Here you will find all available parts and drawings of the 'Festool 570423 ( RW3E220V )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Festool 570423 ( RW3E220V )
Spare parts list of model Festool 570423 ( RW3E220V )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| No information available, not orderable | ||||
| 1 | xxx | |||
| FIELD COIL OF 1000 E ET-BG | ||||
| 2 | 491885 | 55.30 | 66.91 | |
| Switch attachme ET 2 E | ||||
| 3 | 486317 | 15.00 | 18.15 | |
| CABLE WITH PLUG ZKS-22 DIN-H07RN-F | ||||
| 4 | 457603 | 24.80 | 30.01 | |
| Cable conduit RTR 1409 | ||||
| 5 | 432436 | 1.39 | 1.68 | |
| Oval head screw PT-3,5x10-KT15 | ||||
| 6 | 219031 | 1.39 | 1.68 | |
| TOP CAP RS 3 E VOLLST. | ||||
| 7 | 488661 | 11.78 | 14.25 | |
| No information available, not orderable | ||||
| 8 | xxx | |||
| No information available, not orderable | ||||
| 9 | xxx | |||
| No information available, not orderable | ||||
| 10 | xxx | |||
| No information available, not orderable | ||||
| 11 | xxx | |||
| Oval head screw PT-3,5x10-KT15 | ||||
| 12 | 219031 | 1.39 | 1.68 | |
| BRUSH HOLDER AP 65 E | ||||
| 13 | 488915 | 17.54 | 21.22 | |
| No information available, not orderable | ||||
| 14 | xxx | |||
| HOUSING RS 2 E | ||||
| 15 | 487834 | 37.51 | 45.39 | |
| WASHER 14x21,8x0,3 L+MN 1100 | ||||
| 16 | 203777 | 1.39 | 1.68 | |
| ROLLER BEARING 608 RS DIN 625 | ||||
| 17 | 401524 | 5.09 | 6.16 | |
| No information available, not orderable | ||||
| 18 | xxx | |||
| Oval head screw PT-4,0x50-KT15 | ||||
| 19 | 228707 | 1.39 | 1.68 | |
| Air guide washe RTM-EA | ||||
| 20 | 434430 | 2.11 | 2.55 | |
| BALL BEARING 6200 DDU DIN 625 NSK | ||||
| 22 | 401601 | 8.05 | 9.74 | |
| No information available, not orderable | ||||
| 23 | xxx | |||
| Oval head screw M4x20-TAPTITE-T15 | ||||
| 24 | 228569 | 1.39 | 1.68 | |
| SUPRESSOR RTM | ||||
| 25 | 436753 | 11.55 | 13.98 | |
| Cable clamp RS 3 | ||||
| 26 | 439288 | 1.39 | 1.68 | |
| Cable clamp RTK-S | ||||
| 26 | 431899 | 1.39 | 1.68 | |
| Oval head screw PT-3,5x16-KT15 | ||||
| 27 | 228663 | 1.39 | 1.68 | |
| HANDLE SEGMENT KF 4 E | ||||
| 28 | 451403 | 6.67 | 8.07 | |
| Oval head screw PT-4.0x20-KT15 | ||||
| 29 | 228567 | 1.39 | 1.68 | |
| HANDLE RW 900 E | ||||
| 30 | 203755 | 18.51 | 22.40 | |
| SEAL RW 3 E | ||||
| 31 | 438515 | 3.04 | 3.68 | |
| GEAR RW 900 E | ||||
| 32 | 435670 | 64.74 | 78.34 | |
| Circlip DIN 472-47x1,75 | ||||
| 33 | 771487 | 1.39 | 1.68 | |
| SEAL 22-32-7/8 BF.B1DSL | ||||
| 34 | 410653 | 16.01 | 19.37 | |
| SPACER RW 2 E | ||||
| 35 | 436623 | 2.83 | 3.42 | |
| Gear housing RW 900 E VOLLST. | ||||
| 36 | 487491 | 54.81 | 66.32 | |
| Oval head screw M4x20-TAPTITE-T15 | ||||
| 37 | 228569 | 1.39 | 1.68 | |
| Ch. head screw DIN 6912-M6x18-8.8 | ||||
| 38 | 223541 | 1.39 | 1.68 | |
| RING HANDLE RW 3 E | ||||
| 39 | 483903 | 91.96 | 111.27 | |
| BEARING COVER RW 900 E VOLLST. | ||||
| 40 | 487492 | 51.42 | 62.22 | |
| SPACER RW 2 E KOMPL. | ||||
| 41 | 483149 | 14.88 | 18.00 | |
| Gearwheel RW 3 E | ||||
| 42 | 484487 | 61.95 | 74.96 | |
| WASHER RW 2 E | ||||
| 43 | 435669 | 1.85 | 2.24 | |
| BALL BEARING 6303 DIN 625 | ||||
| 44 | 789921 | 9.91 | 11.99 | |
| Woodruff key 4x5 DIN 6888 | ||||
| 45 | 200773 | 1.39 | 1.68 | |
| SHAFT RW 2 E | ||||
| 46 | 435671 | 56.02 | 67.78 | |
