Here you will find all available parts and drawings of the 'Festool 567408 (RS3VersionA)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Festool 567408 (RS3VersionA)
Spare parts list of model Festool 567408 (RS3VersionA)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Oval head screw PT-3,5x10-KT15 | ||||
| 1 | 219031 | 7.32 | 8.86 | |
| No longer available, no replacement | ||||
| 2 | 451430 | |||
| Oval head screw PT-3,5x10-KT15 | ||||
| 7 | 219031 | 7.32 | 8.86 | |
| BRUSH ET2E / RS2/3/4 1PAIR | ||||
| 8 | 489018 | 11.74 | 14.21 | |
| No information available, not orderable | ||||
| 9 | xxx | |||
| HOUSING RS 2 E | ||||
| 10 | 487834 | 38.96 | 47.14 | |
| WASHER 14x21,8x0,3 L+MN 1100 | ||||
| 11 | 203777 | 1.51 | 1.83 | |
| Groove Ball Bearing 608 D1 MC3 E U152 J2 HA1 | ||||
| 12 | 10775821 | 5.54 | 6.70 | |
| No information available, not orderable | ||||
| 13 | xxx | |||
| WIRE RTM-EA VOLLST. | ||||
| 14 | 434527 | 2.90 | 3.51 | |
| FIELD COIL RS 2 ET-BG 230V | ||||
| 15 | 493158 | 61.71 | 74.67 | |
| Oval head screw PT-4,0x50-KT15 | ||||
| 16 | 228707 | 1.51 | 1.83 | |
| ARMATURE 230V RS 3 ET-BG 230V | ||||
| 17 | 493160 | 124.75 | 150.95 | |
| Air guide washe RTM-EA | ||||
| 18 | 434430 | 2.30 | 2.78 | |
| FAN RW 900 E | ||||
| 19 | 441731 | 4.10 | 4.96 | |
| BALL BEARING 6200 DDU DIN 625 NSK | ||||
| 20 | 401601 | 8.78 | 10.62 | |
| No information available, not orderable | ||||
| 21 | xxx | |||
| No information available, not orderable | ||||
| 22 | xxx | |||
| FAN COVER RS 3 | ||||
| 23 | 438717 | 4.39 | 5.31 | |
| Oval head screw M4x20-TAPTITE-T15 | ||||
| 24 | 228569 | 1.51 | 1.83 | |
| SUPRESSOR RTM | ||||
| 25 | 436753 | 12.61 | 15.26 | |
| Cable clamp RS 3 | ||||
| 26 | 439288 | 1.51 | 1.83 | |
| Switch attachme ET 2 E | ||||
| 27 | 486317 | 15.00 | 18.15 | |
| HANDLE SEGMENT KF 4 E | ||||
| 28 | 451403 | 7.27 | 8.80 | |
| WIRE RTM-EA VOLLST. | ||||
| 29 | 434865 | 2.81 | 3.40 | |
| CLIP RTM-EA VOLLST. | ||||
| 30 | 482039 | 32.43 | 39.24 | |
| SPRING RTM-EA | ||||
| 31 | 434588 | 2.66 | 3.22 | |
| Pin RTM-EA | ||||
| 32 | 434528 | 2.09 | 2.53 | |
| BAG CLIP F R TURBOFILTER | ||||
| 33 | 434696 | 10.58 | 12.80 | |
| Turbo filter bag | ||||
| 34 | 487779 | 10.00 | 12.10 | |
| Turbo filter bag set | ||||
| 35 | 487780 | 29.00 | 35.09 | |
| Oval head screw M4x8-TAPTITE-T15 | ||||
| 36 | 228570 | 9.17 | 11.10 | |
| Cable conduit RTR 1409 | ||||
| 37 | 432436 | 1.51 | 1.83 | |
| Oval head screw PT-4.0x20-KT15 | ||||
| 38 | 228567 | 1.51 | 1.83 | |
| Oval head screw DIN 7985-M4x10-8.8-TUF+ | ||||
| 39 | 228586 | 1.51 | 1.83 | |
| CABLE WITH PLUG AP 85 E DIN-H05RN-F | ||||
| 45 | 457600 | 24.32 | 29.43 | |
| FELT SEAL RTM-EA | ||||
| 46 | 434525 | 7.56 | 9.15 | |
| DUST COVER RS 3 | ||||
| 47 | 438293 | 3.02 | 3.65 | |
| No longer available, no replacement | ||||
| 48 | 438173 | |||
| No information available, not orderable | ||||
| 49 | xxx | |||
| No longer available, no replacement | ||||
| 50 | 435936 | |||
| BASE PLATE COMP RS 3 VOLLST. | ||||
| 51 | 483874 | 74.05 | 89.60 | |
| BASE PLATE COMP RS 3 VOLLST. | ||||
| 52 | 483874 | 74.05 | 89.60 | |
| BEARING 6003 DDU C3 FA.NSK | ||||
| 53 | 228756 | 10.37 | 12.55 | |
| ECCENTRIC BALAN RS 3 | ||||
| 54 | 451089 | 26.50 | 32.06 | |
| CAP RTM-EA | ||||
| 55 | 435290 | 2.09 | 2.53 | |
| Sanding pad STICKFIX | ||||
| 56 | 483905 | 24.00 | 29.04 | |
| Sanding pad | ||||
| 56 | 489630 | 21.00 | 25.41 | |
| Oval head screw DIN 7985-M4x10-8.8-PR30+ | ||||
| 57 | 228733 | 1.51 | 1.83 | |
| Oval head screw PT-3,5x16-KT15 | ||||
| 58 | 228663 | 1.51 | 1.83 | |
