52.13

Handle SYS-MINI TL
33	705123	3.31	4.01

Cover SYS-Mini TL transparent
34	718250	12.34	14.93

Cover Sys-mini Tl
34	705122	10.08	12.20

Closure SYS MINI TL kpl.
35	500310	6.05	7.32

Systainer SYS 5 TL
36	10521419	110.84	134.12

Systainer SYS 4 TL
36	10521418	104.42	126.35

Systainer SYS 3 TL
36	10521417	96.80	117.13

Systainer SYS 2 TL
36	10521416	89.18	107.91

Systainer SYS 1 TL
36	10521411	78.89	95.46

Systainer SYS-MAXI 590 X 390 X 210
37	10665017	137.46	166.33

Systainer SYS-MAXI 2 590X390X157.5
37	10665018	114.59	138.65

Insert SYS-DF 700 EQ
99	497719	87.00	105.27

Insert SYS KB-KA 65
99	203244	48.88	59.14

SYSTAINER inser SYS - TL SSP 200
99	764845	45.86	55.49

Insert RAP 150 FE-Set-Plus
99	202343	42.83	51.82

Insert TSC 55
99	708223	40.90	49.49

Insert SYS-HK 85 EB
99	10011998	39.57	47.88

Insert T 18+3 /PSC 420 SYS
99	708226	37.15	44.95

insert SYS-OF D8/D12
99	700866	35.94	43.49

Bedding Sys OF 2200 EB
99	497804	32.31	39.10

Insert STF-D225/ST
99	700882	31.94	38.65

Systainer Inlay SYS-BS DRP 20 ET FF
99	475455	29.52	35.72

Insert Sys Zs-of 2200
99	700878	29.40	35.57

Insert SYS-STF D 150 4S
99	701226	28.31	34.26

Insert SYS-STF D115
99	700831	27.83	33.67

Insert KA 65
99	10004766	27.23	32.95

Insert SYS-TS 75 EBQ
99	700859	26.86	32.50

Insert SYS-STF 80X133
99	700834	26.74	32.36

INSET SYS-MAX I BS 105
99	460687	24.68	29.86

Insert HKC 55
99	708224	24.56	29.72

Insert SYS-STF-RO 90 DX
99	700807	24.44	29.57

Insert SYS-STF D150
99	700830	24.20	29.28

Insert SYS-ISC 240
99	10033232	23.60	28.56

INSET SYS-MAX I BS 75
99	460686	22.99	27.82

Insert SYS-STF D125
99	700848	22.14	26.79

Insert SYS-STF Delta 100x150
99	700847	21.90	26.50

SYSTAINER inser SYS-TL RGP 150-16 E
99	779362	21.05	25.47

Insert SYS 1 CE-SORT
99	700778	20.69	25.03

Insert DF 700 EQ
99	709977	20.33	24.60

Insert SYS 1 UNI
99	700824	20.21	24.45

Insert SYS 1 CE-SORT
99	700780	19.60	23.72

Insert LR-32
99	700902	18.15	21.96

Insert FS-SYS/2
99	700861	17.91	21.67

Insert DF TL DB Stone CE Set 6x
99	768569	17.79	21.53

Insert DF 500 Q
99	478615	14.52	17.57

Insert SYS-TPE
99	700823	13.43	16.25

Cover foam DE SYS 1-5 TL
99	497880	13.19	15.96

Insert WTS 150
99	700838	13.13	15.89

Insert LS 130 EQ
99	700849	13.13	15.89

Insert C 12 Li/ C 15 Li
99	700895	13.13	15.89

Insert SYS-RAS 115
99	700839	13.07	15.81

Insert SYS 1 CE-SORT
99	700779	13.07	15.81

Insert SYS-Dx
99	700871	12.74	15.42

Cover foam KA 65
99	10004767	12.71	15.38

Insert PF1200/ATF/AP 55 SYS
99	700840	12.67	15.33

Insert SYS-PSC 400
99	700885	12.67	15.33

Insert Sys Mfk 700 Eq
99	700877	12.61	15.26

Insert SYS-RS 200/RS 2
99	700853	12.61	15.26

Insert SYS-RS 100/RS 1
99	700854	12.61	15.26

Insert DSC-AG 125 FH SYS
99	717615	12.46	15.08

SYSTAINER inser DCC-AG 125 FH Plus
99	769979	11.95	14.46

Insert T12+3/T15+3/T18+3 AL
99	700897	11.74	14.21

Insert SYS-PSBC 400
99	700886	11.62	14.06

Insert SYS-PS 400
99	700883	11.59	14.02

Insert SYS-HL EB
99	700842	11.59	14.02

Insert SYS-RS 300/RS 3
99	700856	11.38	13.77

Insert OFK 700 EQ
99	700857	11.38	13.77

Insert SYS-DWC 18 Li
99	708221	11.25	13.61

Insert SYS-PSB 300 E
99	700846	11.23	13.59

SYSTAINER insert SYS-BS DSG 125
99	10016224	11.22	13.58

Insert SYS-PSC 420 Li 5,2
99	708225	11.22	13.58

Insert SYS-PSBC 420
99	708227	11.22	13.58

Insert SYS-EHL 65 EQ
99	705323	11.20	13.55

Insert SYS-TS 55 EBQ
99	700860	11.16	13.50

Insert SYS-DS/DTS 400
99	700870	11.16	13.50

Deep drawing in D 36
99	700845	11.09	13.42

Insert LEX 3 77 Set
99	702570	10.90	13.19

Insert RO 90 DX FEQ
99	700893	10.66	12.90

Insert Sys Of 1400
99	700876	10.66	12.90

Insert SYS-RO 125
99	700858	10.66	12.90

Insert AGC 18 Set
99	718397	10.56	12.78

Insert SYS-ETS 125/ES 125
99	700851	10.51	12.72

Insert SYS-C 15/C 18 Li 5,2
99	708220	10.43	12.62

Insert OFK 500
99	717294	10.43	12.62

SYSTAINER inser SYS - TL RGP 80-11 E
99	764862	10.30	12.46

SYSTAINER inser SYS - TL RGP 130-16 E
99	764930	10.30	12.46

Insert SYS-RS/RTS 400
99	700868	10.30	12.46

Insert SYS-PS 300 E
99	700841	10.30	12.46

Insert SYS-RS/RTS 400
99	708098	10.22	12.37

Insert RO 150 FE
99	700879	10.15	12.28

Insert ETS/ES 150
99	700844	10.15	12.28

SYSTAINER inser SYS-BS DSC 125
99	779439	10.10	12.22

Insert SYS-TL-DF CXS/UT
99	703859	9.96	12.05

Insert TI 15
99	704774	9.96	12.05

Insert SYS-PSB 420
99	704792	9.96	12.05

Insert SYS-BHC 18 Li 5,2
99	708218	9.70	11.74

Insert ETS EC 150 SYS
99	708427	9.64	11.66

Insert CXS
99	706330	9.50	11.50

Insert SYS-OF 1010
99	717300	9.50	11.50

Insert CXS
99	700896	9.43	11.41

Insert SYS DF500
99	709976	9.31	11.27

Insert SYS-TS 55 R
99	708457	9.31	11.27

Insert ETS EC 125 SYS
99	708426	9.31	11.27

Insert SYS-TL DRC/PDC
99	708222	9.24	11.18

Insert SYS-T 15+3/T 18+3 Li 5,2
99	708219	9.17	11.10

Insert RTSC/DTSC/ETSC
99	708469	8.84	10.70

Insert AGC 18
99	718290	7.79	9.43

Insert piece HK 85 EB
99	707820	6.73	8.14

Insert OSC 18
99	718272	5.81	7.03

Cover foam SYS ISC 240
99	718216	3.36	4.07

Insert MXP
99	766648	2.57	3.11
